Summary of Contents for Dräger Polytron 8200
- Page 1 Dräger Polytron 8200/8310 Instructions for use WARNING Strictly follow the Instructions for Use. The user must fully understand and strictly observe the instructions. Use the product only for the purposes specified in the Intended use section of this document.
-
Page 3: Table Of Contents
13.1 Dräger Polytron 8200/83X0 ....31 Approvals ........7 13.2... -
Page 4: For Your Safety
Indicates additional information on how to use the Exchanging components may compromise the intrinsic product. safety. This only applies if the device is intrinsically safe. Only operate the product within the framework of a risk- based alarm signalling concept. Dräger Polytron 8200/8310... -
Page 5: Description
3 Enclosure with main electronics (and optional relay) 3 Enclosure with main electronics (and optional relay) 4 Lower part of housing 4 Lower part of housing 5 Sensor 5 Sensor 6 Assembled device 6 Feed through cable 7 e-Box 8 Assembled device Dräger Polytron 8200/8310... -
Page 6: Functional Description
Intended use 2.2.2 Principle of operation of the DrägerSensor IR The Dräger Polytron 8200/8310 is an explosion proof device for continuous monitoring of the concentration of gases and vapors The DrägerSensor IR infrared gas sensor is a gas transmitter containing hydrocarbons. The housing for the device consists... -
Page 7: Intended Operating Area And Operating Conditions
A = 2009, B = 2010, C = 2011, D = 2012, E = 2013, F = 2014, H = 2015, J = 2016, K = 2017 etc. Example: Serial Number ARBH-0054: The third letter is B, i.e. the device was manufactured in 2010. Dräger Polytron 8200/8310... -
Page 8: Restrictions On The Installation
A dust cap can be fitted to the cable entry of the device. This cap is only used for transport purposes and must The openings must be readily accessible to the surrounding be removed before the device is connected to a sealed atmosphere. conduit. Dräger Polytron 8200/8310... -
Page 9: Electrical Installation Without E-Box
2. Lift the handle and remove the enclosure with the main electronics. 3. Connect the device electrically to the protective ground. 4. Rotate the main electronics and disconnect the 5-way plug. 00933300.eps Dräger Polytron 8200/8310... -
Page 10: Electrical Installation With E-Box
A1 relay measurements memory. Terminal 1 Ident. 3.10 Installing software dongles The following SW dongles are available for the Polytron 8200: (NO = Normally open, NC = Normally closed, C = Common) Datalogger dongle Enables the datalogger and the 3.5.3... -
Page 11: Operation
» «. List closed above / complete There are no further functions, menus or sub-menus listed above. List can be scrolled upwards There are further functions, menus or sub-menus listed above. Dräger Polytron 8200/8310... -
Page 12: Activating The Info Mode
Only displayed when the 4-20 mA interface is If an alarm can be acknowledged and is acknowledged, enabled. the LED stops flashing and lights continuously instead until the alarm condition is no longer present. The corresponding relay is deactivated. Dräger Polytron 8200/8310... -
Page 13: Switching To The Quick Menu Mode
LED lights green. The sensor is ready to take measurements. NOTICE The correct date and time settings are important for many functions (see chapter 8.2.3 on page 19). 1 Only displayed when relay is configured. Dräger Polytron 8200/8310... -
Page 14: Calibration
Actual value within the permissible range: Select Next and confirm. Shut off the test gas and remove the calibration adapter from the sensor or disconnect the hose. DSIR 00333299.eps 1 Pressure reducer 2 Calibration adapter 3 Test gas cylinder 4 Hose Dräger Polytron 8200/8310... -
Page 15: Performing Auto Calibration
4. Start the calibration with Next; Back to menu aborts the calibration. NOTICE After 10 minutes, without confirmation the device reverts to measurement mode without performing a calibration. Dräger Polytron 8200/8310... -
Page 16: Menu Overview
Warning interval page 21 Warning current page 21 Maintenance signal page 22 Maintenance current page 22 Analog offset page 22 Set current page 22 Set concentr. page 22 Set fault page 22 Set warning page 22 Set mainten. Dräger Polytron 8200/8310... -
Page 17: Information Menu
Select Information > Instrument > Modules and confirm. A list of all possible modules is displayed. The installed modules are identified by a , those not installed by a Mark a module and request detailed information with Dräger Polytron 8200/8310... -
Page 18: Settings Menu
This configuration results in an alarm being triggered in the event of a loss of power to the transmitter (fail-safe). The fault relay is factory- configured to "Normally energized" and cannot be changed. Dräger Polytron 8200/8310... - Page 19 NOTICE When the function Set fault is exited in the menu, Latching and The alarm must be acknowledged the Polytron 8200/8310 reverts automatically to acknowledgeable manually. The alarm can be measurement mode. acknowledged when the alarm condition is still present.
-
Page 20: Communication Settings
1. Select Settings > Communication > HART interface > Polling address and confirm. 2. Select the address line for the entry and confirm in order to switch to the Change mode. 3. Set the polling address and confirm. 4. Select Confirm and confirm. Dräger Polytron 8200/8310... - Page 21 This function is sets the type of signal used on the analog 4. Select Confirm and confirm. interface for the maintenance signal. 1. Select Settings > Communication > Analog interface > Maint. signal and confirm. 2. Select static or dynamic signal type and confirm. Dräger Polytron 8200/8310...
- Page 22 1. Select Settings > Communication > Analog interface > Set mainten. and confirm. 2. Select On or Off and confirm. The current for the maintenance signal will be transmitted on the analog interface. Dräger Polytron 8200/8310...
-
Page 23: Sensor Settings
Settings menu 8.3.3 Profibus address Information about measurement units The Polytron 8200/8310 represents the measured value in Not yet active - for future functions. various optional units. The following are available: %LEL Sensor settings %LIE %UEG 8.4.1 Switching Auto CAL on or off The Polytron 8000 automatically calculates the correct value. -
Page 24: Datalogger Settings (Only With Data Dongle)
2. To clear the datalogger, select Confirm and confirm. Average The average value of all the concentrations measured within the selected sampling time is stored. Dräger Polytron 8200/8310... -
Page 25: Troubleshooting
Perform new span calibration (see chapter 5.1.2 on page 15). #076 Device fault. Check contacts. #080 - #084 If this fault occurs again: Have the device checked by DrägerService. ® DrägerService is a registered trademark of Dräger. Dräger Polytron 8200/8310... -
Page 26: Warning Reference
Have device checked by DrägerService. #164 Sensor warm-up phase has not ended yet. Wait until the sensor has warmed up. #165 Increased measurement error must be expected. #167 Calibration interval expired. Recalibrate the device (see chapter 5.1 on page 14). #170 Dräger Polytron 8200/8310... -
Page 27: Maintenance
(see chapter 12.1 on page 29). 8. Plug the sensor cable into the socket. 9. Re-fit the sensor electronics and enclosure. 10. Screw the housing cover on again and tighten the set screw. 11. Switch on the power to the device. Dräger Polytron 8200/8310... -
Page 28: Technical Data
2.2 kg (4.9 lbs.) Without e-Box, stainless steel 316 approx. 4.0 kg (8.8 lbs.) With e-Box, aluminum approx. 3.5 kg (7.7 lbs.) With e-Box, stainless steel 316 approx. 5.4 kg (11.9 lbs.) Display Resolution 128 x 64, back-lit Dräger Polytron 8200/8310... -
Page 29: Torques
-40 to +65 °C (-40 to +149 °F) Environmental influences See respective sensor data sheets. 12.1 Torques 12.3 Factory settings (The torques are valid for the aluminum and stainless steel 12.3.1 Alterable settings for the Polytron 8200/8310 316 variants) Standard setting Part Torque Lb. In. Torque Nm Menu DrägerSensor... - Page 30 A2 is not and the gas concentration is so high that A1 and A2 are triggered, an acknowledgement results in the A1 relay dropping out. However the red LED continues to give double flashes as long as the A2 condition exists. Dräger Polytron 8200/8310...
-
Page 31: Order List
Dräger Polytron 8310 Remote e A 4-20/ 45 44 844 HART Relay Dräger Polytron 8200 DD d A 4-20/HART Relay 45 44 440 Dräger Polytron 8310 Remote e S 4-20/HART 45 44 852 Dräger Polytron 8200 DD d S 4-20/HART 45 44 448 Dräger Polytron 8310 Remote e S 4-20/... -
Page 32: Accessories
Order Number Description Name and description Number Bucket Polytron 8200/8310 45 44 788 4-20/HART,SPPT Accessories for Polytron 8200/83X0 Bucket Polytron 8200/8310 D-Junction Box, aluminum 45 44 099 45 44 789 4-20/HART Relay, SPPT D-Junction Box, stainless steel 316 45 44 098... -
Page 33: Declaration Of Conformity
Declaration of Conformity Declaration of Conformity Dräger Polytron 8200/8310... - Page 34 www.norrscope.com...
