Interlogix Simon XTi Installation Manual

Simon XTi Installation Guide
Content
Contact information .......................................................
Description .....................................................................
Installation......................................................................
Connecting hardwired devices......................................
Wiring phone lines.........................................................
Wiring the power transformer ........................................
Resetting memory to factory defaults ............................
Programming.................................................................
Status & Settings screen...............................................
Sensors ........................................................................
Cleaning the touch screen.............................................
Disposal ........................................................................
Specifications...............................................................
Regulatory information .................................................
Contact information
www.utcfireandsecurity.com
For customer support, see
© 2012 UTC Fire & Security Americas Corporation, Inc.
Interlogix is part of UTC Climate Controls & Security,
a unit of United Technologies Corporation. All rights reserved.
Description
This is the Installation Guide for the Simon XTi system (models
600-1054-95R-12 and 600-1054-95R-12-CN).
Table 1: Sensors and recommended sensor groups
Device Part number
Indoor motion sensor 60-639-95R, 60-807-95
Entry/exit door 60-362N-10-319.5
Interior door 60-362N-10-319.5
Door/Window sensor 60-362N-10-319.5
Smoke sensor TX-6010-01-1
Glassbreak sensor 60-873-95
or www.interlogix.com
www.interlogix.com/customer-support
Recommended
sensor group
b 15, 17, 18, 20, 28, or
32
10
14
13
c 26
13
b
Device
1
4-Button Key fob
1
1 Simon XT Talking Touch
Screen
2
3 Simon XT Talking
Touchpad
4
4
Carbon Monoxide alarm TX-6310-01-1
4
5
a. Not certified as a primary protection circuit for UL-listed systems
and is for supplementary use only.
7
b. Has not been investigated by UL.
9
c. Required for UL-listed residential fire alarm applications.
d. The TWTTS has been verified for use by ETL. Neither this device
9
nor other devices that employ the UTCFS 80 Bit Enhanced
10
Protocol have been investigated for use by UL.
10
Note: These sensor groups are only recommendations. The installer should
choose the correct sensor group for the application.
Caution: Do not use outdoor motion sensors for intrusion
protection.
Installation
Panel location
Locate the panel where alarm sounds can be heard and where
the panel will be easily accessible for operation. Do not install the
panel near a window or door where it can be reached easily by an
intruder.
Part number Recommended
sensor group
600-1064-95R 01
b
60-924-3-XT-2WTTS 00, 01, 04, 05, 06, or
b
60-924-RF-TS 07
d
60-924-3-XT 01
b
, 600- 34
b
6520-95
b
