fadini COMBI 740 Instruction Manual page 2

MAIN COMPONENTS OF THE BELOW GROUND OIL-HYDRAULIC GATE OPENER
Emergency manual release with
square ferrule, release key and
welding plate
(for hydraulic jacks with hydraulic locking device)
Combi 740 110°
DESCRIPTION OF JACK / MOTOR PUMP COMPONENTS
Flow regulator
(version with Flow
Regulator)
Maximum and minimum pressure valves
in both shaft rotation directions
Hydraulic jack
release lever
Oil reservoir plug
Motor pump oil reservoir
18
Plate with square ferrule
(for hydraulic jacks without hydraulic locking device)
Stainless steel cover (Optional)
Aluminium enclosure
cover
Combi 740 175°
Enclosure
(zinc-coated or stainless steel)
Braking adjustment
(Braking version)
Rotation shaft
Hydraulic jack
Combi
Right or Left Indication
Braking adjustment
(Braking version)
Flow regulator
(version with Flow
Regulator)
Electric power 4x1mm
cable 230V
length 2.50 meters
Gate spacer
hinge
PIC. 1
2
PIC. 2
