- Page 1 Air conditioner Installation manual AR**TSFA*** / AR**TSFY*** Thank you for purchasing this Samsung air conditioner. Before operating this unit, please read this user manual carefully and retain it for future reference.
-
Page 2: Table Of Contents
Contents Safety Information Safety Information Installation Preparation Step 1-1 Viewing the typical installation Step 1-2 Verifying model numbers Step 1-3 Choosing the installation location Step 1-4 Unpacking Step 1-5 Preparing materials and tools Indoor Unit Installation Step 2-1 Attaching the mounting bracket to the wall Step 2-2 Drilling the wall penetration Step 2-3 Connecting the refrigerant pipes Step 2-4 Connecting the power and communication cables... -
Page 3: Safety Information
Safety Information WARNING: Read This Manual Read and follow all safety information and instructions before installation, use, or maintenance of this appliance. Incorrect installation, use, or maintenance of this appliance can result in death, serious injury, or property damage. Keep these instructions with this appliance. This manual is subject to change. For the latest version, visit www.samsunghvac.com. - Page 4 Safety Information Safety Information Notices and notes To make you aware of safety messages and highlighted information, we use the following notices and notes throughout this manual: WARNING Hazards or unsafe practices that may result in severe personal injury or death. CAUTION Hazards or unsafe practices that may result in minor personal injury or property damage.
-
Page 5: Installation
General information The air conditioner should be used only for the applications for which it has been designed: the indoor unit is not suitable to be installed in areas used for laundry. Installation of the product Our units must be installed in compliance with the spaces indicated in the installation manual to ensure either accessibility from both sides or ability to perform routine maintenance and repairs. -
Page 6: Preparation
Preparation Preparation Step 1-1 Viewing the typical installation A typical installation will be similar to the one shown below. Evaporator/ fancoil (indoor) Maximum pipe height Refrigerant lines, electric, and drain Make at least one round to reduce noise and vibration. Maximum pipe length Compressor/ condenser... -
Page 7: Step 1-2 Verifying Model Numbers
Step 1-2 Verifying model numbers Check the model numbers on the boxes to make sure that the indoor and outdoor units are compatible with each other. For compatible units, see the model’s submittal document, listed on page 3. Nominal capacity (BTU/hour) Indoor unit model number Outdoor unit model number 9000... -
Page 8: Step 1-3 Choosing The Installation Location
Preparation Step 1-3 Choosing the installation Indoor unit location requirements location WARNING If using a multi system, install as described in the Do not install the unit in a humid, oily, or dusty location installation manual supplied with the outdoor unit. or in a location exposed to direct sunlight, water, or rain. - Page 9 Minimum clearances for the indoor unit CAUTION Do not connect the drain hose to existing waste pipes Ceiling as odors may arise. 4 inch Wall Installation on an exterior wall (100 mm) 5 inch 5 inch If the outdoor unit must be installed on an exterior wall, you (125 mm) (125 mm) will need an L-bracket to support the unit.
- Page 10 Minimum clearances for the outdoor unit Check the installation site every 3 months and Legends: perform anti-corrosion treatment such as R-Pro supplied by SAMSUNG (Code : MOK-220SA) or Wall commercial water repellent grease and wax, etc., based on the product condition.
-
Page 11: Step 1-4 Unpacking
Upon receipt, inspect the product to verify that it has not been Unit: inch (mm) damaged during transport. If the product appears damaged, do not install it and immediately report the damage to your local Samsung distributor. Packing material must be disposed of in accordance with local regulations. 23.6 118.11... -
Page 12: Step 1-5 Preparing Materials And Tools
Preparation Step 1-5 Preparing materials and tools If using a multi system, install as described in the installation manual supplied with the outdoor unit. Materials in the indoor unit package Optional accessories Make sure that the indoor unit package contains the following materials: For information on the accessories that are available for each model, see the submittal documents listed on page 3. - Page 13 Make sure that the line set is longer than is needed to #2 Phillips-bit driver for cordless drill reach from the indoor to the outdoor unit, to allow for Phillips screw driver bends and final connections. For more on pipe lengths, see Slotted screw driver Step 1-1 Viewing the typical installation on page 6.
-
Page 14: Indoor Unit Installation
Indoor Unit Installation Step 2-1 Attaching the mounting Step 2-2 Drilling the wall penetration bracket to the wall Determine the position of the hole through which the piping bundle (consisting of power and communication Hold the mounting bracket against the wall at the cables, refrigerant pipes, and the drain hose) will pass. -
Page 15: Step 2-3 Connecting The Refrigerant Pipes
Use a standard 2-5-inch (65-mm) hole saw to drill one IMPORTANT hole at the selected location, at a 15° downward angle so When installing the unit, always connect the that the drain hose will drain properly. refrigerant pipes first, followed by the electrical cables. For disassembly, always disassemble the electric cables before the refrigerant pipes. -
Page 16: Step 2-4 Connecting The Power And Communication Cables
Indoor Unit Installation Tape over the end of the pipes so that debris will not enter NOTE the piping when it is passed through the wall. The pipes If you are using the right rear exit, the pipes should be will be insulated later in the installation process. -
Page 17: Step 2-5 Optional: Extending The Power Cable
rubber and wire of the power cable. CAUTION Peel off 0.79inch (20 mm) of cable shields from the Connect the wires firmly so that wires cannot be pulled pre-installed tube. out. Loose wires can cause the connection to overheat. CAUTION Each circular terminal must match the size of its corresponding screw in the terminal block. -
Page 18: Step 2-6 Connecting The Drain Hose
Indoor Unit Installation Using a crimping tool, compress the two points and flip it CAUTION over and compress another two points in the same location. Make sure that the connection parts are not exposed The compression dimension should be 8.0. to outside. -
Page 19: Step 2-7 Taping The Pipes, Cables, And Drain Hose
Do not box in or cover the drain hose connection. It must CAUTION be accessible for testing later in the installation process and for future servicing. Be careful not to puncture the plug with the screwdriver when installing it. If the drain hose is routed inside the room, insulate the hose so that dripping condensation does not damage the If using the left, right, or bottom exit, pass the drain hose furniture or floors. -
Page 20: Outdoor Unit Installation
Outdoor Unit Installation Outdoor Unit Installation Level the unit, then use anchor bolts to secure it at the If using a multi system,install as described in the four mounting points. installation manual supplied with the outdoor unit. For installations in locations that require seismic or hurricane tie downs, comply with local codes. -
Page 21: Step 3-2 Connecting The Cables And The Pipes
Step 3-2 Connecting the cables and the Remove the cover panel on the unit. pipes Route the piping bundle to the outdoor unit. Use piping clamps to fasten the piping bundle to the foundation or wall. Cut the refrigerant pipes to the length needed to reach the pipe connections (located behind the cover panel;... -
Page 22: Installation Inspection And Testing
Installation Inspection and Testing Installation Inspection and Testing Step 4-1 Performing a drain leak test Step 4-2 Performing pressure tests using nitrogen Pour water into the drain pan. Install the red high-side hose of an R-410A-gauge manifold set to the larger liquid/vapor line’s service port. Attach a pressure regulator to a tank of dry nitrogen. -
Page 23: Step 4-3 Evacuating The System
Step 4-3 Evacuating the system 12 Reconnect the common hose to the vacuum pump. Repeat steps 6 through 12, alternating between breaking the vacuum with dry nitrogen and evacuating, until CAUTION system evacuation has occurred three times, to the following vacuum levels: Because the system does not have filter driers, you must perform this triple evacuation procedure to Evacution... -
Page 24: Step 4-4 Adding Refrigerant (If Needed)
Installation Inspection and Testing Step 4-4 Adding refrigerant (if needed) Step 4-6 Commissioning the unit The outdoor unit is charged with sufficient R-410A refrigerant to The unit is commissioned using the Smart Install feature. support up to a 24.6-ft line set. For lengths greater than 24.6 ft, Smart Install can be started only with the remote control. -
Page 25: Step 4-7 Performing Final Checks And Trial Operation
Electric wiring connection WARNING Heat-resistant insulation of the pipe Drainage Stop the unit, disconnect the power, and contact Samsung technical support if any of the following occurs: Grounding conductor connection The unit produces a burning smell or smoke. Correct operation (Take the following steps.) The power cable is hot or damaged. - Page 26 Installation Inspection and Testing In Heat mode, use the Temperature button to set Check whether, approximately 3 to 5 minutes later, the outdoor unit starts, and a cool or warm air blows out. After 12 minutes of stationary condition, check the 1 minute indoor unit air treatment.
-
Page 27: Sub Pcb Installation(Optional)
Sub PCB installation(optional) (Wired remote controller, central remote controller etc.) Find the PCB wire, and connect the wire to the Sub PCB as seen in the picture. Turn the power off and take off the cover panel of the indoor unit. Connect the wire(remote controller, central remote controller etc) to the Sub PCB.
