Samsung AR Series Technical Data Book

Rac for europe nordic (inv, r32, 50hz, hp)
Hide thumbs Also See for AR Series:
Table of Contents

Advertisement

Quick Links

RAC
Technical
Data Book
RAC for Europe Nordic
(INV, R32, 50Hz, HP)
Model : AR**TX***WKNEE (Indoor Unit)
AR**TX***WKXEE (Outdoor Unit)

Advertisement

Table of Contents
loading

Related Manuals for Samsung AR Series

Summary of Contents for Samsung AR Series

  • Page 1 Technical Data Book RAC for Europe Nordic (INV, R32, 50Hz, HP) Model : AR**TX***WKNEE (Indoor Unit) AR**TX***WKXEE (Outdoor Unit)
  • Page 2 History Version Modification Date Remark Released AR9500T RAC TDB for Europe Nordic 20.05.29 Ver.1.0...
  • Page 3 Nomenclature Model Name Buyer (1) Classification (6) Design Segment Wind-Free GEO Wind-Free AIRISE AIRISE (2) Capacity x1000 Btu/h (7) Version A-Z (1 digit) (3) Year 2020 (8) Color DA White (4) Product Type INVERTER HP R32 (9) Set Indoor Unit (5) Characteristics Outdoor Unit Motion Detect Sensor +Wi-Fi +...

  • Page 4: Indoor Unit

    Line-up Indoor Unit Model Type Design Image Wind-Free AR9500 AR5500 AR4500 AIRISE Capacity (kW) Model Type Design Wind-Free AR9500 ● ● ● ● AR5500 ● ● AR4500 AIRISE...

  • Page 5: Outdoor Unit

    Line-up Outdoor Unit Capacity (kW) Model Type Design Wind-Free AR9500 AR5500 AR4500 AIRISE...
  • Page 6 Contents 1. Specification 2 Capacity Table 3. Dimensional Drawing 4. Center of Gravity 5. Electrical Wiring Diagram 6. Sound Data 7. Temperature and air flow distribution 8. Piping Diagram 9. Operation Limit 10. Capacity Correction 11. Installation...

  • Page 7: Specification

    1. Specification 1. Specification AR4500 Model Name Indoor Unit AR09TXFZBWKNEE AR12TXFZBWKNEE Outdoor Unit AR09TXFZBWKXEE AR12TXFZBWKXEE Mode HEAT PUMP HEAT PUMP Performance 900 / 2,500 / 3,400 900 / 3,500 / 4,400 Cooling Capacity Btu/h 3,071 / 8,530 / 11,601 3,071 / 11,942 / 15,013 (Min/Std/Max) 700 / 3,200 / 6,500 700 / 4,000 / 6,800...
  • Page 8 1. Specification AR4500 Model Name Indoor Unit AR09TXFZBWKNEE AR12TXFZBWKNEE Outdoor Unit AR09TXFZBWKXEE AR12TXFZBWKXEE Infrared remote control Included Included Control MWR-WE13N MWR-WE13N System MWR-WG00JN MWR-WG00JN Wired remote control MWR-WG00KN MWR-WG00KN MWR-SH11N MWR-SH11N Drain Pump Drain Pump Indoor Max. lifting Height / Displacement ㎜...
  • Page 9 1. Specification AR5500 Model Name Indoor Unit AR09TXFYBWKNEE AR12TXFYBWKNEE Outdoor Unit AR09TXFYBWKXEE AR12TXFYBWKXEE Mode HEAT PUMP HEAT PUMP 900 / 2,500 / 3,500 900 / 3500 / 4600 Performance Cooling Capacity Btu/h 3,071 / 8,530 / 11,942 3071 / 11942 / 15696 (Min/Std/Max) 800 / 3,200 / 7,000 800 / 4000 / 7200...
  • Page 10 1. Specification AR5500 Model Name Indoor Unit AR09TXFYBWKNEE AR12TXFYBWKNEE Outdoor Unit AR09TXFYBWKXEE AR12TXFYBWKXEE Infrared remote control Included Included Control MWR-WE13N MWR-WE13N System MWR-WG00JN MWR-WG00JN Wired remote control MWR-WG00KN MWR-WG00KN MWR-SH11N MWR-SH11N Drain Pump Drain Pump Indoor Max. lifting Height / Displacement ㎜...
  • Page 11 1. Specification AR9500 Model Name Indoor Unit AR09TXCACWKNEE AR12TXCACWKNEE Outdoor Unit AR09TXCACWKXEE AR12TXCACWKXEE Mode HEAT PUMP HEAT PUMP 900 / 2500 / 3600 900 / 3500 / 4800 Performance Cooling Capacity Btu/h 3071 / 8530 / 12284 3071 / 11942 / 16378 (Min/Std/Max) 800 / 3200 / 7100 800 / 4000 / 7300...
  • Page 12 1. Specification AR9500 Model Name Indoor Unit AR09TXCACWKNEE AR12TXCACWKNEE Outdoor Unit AR09TXCACWKXEE AR12TXCACWKXEE Infrared remote control Included Included Control MWR-WE13N MWR-WE13N System MWR-WG00JN MWR-WG00JN Wired remote control MWR-WG00KN MWR-WG00KN MWR-SH11N MWR-SH11N Drain Pump Drain Pump Indoor Max. lifting Height / Displacement ㎜...

  • Page 13: Capacity Table

    2 Capacity Table AR4500 AR09TXFZBWKNEE+AR09TXFZBWKXEE Cooling TC : Total Capacity, SHC : Sensible Heat Capacity, PI : Power Input Indoor Temperature (℃, DB / WB) Outdoor 20 / 14 22 / 16 25 / 18 27 / 19 28 / 20 30 / 22 32 / 24 Temp.
  • Page 14 2 Capacity Table AR4500 AR12TXFZBWKNEE+AR12TXFZBWKXEE Cooling TC : Total Capacity, SHC : Sensible Heat Capacity, PI : Power Input Indoor Temperature (℃, DB / WB) Outdoor 20 / 14 22 / 16 25 / 18 27 / 19 28 / 20 30 / 22 32 / 24 Temp.
  • Page 15 2 Capacity Table AR5500 AR09TXFYBWKNEE+AR09TXFYBWKXEE Cooling TC : Total Capacity, SHC : Sensible Heat Capacity, PI : Power Input Indoor Temperature (℃, DB / WB) Outdoor 20 / 14 22 / 16 25 / 18 27 / 19 28 / 20 30 / 22 32 / 24 Temp.
  • Page 16 2 Capacity Table AR5500 AR12TXFYBWKNEE+AR12TXFYBWKXEE Cooling TC : Total Capacity, SHC : Sensible Heat Capacity, PI : Power Input Indoor Temperature (℃, DB / WB) Outdoor 20 / 14 22 / 16 25 / 18 27 / 19 28 / 20 30 / 22 32 / 24 Temp.
  • Page 17 2 Capacity Table AR9500 AR09TXCACWKNEE+AR09TXCACWKXEE Cooling TC : Total Capacity, SHC : Sensible Heat Capacity, PI : Power Input Indoor Temperature (℃, DB / WB) Outdoor 20 / 14 22 / 16 25 / 18 27 / 19 28 / 20 30 / 22 32 / 24 Temp.
  • Page 18 2 Capacity Table AR9500 AR12TXCACWKNEE+AR12TXCACWKXEE Cooling TC : Total Capacity, SHC : Sensible Heat Capacity, PI : Power Input Indoor Temperature (℃, DB / WB) Outdoor 20 / 14 22 / 16 25 / 18 27 / 19 28 / 20 30 / 22 32 / 24 Temp.

  • Page 19: Dimensional Drawing

    3. Dimensional Drawing Indoor units AR4500 : AR09TXFZBWKNEE, AR12TXFZBWKNEE Unit: mm (inches) [8-7/16] 820.0 [32-5/16] 48.3 [1-7/8] 820.0 [32-5/16] 422.3 [16-5/8] 397.7 [15-11/16] 397.0 [15-5/8] 176.0 [6-15/16] 84.0 [3-5/16] 64.0 [2-1/2] 64.0 [2-1/2]...
  • Page 20 3. Dimensional Drawing Indoor units AR5500 : AR09TXFYBWKNEE, AR12TXFYBWKNEE AR9500 : AR09TXCACWKNEE, AR12TXCACWKNEE Unit: mm (inches) 889.0 [35] [8-7/16] 48.3 [1-7/8] 889.0 [35] 466.6 422.4 [16-5/8] 397.0 [15-5/8] 245.0 [9-5/8] 64.0 [2-1/2] 64.0 [2-1/2] 84.0 [3-5/16]...

  • Page 21: Outdoor Units

    3. Dimensional Drawing Outdoor units AR4500 : AR09TXFZBWKXEE, AR12TXFZBWKXEE AR5500 : AR09TXFYBWKXEE, AR12TXFYBWKXEE AR9500 : AR09TXCACWKXEE, AR12TXCACWKXEE Unit: mm (inches) [31 1/8] 601.7 88.7 [3 1/2] [23 11/16] 2- 50.0 [1 15/16] [11 1/4] 509.0 [20 1/16]...

  • Page 22: Center Of Gravity

    4. Center of Gravity Indoor units AR4500 : AR09TXFZBWKNEE, AR12TXFZBWKNEE Unit: mm (inches) 889.0 [35] 406.5 [16] 106.8 [4-3/16] 215.0 [8-1/2] AR5500 : AR09TXFYBWKNEE, AR12TXFYBWKNEE AR9500 : AR09TXCACWKNEE, AR12TXCACWKNEE Unit: mm (inches) 1054.5 [41-1/2] 479.3 [18-7/8] 100.8 [3-15/16] 215.0 [8-1/2]...
  • Page 23 4. Center of Gravity Outdoor units AR4500 : AR09TXFZBWKXEE, AR12TXFZBWKXEE AR5500 : AR09TXFYBWKXEE, AR12TXFYBWKXEE AR9500 : AR09TXCACWKXEE, AR12TXCACWKXEE Unit: mm (inches) [6 1/8] [7 7/16]...

  • Page 24: Electrical Wiring Diagram

    5. Electrical Wiring Diagram Indoor units Printed circuit MOTION SENSOR SENSOR(MOTION) DISPLAY DUST SNESOR SENSOR(DUST) board(DISPLAY BOARD) Thermistor(Room Motor(BLDC FAN ROOM TH BLDC HVPS LOAD(HOVP MODULE) Temp._10Kohm) MOTOR) Thermistor(EVA MID EVA MID - TH UP/DOWN STEP MOTOR1 Motor(STEP MOTOR) WIFI MODULE LOAD(WIFI MODULE) Temp._10Kohm) Thermistor(EVA IN...
  • Page 25 5. Electrical Wiring Diagram Outdoor units DRED Printed circuit board(DRED PCB) DIS-TH Thermistor(Discharge Temp._200Kohm) REACTOR REACTOR OUT-TH Thermistor(AmbientTemp._10Kohm) EEPROM Printed circuit board(EEPROM PCB) COND-TH Thermistor(Cond Out Temp._10Kohm) COMP COMPRESSOR BLDC Motor(BLDC FAN Motor) HEATER Printed circuit board(HEATER PCB) EEV-A Electronic expansion valve A 4-WAY VALVE 4-WAY VALVE NOTE...

  • Page 26: Sound Data

    6. Sound Data 6. Sound Data Indoor units Sound Pressure level Unit: dB(A) Cooling Model High Silent AR09TXFZBWKNEE AR12TXFZBWKNEE AR09TXFYBWKNEE Microphone AR12TXFYBWKNEE • NR Curve 2) AR12TXFZBWKNEE 1) AR09TXFZBWKNEE 3) AR09TXFYBWKNEE 4) AR12TXFYBWKNEE NOTE • Specifications may be subject to change without prior notice. •...
  • Page 27 6. Sound Data Indoor units Sound Pressure level Unit: dB(A) Cooling Model High Silent AR09TXCACWKNEE AR12TXCACWKNEE Microphone • NR Curve 2) AR12TXCACWKNEE 1) AR09TXCACWKNEE NOTE • Specifications may be subject to change without prior notice. • Sound pressure Level - Sound pressure level is obtained in an anechoic room. - Sound pressure level is a relative value, depending on the distance and acoustic environment.
  • Page 28 6. Sound Data Outdoor units Sound Pressure level Unit: dB(A) Model Cooling AR09TXFZBWKXEE Microphone AR12TXFZBWKXEE AR09TXFYBWKXEE AR12TXFYBWKXEE Front • NR Curve 2) AR12TXFZBWKXEE 1) AR09TXFZBWKXEE 3) AR09TXFYBWKXEE 4) AR12TXFYBWKXEE NOTE • Specifications may be subject to change without prior notice. •...
  • Page 29 6. Sound Data Outdoor units Sound Pressure level Unit: dB(A) Model Cooling AR09TXCACWKXEE Microphone AR12TXCACWKXEE Front • NR Curve 2) AR12TXCACWKXEE 1) AR09TXCACWKXEE NOTE • Specifications may be subject to change without prior notice. • Sound pressure Level - Sound pressure level is obtained in an anechoic room. - Sound pressure level is a relative value, depending on the distance and acoustic environment.
  • Page 30 6. Sound Data Indoor units Sound Power level Unit: dB(A) NOTE Model Cooling AR09TXFZBWKNEE • Specifications may be subject to change without prior notice. AR12TXFZBWKNEE - Sound power level is an absolute value that a AR09TXFYBWKNEE sound source generates. AR12TXFYBWKNEE - dBA = A-weighted sound power level.

  • Page 31: Sound Power Level

    6. Sound Data Indoor units Sound Power level Unit: dB(A) NOTE Model Cooling AR09TXCACWKNEE • Specifications may be subject to change without prior notice. AR12TXCACWKNEE - Sound power level is an absolute value that a sound source generates. - dBA = A-weighted sound power level. - Reference power : 1pW.
  • Page 32 6. Sound Data Outdoor units Sound Power level Unit: dB(A) NOTE Model Cooling AR09TXFZBWKXEE • Specifications may be subject to change without prior notice. AR12TXFZBWKXEE - Sound power level is an absolute value that a AR09TXFYBWKXEE sound source generates. AR12TXFYBWKXEE - dBA = A-weighted sound power level.
  • Page 33 6. Sound Data Outdoor units Sound Power level Unit: dB(A) NOTE Model Cooling AR09TXCACWKXEE • Specifications may be subject to change without prior notice. AR12TXCACWKXEE - Sound power level is an absolute value that a sound source generates. - dBA = A-weighted sound power level. - Reference power : 1pW.

  • Page 34: Temperature And Air Flow Distribution

    7. Temperature and air flow distribution AR4500 AR09TXFZBWKNEE • Cooling air velocity distribution • Cooling Temperature distribution (Discharge angle : 20 degree) (Discharge angle : 20 degree) • Heating air velocity distribution • Heating Temperature distribution (Discharge angle : 30 degree) (Discharge angle : 30 degree) AR12TXFZBWKNEE •...
  • Page 35 7. Temperature and air flow distribution AR5500 AR09TXFYBWKNEE • Cooling air velocity distribution • Cooling Temperature distribution (Discharge angle : 20 degree) (Discharge angle : 20 degree) • Heating air velocity distribution • Heating Temperature distribution (Discharge angle : 30 degree) (Discharge angle : 30 degree) AR12TXFYBWKNEE •...
  • Page 36 7. Temperature and air flow distribution AR9500 AR09TXCACWKNEE • Cooling air velocity distribution • Cooling Temperature distribution (Discharge angle : 20 degree) (Discharge angle : 20 degree) • Heating air velocity distribution • Heating Temperature distribution (Discharge angle : 30 degree) (Discharge angle : 30 degree) AR12TXCACWKNEE •...

  • Page 37: Piping Diagram

    8. Piping Diagram 8. Piping Diagram AJ026MCJ3EC/SP OUTDOOR UNIT INDOOR UNIT Thermistor - Thermistor- IDU Heat Exchager Mid Heat (T_IM) Exchanger (T_II) Service Valve- Heat Exchanger - Gas Pipe Indoor unit (SV_G) (HX_ID) Outdoor Fan Motor (OFM) Indoor Thermistor- Fan Motor Indoor Room (IFM) Electronic...

  • Page 38: Operation Limit

    9. Operation Limit 9. Operation Limit Cooling Heating Warming Operation Range Operation Range Operation Range Indoor Temperature (℃ DB) Indoor Temperature (℃ DB)

  • Page 39: Capacity Correction

    10. Capacity Correction 10. Capacity Correction Outdoor units Cooling Pipe Length (m) 12.5 0.96 0.94 0.91 0.99 0.97 0.95 0.92 0.98 0.96 0.93 0.99 0.97 0.95 0.92 0.96 0.94 0.91 Heating Pipe Length (m) 12.5 0.96 0.94 0.91 0.99 0.97 0.95 0.92 0.98...

  • Page 40: Installation

    ※ In case you want more information about the controllers and accessories, please refer to the Controller and Accessory TDB on pvi.Samsung.com site or Global Partner Portal site.
  • Page 41 • For the product that uses the R-32 refrigerant, Install the indoor unit on the wall 1.8 m or higher from the floor. ※ In case you want more information about the controllers and accessories, please refer to the Controller and Accessory TDB on pvi.Samsung.com site or Global Partner Portal site.

  • Page 42: Choosing The Installation Location

    125 mm 125 mm ※ In case you want more information about the controllers and accessories, please refer to the Controller and Accessory TDB on pvi.Samsung.com site or Global Partner Portal site.
  • Page 43 ※ In case you want more information about the controllers and accessories, please refer to the Controller and Accessory TDB on pvi.Samsung.com site or Global Partner Portal site.
  • Page 44 Wall Minimum clearance in mm Air flow direction Top view Side view ※ In case you want more information about the controllers and accessories, please refer to the Controller and Accessory TDB on pvi.Samsung.com site or Global Partner Portal site.
  • Page 45 ※ In case you want more information about the controllers and accessories, please refer to the Controller and Accessory TDB on pvi.Samsung.com site or Global Partner Portal site.

  • Page 46: Connecting The Power And Communication Cables

    Correct Correct Upside Non-fitted (Front view) (Side view) down <Circular terminal> ※ In case you want more information about the controllers and accessories, please refer to the Controller and Accessory TDB on pvi.Samsung.com site or Global Partner Portal site.
  • Page 47 CENELEC: H05RN-F, IEC: 60227 IEC53: H05VV-F) • Power & Communication cable shall not exceed 30 m. ※ In case you want more information about the controllers and accessories, please refer to the Controller and Accessory TDB on pvi.Samsung.com site or Global Partner Portal site.

  • Page 48: Outdoor Unit Installation

    ※ In case you want more information about the controllers and accessories, please refer to the Controller and Accessory TDB on pvi.Samsung.com site or Global Partner Portal site.
  • Page 49 5 For installations in locations that require seismic or hurricane tie downs, comply with local codes. ※ In case you want more information about the controllers and accessories, please refer to the Controller and Accessory TDB on pvi.Samsung.com site or Global Partner Portal site.
  • Page 50 Indoor unit Outdoor unit Unit tCO₂e ①, a ②, b ①+②, c ※ In case you want more information about the controllers and accessories, please refer to the Controller and Accessory TDB on pvi.Samsung.com site or Global Partner Portal site.
  • Page 51 2020. 05 Ver. 1.0 Samsung Electronics Co., LTD. Head Office (Suwon Korea) 129, Samsung-Ro, Yeongtong-Gu, Suwon City, Gyeonggi-Do, Korea 16677 Website : www.samsung.com, https://partnerhub.samsung.com Email : airconditioner@samsung.com Images and data in this book may subject to change without prior notice.
