AIR CONDITIONER
AR12TVFCAWKNAP
AR18TVFCBWKNAP
AR24TVFCAWKNAP
AR12TVEAAWKXAP
AR12TVFCAWKXAP
AR12TVEAAWKNAP
AR18TVEAAWKNAP
AR24TVEAAWKNAP
AR18TVEAAWKXAP
AR24TVEAAWKXAP
AR18TVFCBWKXAP
AR24TVFCAWKXAP
SPLIT-TYPE AIRCONDITIONER
INDOOR UNIT
MODEL CODE
AR12TVEAAWKNAP
AR18TVEAAWKNAP
AR24TVEAAWKNAP
AR12TVFCAWKNAP
AR18TVFCBWKNAP
AR24TVFCAWKNAP
CONTENTS
1. Precautions
2. Pr
cations
3. Alignment and Adjustments
4. Disassembly and Reassembly
5. ASSY CONTROL
6. Electrical Parts List
7. Wiring Diagram
8. PCB Diagram
9. Operating Instructions
10. Troubleshooting
11.Block Diagram
12. Reference Sheet
OUTDOOR UNIT
AR12TVEAAWKXAP
AR18TVEAAWKXAP
AR24TVEAAWKXAP
AR12TVFCAWKXAP
AR18TVFCBWKXAP
AR24TVFCAWKXAP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AR12TVEAAWKNAP and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung AR12TVEAAWKNAP

Summary of Contents for Samsung AR12TVEAAWKNAP

  • Page 1 SPLIT-TYPE AIRCONDITIONER INDOOR UNIT OUTDOOR UNIT MODEL CODE AR12TVEAAWKNAP AR12TVEAAWKXAP AR18TVEAAWKNAP AR18TVEAAWKXAP AR24TVEAAWKNAP AR24TVEAAWKXAP AR12TVFCAWKNAP AR12TVFCAWKXAP AR18TVFCBWKNAP AR18TVFCBWKXAP AR24TVFCAWKNAP AR24TVFCAWKXAP AIR CONDITIONER CONTENTS 1. Precautions 2. Pr cations 3. Alignment and Adjustments AR12TVEAAWKNAP AR12TVFCAWKNAP AR18TVEAAWKNAP AR18TVFCBWKNAP 4. Disassembly and Reassembly...

  • Page 2: Table Of Contents

    Contents 1. Precautions 1-1 Installing the air conditioner 1-2 Power supply and circuit breaker 1-3 During operation 1-4 Disposing of the unit 1-4 Others 2. Product Specications 2-1 The Feature of Product 2-2 Product Specifications 2-3 The comparative specifications of product 2-4 Accessory and option specifications 3.
  • Page 3 Contents 9. Operating Instructions 9-1 Name of Each Part 9-2 Wireless Remote Control-Buttons and Display 10. Troubleshootin 10-1 Items to be checked First 10-2 Communication Error 10-2-1 Communication Error 10-2-2 Indoor temperature sensor Error 10-2-3 Indoor fan motor speed detecting error (BLDC fan) 10-2-4 Outdoor temperature sensor error 10-2-5 Outdoor Cond temperature sensor error 10-2-6 Outdoor Discharge temperature sensor error...

  • Page 4: Precautions

    1. Precautions 1-1 Installing the air conditioner • Uses should not install the air conditioner by themselves. Ask the dealer or authorized company to install the air conditioner except window-type air conditioner in U.S.A and Canada. • If you don't install the air conditioner properly, it may cause a fire, a water leakage or an electric shock. • You must install the air conditioner according to the national wiring regulations and safety regulations.

  • Page 5: Disposing Of The Unit

    1-4 Disposing of the unit • Before the throwing out the air conditioner, remove the batteries from the remote control. • When you dispose of the air conditioner, consult your dealer. If pipes are removed incorrectly, refrigerant may blow out and cause air pollution. When it contacts with your skin, it can cause skin injury. • The package of the air conditioner should be recycled or disposed of properly for environmental reasons.

  • Page 6: Product Specications

    2. Product Specications 2-1 The Feature of Product • Fast cooling If you want the strong and cool air, just select Fast function! It will get you the strongest air! • Wind-Free Cooling Use the Wind-Free Cooling function to enjoy a mild breeze coming through fine holes in the Wind-Free panel instead of air coming directly through the air flow blades.

  • Page 7: Product Specifications

    2-2 Product specification Model AR12TVEAAWK/AP AR18TVEAAWK/AP AR24TVEAAWK/AP Rating Mode Unit Wall-mounted Wall-mounted Wall-mounted T1 Cool 11500 18000 22000 Capacity T3 Cool Heat T1 Cool 1020 1460 1944 Power Input T3 Cool Heat T1 Cool Current T3 Cool Heat (3.3) 12.33 (3.61) 11.32 (3.32) Efficiency Dehumidifying...
  • Page 8 2-2 Product specification Model AR12TVFCAWK/AP AR18TVFCBWK/AP AR24TVFCAWK/AP Rating Mode Unit Wall-mounted Wall-mounted Wall-mounted T1 Cool 11500 18000 21000 Capacity T3 Cool Heat T1 Cool 1020 1460 1900 Power Input T3 Cool Heat T1 Cool Current T3 Cool Heat (3.3) 12.33 (3.61) 11.05 (3.24) Efficiency Dehumidifying...

  • Page 9: The Comparative Specifications Of Product

    2-3 The comparative specification of product DEVELOPMENT MODEL Model AR12TVEAAWK/AP AR18TVEAAWK/AP AR24TVEAAWK/AP Indoor Unit Design Outdoor Unit Indoor Unit 11.5 11.7 Net Weight Outdoor Unit 25.1 38.1 41.2 Indoor Unit 820*299*215 1055*299*215 1055*299*215 Net Dimension Outdoor Unit 720*548*265 880*638*310 880*638*310 Indoor Unit Noise Outdoor Unit...

  • Page 10: Accessory And Option Specifications

    2-4 Accessory and Option Specifications Item Descriptions Code No. Q’ty Remark DB90-11453A ASSY HANGER (Q1, QF1) DB90-11454A ASSY HANGER (Q3) DB96-24901F ASSY WIRELESS REMOCON DB68-08593A MANUAL USER Indoor unit case DB68-08649A (AR**TVCA**) MANUAL USER DB68-08650A (AR**TVFC**) DB68-08808A MANUAL INSTALL Batteries for Remote controller 4301-000121 M4 x 12 Tapped Screws 6002-000213...

  • Page 11: Alignment And Adjustments

    3. Alignment and Adjustments 3-1 Test Mode How to Approach Test Mode You can approach the test mode by pressing the on/off switch of indoor unit for 5 seconds. Test mode operation option After installing the air conditioner, check whether each subordinate is normally operated or not by operating the test mode.

  • Page 12: Display Error And Check Method

    3-2 Display Error and Check Method 3-2-1 Indoor Display Error and Check Mathod ERROR MODE TYPE DESCRIPTION INDOOR/ 7-SEG OUTDOOR C101, C102 Communication error C108 Set address error C121 Room TH sensor error C122, C123 INDOOR MID, INDOOR IN EVA-TH sensor error C140 Dust sensor error C142...
  • Page 13 3-2 Display Error and Check Method 3-2-2 Outdoor Display Error and Check Mathod ERROR MODE DESCRIPTION 7-SEG Power off /VDD NG Power on reset (1sec) Normal operation Abnormal communication (Indoor <-> Outdoor) IPM over current (O.C) error C464 Comp. strating error C461 EEPROM data error (no data) C470...

  • Page 14: Setting Option Setup Method

    3-3 Setting Option Setup Method Ex) Option No. : Step 1 Enter the Option Setup mode. 1. Tack out the batteries of remote control. 2. Press the temperature button simultaneously and insert the battery again. 3. Make sure the remote control display shown as Step 2 Enter the Options Setup mode and select your options asscording to the following procedure.
  • Page 15 Method Display Press the button to set Dry mode. Setting option SEG5 Press the button the display panel to. … Press the button repeatedly to select. Setting option SEG6 Press the button the display panel to. … Press the button repeatedly to select. Press the button to set Fan mode.
  • Page 16 Method Display Press the button to set Auto mode. Setting option SEG11 Press the button the display panel to … Press the button repeatedly to select . Setting option SEG12 Press the button the display panel to … Press the button repeatedly to select.
  • Page 17 Method Display Press the button to set Fan mode. Setting option SEG17 Press the button the display panel to … Press the button repeatedly to select . Setting option SEG18 Press the button the display panel to … Press the button repeatedly to select .

  • Page 18: Disassembly And Reassembly

    4. Disassembly and Reassembly Necessary Tools Item Remark +SCREW DRIVER Q’ty 1 ea. To assembly and disassembly the screw MONKEY SPANNER Q’ty 1 ea. To assembly and disassembly the Fan motor and Compressor - SCREW DRIVER Q’ty 1 ea. To assembly and disassembly the screw...

  • Page 19: Indoor Unit

    4-1. Indoor Unit Parts Procedure Remark PANEL-FRONT 1) Stop the driving of air conditioner and shut off main power supply. 2) Detach FILTER PRE from the PANEL FRONT. 3) The COVER PANEL is fixed to body by hooks in center and side area. 4) Separate the hook pulling end of the COVER PANEL as shown in figures.(Watch out for the damage of hooks)
  • Page 20 Parts Procedure Remark PANEL-FRONT Caution: Assembly of Cover Panel after service end. - Piping and Drain Hose must be caseful not to damage and progress must be done with both hands. - Need to check all bottom hooks in holes of the main frame before you push to assemble.
  • Page 21 Parts Procedure Remark PANEL-FRONT 5) The GRILLE INLET is fixed to body by hooks in the center and side area. 6) Separate the hook pulling end of the GRILLE INLET as shown in figures.(Watch out for the damage of hooks) 7) To detach the PANEL FRONT from the main frame, unfasten 2 screws at the bottom.
  • Page 22 Parts Procedure Remark PANEL-FRONT 9)Raise the PANEL FRONT upward as shown in the figure to separate the 3 hooks. CONTROL-IN 10)To open the CONTROL-IN, raise the side flanges of the PLATE-RIGHT at an angle and un- lock 2 hooks. 11)To detach the CONTROLIN, unfasten a screw back of the PLATE-LEFT as shown in figures. (use (+) Screw Driver)
  • Page 23 Parts Procedure Remark CONTROL-IN 12)Separate Fan Moter wire as shown in figures. Caution: When you separate the connec- tor, pull pressing the locking button. 13)Separate Blade Moter wire as shown in figures. Caution: When you separate the connec- tor, pull pressing the locking button. 14)Cut off the Cable Tie tied up wires.
  • Page 24 Parts Procedure Remark CONTORL IN 15)Unfasten a screw of the Ground wire and pick up Temperature wires from ASSY EVAP. (Use (+) Screw Driver.) 16) The CONTROL-IN is fixed to HOLER PIPE by a hook bottom of the case as shown in the last figure. (Please loosen remaining connectors before detaching CASECONTROL.
  • Page 25 Parts Procedure Remark TRAY DRAIN 18) To detach the TRAY DRAIN from the main frame, pull the bottom of the TRAY DRAIN and it leans toward to you as shown in figures. 19) Pull out the Drain Hose.
  • Page 26 Parts Procedure Remark EVAPORATOR 20) The HOLDER PIPE is fixed to body by 2 hooks as shown in the figure. 21) To detach the HOLDER PIPE from the main frame,loosen 2 hook structhres. When separate hooks: Use the (-) Screw Driver. Insert the (-) Screw Driver into the gap of the hook and lean to the Moter side as shown in figures. (Watch out for...
  • Page 27 Parts Procedure Remark EVAPORATOR 25) Pull up the EVAPORATOR of the opposite side of the Fan Moter 26) loosen a hook of the Fan Moter side. 27) Pull up the EVAPORATOR to- ward to you.
  • Page 28 Parts Procedure Remark FAN MOTOR 28) Unfasten a screw on the & COVER MOTER. CROSS FAN (Use (+) Screw Driver.) 29) Unwind the Moter Wire. 30)Detach the COVER MOTER. 31) Unfasten a screw of the CROSS FAN a little. (Use (+) Screw Driver.) 32)Raise up the CROSS FAN of the left side and pull out from the Moter.

  • Page 29: Outdoor Unit

    4-3. Outdoor Unit (N-WW, SI) AR12TVEAAWKXAP AR12TVFCAWKXAP Parts Procedure Remark Common work 1) Loosen each screws and detach the cabi Top cover. 2) Loosen screws of the cabi front and detach it.
  • Page 30 Parts Procedure Remark 3) Remove the 4 Cond Bar from the holder of outdoor unit cabinet. * This process is supported by heating models only 4) Loosen ing screws from the Cabi Front Lh and detach it. 5) Loosen ng screws from the Cabi Side Rh and detach it.
  • Page 31 Parts Procedure Remark 1) Detach the Nut Flange like the & picture on the right side. Motor (Turn clockwise because the screw is left-handed.) (Use Monkey Spanner.) 2) Detach the Fan Propeller. 3) Loosen 4 fixing screws to detach the Motor. (Use Monkey Spanner.) 4) Disconnect the wire between Ass’y Control Out and Motor.
  • Page 32 Parts Procedure Remark Assy 1) To remove the Cover control box : Control Out Pull the motor wire is allow sufficientspace as shown on the right side and then remove the screw. 2) Detach several connectors from the Assy Control Out. 3) Detach several connectors from the PCB of Assy Control Out.
  • Page 33 Parts Procedure Remark Compressor 1) Loosen the ng nut and detach the Compressor Lead Wire. (Use Monkey Spanner.) 2) Loosen the bolts at the bottom of Compressor like the picture on the right side. (Use Monkey Spanner.)
  • Page 34 4-4. Outdoor Unit (Q-480) AR18TVEAAWKXAP AR18TVFCBWKXAP AR24TVEAAWKXAP AR24TVFCAWKXAP Parts Procedure Remark COMMON 1) Loosen fixing screws from the WORK cabi side Rh and detach it. 2) L oosen each sc rews and detach the Cabi Top Cover. 3) Loosen fixing screws from the cabi side. 4) Loosen fixing screws from the cabi side Rh and detach it.
  • Page 35 Parts Procedure Remark COMMON 5) Loosen fixing screws from the WORK cabi front and detach it. 6) L oosen fixing screws from the Cabi left and detach it and Remove the 4 Cond Bar from the holderof outdoor unit cabinet.
  • Page 36 Parts Procedure Remark 1) Detach the Nut Flange like the & picture on the right side. Motor (Turn clockwise because the screw is left-handed.) (Use Monkey Spanner.) 2) Detach the Fan Propeller. 3) Loosen 4 fixing screws to detach the Motor. (Use Monkey Spanner.) 4) Disconnect the wire between Assy Control Out and Motor.
  • Page 37 Parts Procedure Remark Assy 1) To remove the Cover control box : Control Out Pull the motor wire is allow sufficient space as shown on the right side and then remove the screw. 2) Detach several connectors from the Assy Control Out. 3) Detach several connectors from the PCB of Assy Control Out.
  • Page 38 Parts Procedure Remark Compressor 1) Loosen the ng nut and detach the Compressor Lead Wire. (Use Monkey Spanner.) 2) Loosen the bolts at the bottom of Compressor like the picture on the right side. (Use Monkey Spanner.)

  • Page 39: Assy Control

    5. ASSY CONTROL 5-1 ASSY KIT CODE DB92-04845G,W,X NAME CODE unit CASE CONTROL-IN DB61-07432A PLATE CONTROL-LF DB61-07431A PLATE CONTROL-LOW DB61-07428A PLATE CONTROL-UP DB61-07429A PLATE CONTROL-SUB DB61-07427A HOLDER-WIRE DB61-05871A SCREW-TAPPING 6002-001163 SCREW-TAPPING 6002-000213 SCREW-SPECIAL 6009-001001 CABLE TIE 6501-001075 TERMINAL BLOCK_4P_GLOBAL DB37-00033A ASSY PCB DISPLAY_88_WIFI DB92-04833B ASSY PCB DISPLAY_88_External WIFI...

  • Page 40: Assy Kit Code Db92-04849G

    5-2 ASSY KIT CODE DB92-04849G NAME CODE Q'ty unit ASSY-THERMAL GREASE 0205-000178 0.002 SCREW-MACHINE (TB) 6001-000722 SCREW-TAPPING (CLAMP 6002-000234 4EA) SCREW-TAPPING (CLAMP 6002-000239 2EA, CASE 1EA) SCREW-TAPPING (PBA) 6002-000630 SCREW-TAPPING (EARTH) 6009-001001 ASSY-SCREW MACHINE DB91-00933A (H/S??) HOLDER-WIRE CLAMP DB61-00250A CASE CONTROL LOW (WW, DB61-06722A SI,Q-480) COVER CONTROL OUT...

  • Page 41: Electrical Parts List

    6. Electrical Parts List 6-1 INDOOR MAIN PCB CODE DB92-04839B Parts Code Design Loc Parts Description Spec. Quantity Unit 0201-001528 COATING ADHESIVE-SIL LDC2577D,Y/GRN,175CPS 0201-001982 ADHESIVE-SIL ADHESIVE-SIL TSE3854DS-W,White,2.2,MIL-A-46146B,UL94V-0 0.0035 0202-001463 SOLDER-WIRE SOLDER-WIRE LFC2-W3.0,D3,99.79Sn/0.2Cu/0.01P,No Flux SOLDER-WIRE 0202-001608 SOLDER-WIRE FLUX LFC7-107,D0.8,99.3Sn/0.7Cu/0.01P,Flux 3.5% FLUX 0204-005794 SOLVENT SOLVENT...
  • Page 42 Parts Code Design Loc Parts Description Spec. Quantity Unit 2401-001573 CE107 C-AL 47uF,20%,50V,GP,TP,6.3x11mm,2.5mm 2401-001573 CE123 C-AL 47uF,20%,50V,GP,TP,6.3x11mm,2.5mm 2401-001573 CE902 C-AL 47uF,20%,50V,GP,TP,6.3x11mm,2.5mm 2401-001838 CE105 C-AL 470uF,20%,25V,WT,TP,10x16mm,5mm 2401-003607 CE106 C-AL 10uF,20%,50V,HR,TP,5x11mm,5mm MAIN,QMD RAC AR9500T,142x121mm,Y,220V- DB94-08039A ASSY PCB SMD 240V,5V,12V,17V,10W,PF1-RAC,485 INV,DLX,DB92- 04839A AC85-265V,500mA,400mA,400mA,5V,12V,15V,S/W DC26-00053A TRAN101 TRANS SWITCHING...

  • Page 43: Assy Pcb Display Code Db92-04833B

    6-2 ASSY PCB DISPLAY CODE DB92-04833B Parts Code Design Loc Parts Description Spec. Quantity Unit 0201-001528 COATING ADHESIVE-SIL LDC2577D,Y/GRN,175CPS DB61-07412A CASE-LED CASE-LED AR9500T, QMD RAC,HIPS,T1.8,L69,BLACK,8.8 WINDOW DIS- DB64-03476A WINDOW DISPLAY AR9500T, QMD RAC,PET,T0.27,8.8 FILM, AI, Timer, Wi-Fi PLAY DB94-08137A ASSY PCB SMD DISPLAY_DLX,QMD RAC AR9500T,84.5x50mm,N,WIFI,DB92-04833B 0202-001933 SOLDER-CREAM...
  • Page 44 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121...
  • Page 45 2203-007544 C-CER,CHIP 100nF,10%,50V,X7R,TP,1005,T0.5 2203-007544 C-CER,CHIP 100nF,10%,50V,X7R,TP,1005,T0.5 2203-008315 C102 C-CER,CHIP 22000nF,20%,25V,X5R,TP,2012,T1.25 2203-008315 C103 C-CER,CHIP 22000nF,20%,25V,X5R,TP,2012,T1.25 2402-001268 C-AL,SMD 100uF,20%,25V,WT,TP,8x6.3mm 2402-001268 C-AL,SMD 100uF,20%,25V,WT,TP,8x6.3mm 3404-001222 SWITCH-TACT 12VDC,50mA,160gf,6x6x5.0mm,SPST HEADER-BOARD TO 3711-005477 BOX,4P,1R,2.0mm,SMD-A,SN,WHT,12x7.7x5.15mm CABLE 3711-007975 CNS100 CONNECTOR-HEADER BOX,10P,1R,1.25mm,SMD-A,SN,BLK,17.45x5.7x3.55mm HEADER-BOARD TO 3711-008640 BOX,15P,1R,2.0mm,SMD-A,SN,WHT,34x9.2x5.15mm CABLE CWAM210S,RAC,IEEE802.11,2.4GHz,ARTIK 051,5V, 4709-002815 IC100 W-LAN MODULE 12V,UART,SISO,40.0x15.0x3.9mm,-20to+70C...

  • Page 46: Assy Pcb Display Code Db92-04833C

    6-3 ASSY PCB DISPLAY CODE DB92-04833C Parts Code Design Loc Parts Description Spec. Quantity Unit 0201-001528 COATING ADHESIVE-SIL LDC2577D,Y/GRN,175CPS DB61-07412A CASE-LED CASE-LED AR9500T, QMD RAC,HIPS,T1.8,L69,BLACK,8.8 WINDOW DIS- DB64-03476A WINDOW DISPLAY AR9500T, QMD RAC,PET,T0.27,8.8 FILM, AI, Timer, Wi-Fi PLAY DB94-08165A ASSY PCB SMD DISPLAY_DLX,QMD RAC AR9500T,84.5x50mm,EXTERNAL WIFI,DB92-04833C 0202-001933 SOLDER-CREAM...
  • Page 47 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121 R-CHIP 680ohm,5%,1/4W,TP,3216 2007-001121...
  • Page 48 2203-007456 C-CER,CHIP 1000nF,10%,25V,X5R,TP,1005,T0.5 2203-007544 C-CER,CHIP 100nF,10%,50V,X7R,TP,1005,T0.5 2203-007544 C-CER,CHIP 100nF,10%,50V,X7R,TP,1005,T0.5 2203-008315 C102 C-CER,CHIP 22000nF,20%,25V,X5R,TP,2012,T1.25 2203-008315 C103 C-CER,CHIP 22000nF,20%,25V,X5R,TP,2012,T1.25 2402-001268 C-AL,SMD 100uF,20%,25V,WT,TP,8x6.3mm 2402-001268 C-AL,SMD 100uF,20%,25V,WT,TP,8x6.3mm 3404-001222 SWITCH-TACT 12VDC,50mA,160gf,6x6x5.0mm,SPST HEADER-BOARD TO 3711-005477 BOX,4P,1R,2.0mm,SMD-A,SN,WHT,12x7.7x5.15mm CABLE HEADER-BOARD TO 3711-008640 BOX,15P,1R,2.0mm,SMD-A,SN,WHT,34x9.2x5.15mm CABLE DB41-01436A PCB DISPLAY PCB DISPLAY FR-4,2L,T1.6,84.5x50mm,8,QMD RAC DISPLAY DLX,1Oz,194x242mm...

  • Page 49: Wiring Diagram

    7. Wiring Diagram 7-1 Indoor Unit CODE : DB68-08680A-01...

  • Page 50: Outdoor Unit

    7-2 Outdoor Unit CODE : DB68-08682A-01...

  • Page 51: Pcb Diagram

    8. PCB Diagram 8-1 INdoor Main PCB CODE DB92-04839B DLX_QMD_Indoor Main PCB : DB92-04839A-E CN810 CN800 CN320 CN801 CN100 CN390 CN340 CN900 CNP100 CN230 CN100 : DISPLAY CN230 : DOWNLOAD CN340 : WIRED REMOCON #1 : LED_DIO #1 : COM1_RXD #1 : COM2_Tx #2 : +5V #2 : COM1_TXD...

  • Page 52: Outdoor Main Pcb Code Db92-04837A-E

    8-2 Outdoor Main PCB CODE DB92-04837A-E FP#2_20S_QMD_Out Door Main PCB : DB92-04837A-E CN700 CN380 CPN901 CN810 CN470 CN210 CN551 CN320 CN300 CNP402 CNP004 CNP052 CNP031 CNP051 CNP001 CNP003 CNP002 CN320 : SUB CPN901 : BLDC FAN CN810 : EEV-A CN470 : SENSOR CN700 : HEATER #1 : +5V_1 #1 : DC_LINK...

  • Page 53: Display Pcb Db92-04833B

    8-3 DISPLAY PCB DB92-04833B,C...

  • Page 54: Wire Connecting The Indoor Unit Terminal Blocks

    8-4 Wire connecting the indoor unit terminal blocks 1. Terminal press of Ring terminal shall be set facing up before connecting wire. 2. There shall be no empty space between Ring terminal and Screw after Clamp. If not, there exists a possibility of fire which can be caused by electric heat in the connecting part.

  • Page 55: Operating Instructions

    9. Operating Instructions 9-1 Name of Each Part 9-1-1 Indoor Unit The design and shape are subject to change according to the model. - Main Parts 01 Air intake 06 Airflow blade (left and right 02 Air filter 07 Power button/Remote control receiver 03 Tri-care filter (For AR**T*EA*** models) 08 Room temperature sensor 04 Wind-Free panel 09 Display 05 Airflow blade (up and down)
  • Page 56 - Display 01 Temperature indicator (numeric) Filter reset indicator ( ) Electricity consumption indicator (numeric) Auto clean indicator ( ) 02 AI Auto indicator 03 Timer indicator good’sleep indicator 03 04 04 Wi-Fi indicator 01 Temperature indicator (numeric) Filter reset indicator ( ) Electricity consumption indicator (numeric) Auto clean indicator ( ) 02 AI Auto indicator...

  • Page 57: Wireless Remote Control-Buttons And Display

    9-2 Wireless Remote control-Buttons and Display DB96-24901F Set temperature indicator Timer option indicator Operation mode indicator Options indicator Low battery indicator Transmit indicator Fan speed indicator Wind-Free indicator Vertical air swing indicator Horizontal air swing indicator Power button Temperature button Timer button Fan speed button Direction button / Selection button...

  • Page 58: Troubleshootin

    10. Troubleshooting 10-1 Items to be checked first The input voltage should be rating voltage ±10% range.The air conditioner may not operate properly if the voltage is out of this range. Is the line cable linking the indoor unit and the outdoor unit linked properly? The indoor unit and the outdoor unit shall be linked by 5 cables.

  • Page 59: Communication Error

    10-2 Communication Error 10-2-1 Communication Error Indoor display 7-SEG DISPLAY DESCRIPTION C101/C102 Communication error(Indoor<->outdoor) Outdoor display 1min. Time out Comm. Abnormal Communication LED OFF LED ON LED BLINKING 1. Checklist : 1) Is the cable between the indoor unit and outdoor unit connected correctly? 2) Isn’t the power cable and communication cable cross? 2.

  • Page 60: Indoor Temperature Sensor Error

    10-2-2 Indoor temperature sensor Error Indoor display 7-SEG DISPLAY DESCRIPTION C121 Indoor room temp sensor error LED OFF LED ON LED BLINKING 1. Checklist : 1) Is the indoor units temperature sensor connected correctly? 2) Is the sensor placed correctly? 3) Does the both terminal of sensor satisfy the resistance value in accordance with temperature? 2.

  • Page 61: Indoor Fan Motor Speed Detecting Error (Bldc Fan)

    10-2-3 Indoor fan motor speed detecting error (BLDC fan) Indoor display 7-SEG DISPLAY DESCRIPTION C154 Indoor fan error LED OFF LED ON LED BLINKING 1. Checklist : 1) Is the indoor units fan motor properly connected with the connector(CN72)? 2) Is the AC voltage correct? 2.

  • Page 62: Outdoor Temperature Sensor Error

    10-2-4 Outdoor temperature sensor error Indoor display 7-SEG DISPLAY DESCRIPTION C221 Outdoor temperature sensor error Outdoor display Outdoor temperature sensor error LED OFF LED ON LED BLINKING 1. Checklist : 1) Is the sensor connected correctly? 2) Is the sensor placed correctly? 3) Does the both terminal of sensor satisfy the resistance value in accordance with temperature? 4) Is the resistance value of sensor connection pull-up correct? Model...

  • Page 63: Outdoor Cond Temperature Sensor Error

    10-2-5 Outdoor Cond temperature sensor error Indoor display 7-SEG DISPLAY DESCRIPTION C231 Outdoor Cond temperature sensor error Outdoor display Outdoor Cond temperature sensor error LED OFF LED ON LED BLINKING 1. Checklist : 1) Is the sensor connected correctly? 2) Is the sensor placed correctly? 3) Does the both terminal of sensor satisfy the resistance value in accordance with temperature? 4) Is the resistance value of sensor connection pull-up correct? 2.

  • Page 64: Outdoor Discharge Temperature Sensor Error

    10-2-6 Outdoor Discharge temperature sensor error Indoor display 7-SEG DISPLAY DESCRIPTION C251 Outdoor Discharge temperature sensor error Outdoor display Outdoor Discharge temperature sensor error LED OFF LED ON LED BLINKING 1. Checklist : 1) Is the sensor connected correctly? 2) Is the sensor placed correctly? 3) Does the both terminal of sensor satisfy the resistance value in accordance with temperature? 4) Is the resistance value of sensor connection pull-up correct? 2.

  • Page 65: Operation Condition Secession Error

    10-2-7 Operation condition secession error Indoor display 7-SEG DISPLAY DESCRIPTION C440 Prohibit Operation Condition Error (Heating) C441 Prohibit Operation Condition Error (Cooling) Outdoor display Operation condition secession LED OFF LED ON LED BLINKING 1. Checklist : 1) Check the temperature around the outdoor unit. 2.

  • Page 66: Eeprom Error/Otp Error

    10-2-8 EEPROM error / OTP error Indoor display 7-SEG DISPLAY DESCRIPTION C470 EEPROM Data Error (no data) OTP errorEEPROM Data Error C471 (Main Micom Inv Micom) Outdoor display EEPROM Data Error (no data) OTP errorEEPROM Data Error (Main MicomInv Micom) LED OFF LED ON LED BLINKING...

  • Page 67: Outdoor Fan Motor Error

    10-2-9 Outdoor Fan motor error Indoor display 7-SEG DISPLAY DESCRIPTION C458 Outdoor fan error Outdoor display Outdoor fan error LED OFF LED ON LED BLINKING 1. Checklist : 1) Are the input power voltage and the power connection correct? 2) Is the motor wire connected to the outdoor PBA correctly? 3) Is there no assembly error or non-assembly in the terminal of motor wire connector? 4) Is there no obstacle at the surrounding of motor and propeller? 2.

  • Page 68: Compressor Starting Error

    10-2-10 Compressor starting error Indoor display 7-SEG DISPLAY DESCRIPTION C461 Comp starting error Outdoor display Comp starting error LED OFF LED ON LED BLINKING 1. Checklist : 1) Is the connection of cable for the compressor? 2) Is the compressor wire is connected clockwise? U(RED)-V(BLU)-W(YEL) 3) Is the interphase resistance of compressor normal? 2.

  • Page 69: Compressor Wire Missing Error/Rotation Error

    10-2-11 Compressor wire missing error/rotation error Indoor display 7-SEG DISPLAY DESCRIPTION C467 Compressor wire missing errorr/rotation error Outdoor display Compressor wire missing error/rotation error LED OFF LED ON LED BLINKING 1. Checklist : 1) Is the connection of cable for the compressor? 2) Is the compressor wire is connected clockwise? U(RED)-V(BLU)-W(YEL) 3) Is the interphase resistance of compressor normal? 2.

  • Page 70: Current Sensor Error/Input Current Sensor Error

    10-2-12 Current sensor error/Input current sensor error Indoor display 7-SEG DISPLAY DESCRIPTION C462 AC Input I_Limit Trip Error Outdoor display Current sensor error Input current sensor error LED OFF LED ON LED BLINKING 1. Checklist : 1) Is the PFC Shunt(“A”) resistance value correct? Check the resistor is opened 2) Is the IPM Shunt(“B”) resistance value correct? Check the resistor is opened 3) Is there no short or open around “C”? 2.

  • Page 71: Over Current) Error

    10-2-13 O.C(Over Current) error Indoor display 7-SEG DISPLAY DESCRIPTION C464 IPM Over Current(O.C) Error Outdoor display Current sensor error LED OFF LED ON LED BLINKING 1. Checklist : 1) Is the IPM Shunt resistance value correct? Check the resistor is opened 2) Is the condition of surrounding temperature abnormal overload? 3) Is there any problem as like the temperature sensor separation or measurement value error? 4) Is the interphase resistance of compressor normal?
  • Page 72 Is the position of Correct the sensor position or temperature sensor and sensing exchange the sensor value normal? Is the compressor body Exchange the Outdoor PBA and interphase resistance insulated? Exchange the compressor...

  • Page 73: No Power Outdoor (Initial Diagnosis) (Not Displayed)

    10-2-14 No power outdoor (Initial Diagnosis) (Not displayed) 1. Checklist : 1) Is input power normal? 2) Is AC power linked correctly? (L,N,E) 3) Is mis-wiring between communication wire and Power wire? 4) Is mis-wiring between Main PBA and SMPS PBA wire? 5) Is input voltage of SMPS AC in Main PBA (CN150) normal? 6) Is the voltage of SMPS DC in Main PBA (CN151,CN152) normal? 2.

  • Page 74: When The Up/Down, Left/Right, Grill Louver Motor Does Not Operate

    10-2-15 When the Up/Down, Left/Right, Grill louver motor does not operate (Initial Diagnosis) (Not displayed) 1. Checklist : 1) Is the input power voltage normal? 2) Is the Up/Down louver motor properly connected with the connector? (CN61, CN62, CN63) 2. Troubleshooting procedure Unplug the power cord and plug it after 30seconds later.

  • Page 75: When The Remote Control Is Not Receiving

    10-2-16 When the remote control is not receiving 1. Checklist : 1) Check if the connector was normally assembled. 2) Check the battery in remote control 3) All the lights out and check again : Change electronic typed to a rescent light 4) Put the set in operation and check the voltage of display PBA 5) Replace the display PBA 2.

  • Page 76: Smart Install Error

    10-2-17 Smart Install error 1. Checklist : 1) Check the leakage region.(Use leakage detection liquid or soapy water) 2) When leakage region is found from service valve and piping connection re nut part : After the related measures to check the refrigerant supplements and operation. 3) If the leakage region is pipe welding part : Weld leakage region after refrigerant gas release.(Brass parts should only apply) 4) If the leakage region is surface area (Heat exchanger or pipe welding region is not) : Replace parts.

  • Page 77: Outdoor Olp Over Temperature Error (One Way Inverter Only)

    10-2-18 Outdoor OLP over temperature error (One way Inverter Only) Indoor display DESCRIPTION No display about the outdoor condition Outdoor display C463 IPM Over Current(O.C) Error LED OFF LED ON LED BLINKING 1. Checklist : 1) Is the sensor placed correctly? 2) Check the service valve is closed 3) Check the compressor locking or gas leak 2.

  • Page 78: Block Diagram

    11. Block Diagram 11-1 Indoor unit [INDOOR] WIRED REMOCON MAIN PBA OUT MODULE MICOM(TMPM3HPFDFG) SENSOR CAP ZERO ROOM SENSOR WiFi MODULE(OPTION) EMI FILTER HUMIDITY SENSOR DISPLAY EVA SENSOR REMOCON RECEIVER BLDC MOTOR DETECT SENSOR SMPS DETECT DC LOAD CONTROL MAIN DC POER (15V,12V,5V) STEP MOTOR(H/V) 485 COMM.

  • Page 79: Outdoor Unit

    11-2 Outdoor unit MAIN BLOCK INVERTER BLOCK SENSOR EEV1 DOWNLOAD MAIN CURRENT INVERTER MICOM SENSING UART COMM MICOM 4WAY V/V COMPRESSOR SMPS DRED HEATER SPEED OTN OPTION HIGH-PRESSURE INDOOR EEPROM 485 COMM SWITCH CURRENT CAPACITOR SENSING POWER PFCM FILTER RAC ONLY...
  • Page 80 11-2-1 Pre-inspection Notices Check if you pulled out the AC power plug when you eliminate the PCB or front panel. Don’t hold the PCB side not impose excessive force on it to eliminate the PCB. Don’t pull the lead wire but hold the whole housing to connect or disconnect a connector to the PCB. In case of outdoor PCB disassembly, check first the complete discharge of condenser after 1 minute power off.
  • Page 81 11-2-4 Outdoor detailed inspection procedure Procedure Inspection Method Cause Plug out and pull the PCB out of 1) Is 1st fuse disconnected? • Over current the control box. Check the PCB fuse • AC part and pattern short of (Wait 3 minutes after power off) Outdoor PBA 1) Is the Compressor wire connected clockwise? • Wrong assembly...

  • Page 82: Reference Sheet

    12. Reference Sheet 12-1 Low Refrigerant Pressure Distribution Note : Please measure the refrigerant pressure after the air conditioner operates on testing cooling mode during more than 10 minutes. ■ Indoor Temp. Variation : 20°C ~ 32°C ■ Outdoor Temp. Variation : -5°C ~ 45°C Indoor Temperature Outdoor Temperature[ ] 12-2 Pressure &...

  • Page 83: Q & A For Non-Trouble

    It occurs when the drain pump is plugged out or it is out of order. Check the power of the drain pump and the position of the drain hose, and when the pump is faulty, contact the drain pump manufacturer. Samsung Electronics do not manufacture drain pumps. So, we are not able to correct the drain pump problems.
  • Page 84 Classication Class Description Smells Whenever the air conditioner is turned on, it stinks. When are no components in the air conditioner sending out chemical smells. But, when the air condi- tioner is turned on, other smell sources are sucked into the air conditioner and get out of it. So, find and root out the smell sources. Generally, when the drain hose is taken out to the washing room or there are sources of smells such as a diaper bin, a shoe shelf or a socks bin, bad smells generate.
  • Page 85 There is a cost table. But, our service engineer needs to visit to total up the cost correctly. When you move in, make sure to contact Samsung Electronics Service Center or Authorized Service Agent in advance to streamline the process.

  • Page 86: Cleaning /Filter Change

    12-4 Cleaning /Filter Change Auto clean function Use the Auto clean function if the indoor unit produces odors. Activating Auto clean To activate Auto clean, press the (Options) button for at least 3 seconds. The indoor unit display shows: Canceling Auto clean To cancel Auto clean while it is running, follow the procedure below: ▶...
  • Page 87 Cleaning the outside of the indoor unit 1 Turn off the air conditioner and wait until the fan stops. 2 Disconnect the power supply. 3 Use a soft brush or tepid damp cloth to clean the exterior. WARNING • Do not clean the appliance by spraying water directly onto it. Soft brush Water entering the unit may result in electric shock or fire that could cause death, serious injury, or property damage:...

  • Page 88: Installation

    12-5 Installation 12-5-1 Before Installation Keep the air conditioner outlet and inlet free from its surroundings.In case of installation, keep the symmetry and fix it to prevent vibration. The pipe length shall meet the standard as far as possible. 12-5-2 Installation Procedure ■ Location Install the product in an area to guarantee the best cooling eect, convenience of piping and elec- tric work, and inexistence of vibration or wind.

  • Page 89: Installation Diagram Of Indoor Unit And Outdoor Unit

    12-6 Installation Diagram of Indoor Unit and Outdoor Unit 12-6-1 Air-Purge Procedure 1) Connect each assembly pipe to the appropriate valve on Indoor unit Outdoor unit the outdoo Gas pipe side Liquid pipe side 2) Connect the charging hose of low pressure side of manifold gauge to the packed valve having a service port (3/8"...
  • Page 90 12-6-2 "Pump down" Procedure Pump down will be carried out when an evaporator is replaced or when the unit is relocated in another area. 1) Remove the caps from the 3 way valve and the 3 way valve. 2) Turn the 3 way valve clockwise to close and 3 way Valve connect a pressure gauge (low pressure side) to the service valve, and open the 3 way valve...
  • Page 91 Maintenance Procedures If vacuuming is not possible, make a manifold so that Performing the gas leak tests for repair refrigerant can be easily removed from the parts of the In case of repair of the refrigerant circuit, the following procedure system.

  • Page 92: Reference Sheet

    12-7. Reference Sheet Index for Model Name 10th 11th 12th 13th 14th Project Capacity Sell Feature Series Color Unit Export Item Item Reference Item Item Export 19 Year INVERTER HP R32 Export 20 Year INVERTER CO R32 Export 21 Year INVERTER HP R410 Export 22 Year...
  • Page 93 China http://gspn2.samsungcsportal.com Asia Middleeast & Africa http://gspn1.samsungcsportal.com This Service Manual is a property of Samsung Electronics Co., © Samsung Electronics Co., Ltd. Ltd. Any unauthorized use of Manual can be punished under November 2019 applicable International and/or domestic law.

This manual is also suitable for:

Ar18tveaawknapAr24tveaawknapAr12tvfcawknapAr18tvfcbwknapAr24tvfcawknapAr12tveaawkxap ... Show all
