Table 6: Simon XT 1.3 and up Interactive Services Menu
Menu
System Programming +
Installer Code
- Interactive Services
-- LTE Module Status
--- Radio
--- LTE Freq.
--- LTE Band
--- Battery
--- SN
--- SIM card
--- Version
-- Z-Wave Setup 2
--- Number of Z-Wave
Devices 2
--- Add Z-Wave Device 2
--- Remove Z-Wave Device 2
2
--- Z-Wave Home ID
-- Account Creation
1
--Image Sensor Setup
Description
Scroll down to System Programming,
enter the Installer Code and press OK
Scroll up to Interactive Services and press
OK
Scroll down through the various LTE
module information screens
Signal level, connection status, roaming
status, and errors (if any)
LTE frequency used by the module.
By default the module will choose the best
LTE band.
Current battery voltage and AC power
status
Module serial number. Needed to create
or troubleshoot an Alarm.com account.
IMSI number. Sometimes needed to
troubleshoot an account
LTE module firmware version and sub-
version. Example: 4183a, where 4 = XT,
183 = module firmware version, a =
subversion (the label on the module will
say X183)
This menu is used to add, remove, and
troubleshoot Z-Wave devices and
networks. To control Z-Wave devices via
the Alarm.com website and smart phone
apps, you will also need to enable Z-Wave
services on the account.
The total number of Z-Wave devices
currently known to the LTE module.
Press OK to enter Z-Wave Add Mode.
Make sure the device you are trying to add
is powered up and within 3 to 6 feet of the
Simon XT, XTi, or XTi-5 panel. Refer to the
manufacturer's instructions for button
presses required to enroll device.
Press "OK" to remove an existing Z-Wave
device, or to "reset" a Z-Wave device that
was previously learned into a different Z-
Wave network. Previously enrolled
devices must be reset before they can be
enrolled into the module.
Press "OK" to query the Z-Wave network
Home ID. If the ID is 0, verify that the
module has communicated with
Alarm.com and that the Alarm.com
account is set up for Z-Wave.
This menu is available only to installers
who have their own Alarm.com account
creation system. You must enter a
Technician ID and a Lead ID in order to use
this menu.
An Image Sensor daughterboard is
required to enable Image Sensor
capabilities on the module. This menu is
only active if an Image Sensor
daughterboard is connected.
Copyright © 2015 Alarm.com
Simon XT/XTi/XTi-5 LTE Module
--- Learn Image Sensor 1
--- Delete Image Sensor 1
---Image Sensor Settings 1
----Image Sensor #[x] 1
-----[Power Information] 1
-----Signal 1
-----Test PIR 1
-----PIR Sensitivity 1
-- Dealer Logo Update
System Test + Installer Code
- Interactive Services
-- Sensor Reporting Test
-- AVM/LTE Test
-- LTE Module Status
System Test + Master Code
- Interactive Services
-- LTE Module Status
-- Z-Wave Setup
| www.alarm.com | v4.2
| Installation Guide
Press "OK" to enter Add Mode. Enroll the
Image Sensor by inserting batteries or
resetting.
Press "OK" and scroll to the Image Sensor
to delete. Press "OK" to delete.
Press "OK" and scroll to the Image Sensor
of interest. Press "OK".
[x] is the sensor ID. Press "OK" to view
information on this Image Sensor.
Gives information on the Image Sensor's
battery level and power status.
The signal strength of the communication
between the Image Sensor and the Image
Sensor daughterboard.
Press "OK" to put the Image Sensor in PIR
Test Mode.
Press "OK" to view current selection. Scroll
down to view available sensitivity levels.
Press "OK" to select.
This menu is used to upload a Dealer logo
to the two-way talking touchscreen
(2WTTS). (Only available for dealers who
have set up this feature with Alarm.com.)
Press "OK". If a logo is NOT available for
upload to the 2WTTS, you will see "Logo
update not available". If a logo is available,
you will be asked to wait until the panel's
LEDs start flashing, then wait until the
panel's LEDs stop flashing – at which time
the logo should show on the 2WTTS.
Scroll down to System Test, enter the
Installer Code and press OK
Scroll up to Interactive Services and press
OK
This menu is used to automate the process
of confirming that all sensors report
correctly to the Central Station. It will put
the account on test and request the list of
sensors that did not report correctly. It is
available only to installers who have
integrated their sensor testing process
with the Central Station and with
Alarm.com
This menu is used to automate the process
of testing AVM over the LTE link. It is
available only to installers who have
integrated their wireless AVM testing
process with the Central Station and with
Alarm.com
See Installer Programming section above.
Scroll down to System Test, enter the
Master Code and press OK
Scroll up to Interactive Services and press
OK
See Installer Programming section above.
See Installer Programming section above.
