- Page 1 Operation manual Brise...
- Page 3 PREAMBLE This certificate of fans "ECO" and "BRISE" contains the description, operation and installation data, rules and warnings important for correct and safe operation of the fan. PURPOSE Household fans "ECO" and "BRISE" (hereinafter "the fans”) are intended for ventilation of the household and public premises heated in winter time.
- Page 4 Fig. 1 1 - electric motor, 2 - control box cover, 3 - control box, 4 - switching box, 5 - connector block, 6 - fan case, 7 - impeller, 8 - fan cover, 9 - control card, 10 - automatic diaphragm.
- Page 5 Fig. 2 1 - electric motor, 2 - impeller, 3 - control box cover, 4 - control box; 5 - switching box, 6 - connector block, 7 - fan case, 8 - ring, 9 - fan cover...
- Page 6 Table 1 Max, Rated power, Noise Weight, air inflow, Type level, dBA m /hour Eco 100 Brise 100 Brise 100 max Overall and connecting sizes of fan "ECO" Fig. 3 Overall and connecting sizes of fan "Brise" Fig. 4...
-
Page 7: Safety Requirements
SAFETY REQUIREMENTS The fans belong to devices of the Class A insulation by type of protection against electric-shock hazard. Level of protection against access to hazardous parts and water ingress protection is IP24. Before connection of the fan to network, you should be convinced of absence of visible damages of the impeller, case, cover, and that there are no foreign objects left in flowing part of the case which can damage impeller. - Page 8 POWER NETWORK CONNECTION DIAGRAM 220-240 V Fig. 5 Fig. 6...
- Page 9 Fig. 7 Fig. 8...
-
Page 10: Fan Installation
FAN INSTALLATION To install the fan, you should: 1. Remove the cover from the fan (fig. 9) 2. Put the fan to a wall and mark the fixing apertures (fig. 10). 3. Drill the apertures in a wall and insert the dowels (fig. 11). 4. - Page 11 Fig. 10 Fig. 11...
- Page 12 Fig. 12 Fig. 13...
- Page 13 Fig. 14 Fig. 15...
-
Page 14: Storage Rules
STORAGE RULES Store the fans in the manufacturer packaging in an aired room at temperature from +5°C to +40°C and relative air humidity no more than 80 % (at t=25°C). Presence of steams, acids, alkalis and other aggressive impurities in air is not allowed. -
Page 15: Manufacturer's Guarantees
MANUFACTURER'S GUARANTEES We hereby declare that the following complies with the essential protection requirements of Electromagnetic Council Directive 2004/108/EC, 89/336/EEC and Low Voltage Directive 2006/95/EC, 73/23/EEC and CE-marking Directive 93/68/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility. This certificate is issued following test carried out on samples of the product referred to above. -
Page 16: Manufacturing Date
Eco 100 Brise 100 Brise 100 max The model (underline the necessary) is serviceable SALE DATE MANUFACTURING DATE SELLER STAMP OF INSPECTOR ECO_BRISE_DE_EN-02...
