TruVision HD-TVI 3MPX
Camera Installation Guide
P/N 1073216-EN • REV C • ISS 03FEB17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TruVision HD-TVI 3MPX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Interlogix TruVision HD-TVI 3MPX

Summary of Contents for Interlogix TruVision HD-TVI 3MPX

  • Page 1 TruVision HD-TVI 3MPX Camera Installation Guide P/N 1073216-EN • REV C • ISS 03FEB17...

  • Page 3: Table Of Contents

    Contents Introduction 2 Product overview 2 Installation 4 Installation environment 4 Package contents 5 Camera description 15 Mounting the TVI fixed lens bullet camera 20 Mounting the TVI VF motorized lens bullet camera 26 Mounting the TVI fixed lens turret camera 32 Mounting the TVI VF motorized lens turret camera 41 Specifications 50...

  • Page 4: Introduction

    Introduction Product overview This is the installation guide for TruVision 3MPX HD-TVI camera models: HD-TVI fixed lens bullet camera:  TVB-2407 (3MPX Bullet, 3.6 mm lens, PAL)  TVB-4407 (3MPX Bullet, 3.6 mm lens, NTSC) HD-TVI VF motorized lens bullet camera: ...
  • Page 5 HD-TVI VF motorized lens turret camera:  TVT-2402 (3MPX Turret, 2.8 to 12 mm lens, PAL)  TVT-4402 (3MPX Turret, 2.8 to 12 mm lens, NTSC) Installation Guide...

  • Page 6: Installation

    Installation This section provides information on how to install the cameras. Installation environment When installing your product, consider these factors: • Electrical: Install electrical wiring carefully. It should be done by qualified service personnel. Always use a proper PoE switch or a 12 VDC UL listed Class 2 or CE certified power supply to power the camera.

  • Page 7: Package Contents

    • Moisture: Do not expose the camera to rain or moisture, or try to operate it in wet areas. Turn the power off immediately if the camera is wet and ask a qualified service person for servicing. Moisture can damage the camera and also create the danger of electric shock.
  • Page 8 HD-TVI fixed lens bullet camera  Camera with power  3 screws (4 × and video output cable 25 mm) and 3 harness (cables not anchors (7.5 × shown) 24.5 mm)  Mounting template  Installation guide Installation Guide...
  • Page 9 • 12 VDC connector: • Torx wrench Two terminal connector with positive and negative indicators • CD • Equipment disposal sheet • Battery disposal sheet Installation Guide...
  • Page 10 HD-TVI VF motorized lens bullet camera  Camera with power  4 screws (4 × and video output 25 mm) and 4 (7.5 × cable harness (cables 24.5 mm) anchors not shown) • Torx wrench • Back box • Video test cable •...
  • Page 11  Mounting template  Installation guide Ceiling Mounting 1:Screw Hole for 2:Screw Hole for Bracket Mounting Base • CD • Equipment disposal sheet • Battery disposal sheet Installation Guide...
  • Page 12 HD-TVI fixed lens turret camera • 3 screws (4 × 25 mm)  Camera with power and 3 anchors (7.5 × and video output cable harness (cables 24.5 mm) not shown) • 12 VDC connector:  Mounting template Two terminal connector with positive and negative indicators...
  • Page 13 • Adapter plate  4 screws (PM6-32 × 10). Used to attach the turret camera to a 2 Gang electrical box  4 screws (KM4 × 8).  3 screws (PM4 x 8). Used to attach the Used to attach the turret camera to the turret camera to the bracket...
  • Page 14  Equipment disposal  Battery disposal sheet sheet HD-TVI VF motorized lens turret camera  3 screws (4 × 25  Camera with power and video output cable mm) and 3 anchors (7.5 × 24.5 mm) harness  Template  Installation guide Installation Guide...
  • Page 15 • 12 VDC connector:  Adapter plate Two-terminal connector with positive and negative indicators  4 screws (KM4 x 8).  4 screws (PM6-32 Used to attach turret × 10). Used to camera to bracket attach the turret camera to a 2 Gang electrical box ...
  • Page 16 • Equipment disposal • Battery disposal sheet sheet Installation Guide...

  • Page 17: Camera Description

    Camera description Figure 1: HD-TVI fixed lens bullet camera Selectable TVI or IR LEDs 960H output HD-TVI (wires 12 VDC power disconnected) / 960H (wires Mounting base connected Camera body together) selection Lens Installation Guide...
  • Page 18 Figure 2: HD-TVI VF motorized lens bullet camera Lens Sunshield Selectable TVI or Mounting base 960H output Access to 960H or 12 VDC/24 VAC TVI selection power switch Camera body Note: When making adjustments to the motorized lens bullet, it is important to make sure that the access cover for the area that contains the video test cable connector, OSD menu button, and the 960H/TVI selection switch is properly tightened to prevent leakage.
  • Page 19 Video test cable 960H/TVI selection switch OSD menu button Note: When making adjustments to the motorized lens bullet, it is important to make sure that the access cover for the area that contains the video test cable connector, OSD menu button, and the 960H/TVI selection switch is properly tightened to prevent leakage.
  • Page 20 Figure 3: HD-TVI fixed lens turret camera Trim ring Selectable TVI or 960H output Housing HD-TVI (wires Base disconnected) / Lens assembly 960H (wires connected 12 VDC power together) selection Installation Guide...
  • Page 21 Figure 4: HD-TVI VF motorized lens turret camera Lens assembly 12 VDC power Housing Selectable TVI or 960H output Trim ring HD-TVI (wires Base disconnected) / OSD (5-direction) 960H (wires button connected together) selection Installation Guide...

  • Page 22: Mounting The Tvi Fixed Lens Bullet Camera

    Mounting the HD-TVI fixed lens bullet camera Surface mount Place the provided template level against the mounting surface and mark the position of the mounting holes. Following all local safety regulations, drill and prepare the mounting and cable access (if required) holes.
  • Page 23 Connect the corresponding cables. Adjust the camera to get the best viewing angle. See the figure below. Pan position range: 0-360° P (pan) adjustment T (tilt) adjustment R (rotation) adjustment Rotation position Tilt position range: range: 360° 0-180° Installation Guide...
  • Page 24 Loosen the P screw to adjust the pan direction [0-360°]. Tighten the screw after completing the adjustment. Loosen the T screw to adjust the tilt direction [0-180°]. Tighten the screw after completing the adjustment. Loosen the R screw and rotate the camera [0-360°] to adjust the lens to the desired surveillance angle.
  • Page 25 Route the cables through the cable access hole of the back box. Mount the camera to the back box cover using the screws provided. Place the mounting template level against the mounting surface and mark the position of the mounting holes. Use the ‘UP’ marking on the back box and camera mounting base as a reference.
  • Page 26 Following all local safety regulations, drill and prepare the mounting holes. Install the back box to the mounting surface using the hardware provided. Installation Guide...
  • Page 27 Connect the corresponding cables and install the back box cover and camera to the back box. Refer to step 6 of “Surface mount” on page 20 to adjust the camera viewing angle. Installation Guide...

  • Page 28: Mounting The Tvi Vf Motorized Lens Bullet Camera

    Mounting the HD-TVI VF motorized lens bullet camera Surface mount when using the optional back box Place the provided template level against the mounting surface and mark the position of the mounting holes. Following all local safety regulations, drill and prepare the mounting and cable access (if required) holes.
  • Page 29 Secure the camera to the mounting surface with the provided hardware. Connect the corresponding cables. Adjust the camera to get the best viewing angle. See the figure below. Installation Guide...
  • Page 30 P (pan) adjustment T (tilt) adjustment R (rotation) adjustment Loosen the P screw to adjust the pan direction [0-360°]. Tighten the screw after completing the adjustment. Loosen the T screw to adjust the tilt direction [0-180°]. Tighten the screw after completing the adjustment.
  • Page 31 Surface mount when using the optional back box Remove the cover from the back box and align the screw holes of the bullet camera with the holes in the back box cover. Route the cables through the cable access hole of the back box.
  • Page 32 Place the provided template level against the mounting surface and mark the position of the mounting holes. Following all local safety regulations, drill and prepare the mounting holes. Install the back box to the mounting surface using the hardware provided. Installation Guide...
  • Page 33 Connect the corresponding cables and install the back box cover with camera to the back box. Installation Guide...

  • Page 34: Mounting The Tvi Fixed Lens Turret Camera

    Refer to step 6 of “Surface mount” on page 28 to adjust the camera to the desired viewing angle. Mounting the HD-TVI fixed lens turret camera Surface mount Disassemble the turret camera by rotating the trim ring, as shown below. Place the provided template level against the mounting surface and mark the position of the mounting holes.
  • Page 35 Following all local safety regulations, drill and prepare the mounting and cable holes. Route the cables through the cable access (if required) hole. Secure the mounting base to the mounting surface with the hardware provided. Installation Guide...
  • Page 36 Route the cables. Connect the power cord and TVI cables. Reassemble the turret camera by rotating the trim ring back in place. If installing the turret camera to a wall mount or other accessory, an adapter plate is provided. Installation Guide...
  • Page 37 Install the adapter plate to the accessory with three PM4 x 8 screws, referencing number "2". Adjust the camera to get the best viewing angle. See figure below. Installation Guide...
  • Page 38 Pan position range: 0-360° Tilt position range: Rotation position 0-75° range: 0-360° Hold the camera body and rotate the enclosure to adjust the pan angle [0- 360°]. Move the camera body up and down to adjust the tilt angle [0-75°]. Rotate the camera body to adjust the azimuth angle [0-360°].
  • Page 39 Surface mount when using the optional back box Disassemble the turret camera by rotating the trim ring, as shown below. Remove the cover from the back box. Place the provided template level against the mounting surface and mark the position of the mounting holes.
  • Page 40 Route the cables through the cable access hole of the back box. Mount the camera to the cover of the back box. Mount the back box to the mounting surface. Installation Guide...
  • Page 41 Connect the corresponding cables and install the back box cover, with camera, to the back box. Rotate the trim ring back on to the camera, as shown below. Installation Guide...
  • Page 42 Refer to step 8 of “Surface mount” on page 32 to adjust the camera to the desired viewing angle. Installation Guide...

  • Page 43: Mounting The Tvi Vf Motorized Lens Turret Camera

    Mounting the HD-TVI VF motorized lens turret camera Surface mount Place the provided template level against the mounting surface and mark the position of the mounting holes. Following all local safety regulations, drill and prepare the mounting holes. Disassemble the turret camera by rotating the trim ring counterclockwise, as shown below.
  • Page 44 Secure the mounting base to the surface using the screws provided. If installing the turret camera to a wall mount or other accessory, an adapter plate is provided. Install the adapter plate to the accessory with three PM4 x 8 screws, referencing number "2". Installation Guide...
  • Page 45 Reassemble the turret camera by rotating the trim ring back on the camera, as shown below. Helpful hints when mounting the turret camera: Mount the turret base to a surface. Installation Guide...
  • Page 46 When mounting on a wall, aim the lens towards the floor and the UP marking on the camera assembly towards the ceiling. Place the camera eyeball assembly on two of the three standoffs of the mounting base. Place the turret housing over the camera assembly.
  • Page 47 Hold the camera body and rotate the enclosure to adjust the pan angle [0- 360°]. Move the camera body up and down to adjust the tilt angle [0-75°]. Rotate the camera body to adjust the azimuth angle [0-360°]. Pan position range: Tilt position range: 0-360°...
  • Page 48 Place the provided template level against the mounting surface and mark the position of the mounting holes. Following all local safety regulations, drill and prepare the mounting holes. Disassemble the turret camera by rotating the trim ring counterclockwise, as shown below. Installation Guide...
  • Page 49 Route the cables through the cable access hole of the back box. Mount the camera to the back box. Installation Guide...
  • Page 50 Install the back box to the mounting surface using the hardware provided. Connect the corresponding cables and install the back box cover and camera to the back box. Installation Guide...
  • Page 51 Rotate the trim ring back on to the camera body, as shown by the arrow. Adjust the camera according to step 8 of “Surface mount” on page 37 to get the best viewing angle. Installation Guide...

  • Page 52: Specifications

    Specifications Power supply 12 VDC / 24 VAC TVB-2407 / TVB-4407: Current 12 VDC: Max. 417 mA TVB-2408/TVB-4408: 12 VDC: Max. 750 mA / 24 VAC: Max. 400 mA TVT-2401/TVT-4401: 12 VDC: Max. 417 mA TVT-2402/TVT-4402: 12 VDC: Max. 550 mA TVB-2407/TVB-4407: Power consumption...
  • Page 53 Weight (net) TVB-2407/TVB-4407: 370 g / 0.82 lb. TVB-2408/TVB-4408: 900 g / 1.98 lb. TVT-2401/TVT-4401: 350 g / 0.77 lb. TVT-2402/TVT-4402: 750 g / 1.57 lb. TVB-2407/TVB-4407: Dimensions 58.2 × 154.5 mm / 2.3 × 6.08 in. TVB-2408/TVB-4408: 94.7 × 265.4 mm / 3.7 × 10.45 in. TVT-2401/TVT-4401: 226.7 ×...

  • Page 54: Legal And Regulatory Information

    Legal and regulatory information Copyright: © 2017 United Technologies Corporation. All rights reserved. Interlogix is part of UTC Climate, Controls & Security, a unit of United Technologies Corporation. Trademarks and patents: Trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products.
  • Page 55 and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
  • Page 56 Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info. Contact information: For contact information, see www.interlogix.com or www.utcfssecurityproducts.eu Installation Guide...
