Vello BG-C20 User Manual

Battery grip
Hide thumbs

Advertisement

Quick Links

Download this manual
BG-C20
BATTERY GRIP
Designed for the
Canon EOS R5, R5 C, R6, and R6 II
Mirrorless Cameras

Advertisement

loading
Need help?

Need help?

Do you have a question about the BG-C20 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vello BG-C20

Summary of Contents for Vello BG-C20

  • Page 1 BG-C20 BATTERY GRIP Designed for the Canon EOS R5, R5 C, R6, and R6 II Mirrorless Cameras...
  • Page 2 Thank you for choosing Vello The Vello BG-C20 battery grip extends the shooting time and grip comfort when using your Canon EOS R5, R5 C, R6 or R6 II mirrorless camera in a vertical (portrait) orientation. This grip accepts up to two Canon LP-E6NH/ E6N rechargeable batteries, and you can charge the batteries in the grip without removing them.
  • Page 3 Precautions The BG-C20 should be used only with the compatible Remove batteries from the grip when not in use. devices specified in this manual. Do not attempt to disassemble. Use only with the batteries and battery holders Avoid exposing this product to water or extreme recommended in this manual.
  • Page 4 Overview 14 15...
  • Page 5 Shutter release button Battery compartment lock Power contacts Multi-function button DC coupler cord hole Power contact cap Main dial Thumbwheel Contacts Camera battery door holder Charge indicator LEDs Contact cap Control lock switch Joystick / select dial Slot 1 lock release Hand-strap mount Magnify / reduce button Battery slot 1...
  • Page 6 Attaching the Battery Grip Ensure that the camera is Slide the chamber door Remove the grip’s two turned off, and remove the into the BG-C20’s camera contact caps. camera’s battery chamber battery door holder until door. Press the door’s latch it clicks.
  • Page 7 Insert the battery grip’s power contacts into the Rotate the thumbwheel in the direction of the camera’s battery chamber and attach the grip arrow until the grip is secured to the camera. to the camera.

  • Page 8: Inserting The Batteries

    Inserting the Batteries Turn off the c amer a’s Twist the battery tray’s lock Canon LP-E6NH or E6N power, and make sure the and remove the battery tray Batteries: Insert the first grip’s control lock switch is from the grip. battery into slot 1 as shown in the Off position.
  • Page 9 Household Power Outlet: Insert and lock the battery Turn on the camera power, T h e C a n o n A C K - E 6 tray inside the battery grip. and switch the grip’s control AC Power Adapter Kit lock to the On position.

  • Page 10: Removing The Batteries

    Removing the Batteries Turn off the c amer a’s Twist the battery tray’s lock Pull the lock release for power, and make sure the and remove the battery tray battery slot 1 or 2 until the grip’s control lock switch is from the grip.

  • Page 11: Specifications

    In-Grip Battery Charging You can charge the batteries inside the grip via the camera’s USB power source. Make sure you turn off the camera to begin charging. For instructions, see your camera’s manual. The charging indicator LEDs will glow green when charging, and turn off when fully charged. If there are two batteries in the grip, slot 1 will charge first.
  • Page 12 To obtain warranty coverage, contact the Vello Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return the defective product to Vello along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk and expense.
