- Page 1 SEQUEL 20 6114 ® 3-DRAWER FILE PEDESTAL INSTRUCTION MANUAL LET’S GET STARTED. DESIGN MATTHEW WEATHERLY...
- Page 3 Congratulations on the purchase of your Sequel 20 3 Drawer File Pedestal 6114 from BDI. Your file pedestal has been designed to provide a lifetime of enjoyment. This manual will provide you with assembly instructions and other helpful information that will ensure that you get the most out of your file pedestal.
- Page 4 HARDWARE AND COMPONENTS Unpack and identify the parts listed below. The assembly workspace should be a non-marring surface such as carpet. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. Do not use power tools for assembly of this product.
- Page 5 HARDWARE AND COMPONENTS PART # DESCRIPTION Cabinet QUANTITY PART # PART # PART # DESCRIPTION DESCRIPTION Drawer Pull DESCRIPTION Glass Top QUANTITY QUANTITY QUANTITY TOOL REQUIRED (NOT INCLUDED) Phillips Screwdriver NEED ASSISTANCE? customerservice@bdiusa.com BDIUSA.COM | 5...
-
Page 6: Step 1. Attach The Legs
ASSEMBLY STEP 1. ATTACH THE LEGS Carefully position (C1) Cabinet onto its back. Install PART/DESCRIPTION (C2) Legs using (H1) Screws and (T1) Hex Wrench. T1-HEX WRENCH H1-SCREW 6 | BDIUSA.COM SEQUEL 20 6114... - Page 7 STEP 2. ATTACH DRAWER PULLS ASSEMBLY Open a drawer and connect a (C3) Drawer Pull PART/DESCRIPTION using 2 (H2) Screws. Tighten with a Phillips Screwdriver (not included). Install the other 2 (C3) Drawer Pulls one at a time. H2-Screw NOT INCLUDED Phillips Screwdriver NEED ASSISTANCE? customerservice@bdiusa.com BDIUSA.COM | 7...
-
Page 8: Fine Tuning
1.5 mm FINE TUNING LEVEL CABINET If needed, dial out 1 or more levelers using the PART/DESCRIPTION (T2) Leveler Wrench attain a level stance. T2-Leveler Wrench down 8 | BDIUSA.COM SEQUEL 20 6114... - Page 9 ARRANGING YOUR FILES FINE TUNING Letter sized file folders fit side-to-side as shown. PART/DESCRIPTION Legal sized file folders fit front-to-back. For Letter or A4 files facing front-to-back, attach (H5) File Bar Clip to both ends of (H4) Small File H4-SMALL FILE BAR Bar as shown.
-
Page 10: Care And Maintenance
While BDI’s stained wood finishes are stable in tone & appearance, all finishes are subject to some degree of discoloration with prolonged exposure to direct sunlight. Please take care to avoid positioning your BDI cabinet in any area with extensive direct sunlight. -
Page 11: Warranty
WARRANTY BDI warrants to the original purchaser that for the below stated warranty term, BDI will repair or replace any product, part, or component covered by this warranty which fails under normal use as a result of a defect in material or workmanship. BDI will repair or replace the aforementioned product, part or component with a comparable product, part or component. - Page 12 These distinctive product configurations are protected by US and international patents, trade dress, and/or copyright laws. Sequel & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2020, BDI | V.08.21.2020 Made in Vietnam.
