AIR CONDITIONER
AR07CXCAAWKNEU
AR09CXCAAWKNEU
AR12CXCAAWKNEU
AR09TXCAAWKXEU
AR12TXCAAWKXEU
SPLIT-TYPE AIRCONDITIONER
INDOOR UNIT
AR07CXCAAWKNEU
MODEL CODE
AR09CXCAAWKNEU
AR12CXCAAWKNEU
CONTENTS
1. Precautions
2. Product Specifications
3. Alignment and Adjustments
4. Disassembly and Reassembly
5. ASSY CONTROL
6. Wiring Diagram
7. PCB Diagram
8. Operating Instructions
9. Troubleshooting
10.Block Diagram
11. Reference Sheet
OUTDOOR UNIT
-
AR09TXCAAWKXEU
AR12TXCAAWKXEU
