Without cup base:
120 mm
86 mm
46 mm

Pin definitions

There are eight wires on a standard UTP/STP cable and each wire is
color-coded. The following shows the pin allocation and color of straight
and crossover cable connection:
Figure 3: Straight-through cable
1 White/Orange
2 Orange
3 White-Green
4
5 White/Blue
6 Green
7 White/Brown
8 Brown
16
20 mm
Blue
205 mm
145.5 mm
White/Orange
Orange
White-Green
Blue
White/Blue
Green
White/Brown
Brown
1
2
3
4
5
6
7
8
