Summary of Contents for Vello BG-C15-2
- Page 1 BG-C15-2 BATTERY GRIP Designed for the Canon 77D and T7i DSLR Cameras...
- Page 2 Thank you for choosing Vello The Vello BG-C15-2 battery grip offers extended shooting time and comfort when shooting in a vertical (portrait) orientation. The grip is compatible with the Canon 77D and T7i DSLR cameras and accepts up to two Canon LP-E17 rechargeable batteries. It offers an...
- Page 3 Keep out of reach of children. the battery pack, discontinue use immediately. Remove All images are for illustrative purposes only. the batteries, and take the device to a Vello authorized reseller. The battery level may not display properly if batteries...
- Page 4 Overview...
- Page 5 Shutter release button Thumbwheel lock Battery slot 2 latch Handstrap mount Battery compartment latch Control lock switch Tripod socket Battery compartment door Camera battery door holder 2.5 mm remote cable socket Battery slot 1 Power contacts Nonslip grip Battery slot 1 latch Contact cap Mounting screw Battery slot 2...
- Page 6 Re m ove t h e c a m e r a’s Remove the power contact power is turned off. battery chamber door. Pull cap. Slide the chamber door gently at a 45° angle until the into the BG-C15-2’s camera door detaches. battery door holder for safekeeping.
- Page 7 Inser t the battery grip’s Rotate the thumbwheel in Connect the shutter release power contacts into the the direction of the arrow cable from the 2.5 mm camera’s battery chamber, until the grip is secured to remote cable socket on the and attach the grip to the the camera.
-
Page 8: Inserting The Batteries
Inserting the Batteries Turn off the camera’s power, and make sure the Slide the battery compartment latch to the left grip’s control lock switch is in the off position. and open the battery compartment door. - Page 9 Insert the first battery into Turn on the camera power, Note: When removing the grip, slot 1, and push it in until and switch the grip’s control turn off the camera’s power, it clicks secure. Repeat for lock to the on position. switch the grip’s control lock slot 2.
-
Page 10: Specifications
Specifications Up to two Canon LP-E17 type rechargeable Li-ion batteries Power source 32°F to 104°F (0°C to 40°C) Operating temperature 3.8 × 5 × 3 in. (9.8 × 12.7 × 7.6 cm) Dimensions (H × W × D) 7.6 oz. (215 g) without batteries Weight... -
Page 11: One-Year Limited Warranty
ONE-YEAR LIMITED WARRANTY This VELLO product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. - Page 12 www.vellogear.com All other trademarks are the property of their respective owners.
