Pre-Flight - GeoCue True View 410 Hardware User's Manual

True View 410 Hardware User Guide

2. PRE-FLIGHT

1. Ready the drone for flight and insert the battery into the True View unit (Figure 31).
2. Lift all antennas up and tighten the nut (Figure 32) on the True View antenna.
3. Place the drone in an open area where you intend to takeoff. True View will need an
unobstructed view of the sky. Avoid placing the drone near large metal objects such as
buildings or vehicles to avoid signal disturbance.
4. Insert the USB drive.
23
Figure 31 – Insert True View Battery
Figure 32 – True View Antenna
True View 410 Hardware User Guide 8/3/2020
