Removing the Keyboard
1. Turn off the computer, and turn it over and remove the battery
2. Turn the computer over, open the Lid/LCD, and carefully unsnap up the center cover module
(between F11 & F12) using non-metallic instrument.
3. Lift up the center cover module
4. Remove screws - from the keyboard.
3 7
5. Carefully lift the keyboard
8
6. Disconnect the keyboard ribbon cable
its locking collar socket .
12
7. Remove the keyboard .
8
8. Reverse the process to replace the keyboard (make sure to reconnect the keyboard cable).
a.
1
b.
3 4 5
1
(page 2 -
.
1
up, being careful not to bend the keyboard ribbon cable.
from the locking collar socket
9
c.
2
6 7
5).
from point
1
, and the keyboard LED cable
10
8
9
11
10
12
Disassembly
Figure 7
Keyboard
Removal
2
a. Open the lid/LCD and
unsnap the LED cover
at point 2.
b. Lift the LED cover
module and remove
from
11
the screws from the
keyboard.
c. Disconnect the cables
from the locking collar.
d. Remove the key-
board.
1. Center Cover Mod-
ule
8. Keyboard
• 5 Screws
Removing the Keyboard 2 - 11
