TRUE VIEW 410 UNIVERSAL MASS STORAGE (UMS)

The True View UMS (universal mass storage) device is the media attached to the True View sensor on
which A True View Cycle will be written during flight operations and system wind-down.
The UMS should meet the following requirements to be used on the system.
1. USB-C connection
2. FAT32 format for firmware pre v2.0.3, or NTFS after updating firmware to v2.0.3 or later
3. 114 GB minimum capacity
4. Need "SystemConfiguration.json" and "CoreConfiguration.json" files on the drive during
operation.

SYSTEM CONFIGURATION FILE (SCF)

The System Configuration file (SCF), SystemConfiguration.json, must reside on the True View 410
Universal Mass Storage and is copied into the Cycle\System folder upon creation of each Cycle. The
SCF contains information on the calibration parameters of all components for each True View system
and is used by True View EVO to process True View data. The latest calibration file for each sensor is
stored on the True View Reckon portal.

CORE CONFIGURATION FILE

True View System settings are stored internally to the system, but can be changed by modifying the
CoreConfiguration.json file on the UMS. The system identifies if the file has been modified, then
operates accordingly. Features may be turned on or off by using a true or false Boolean in the Core
Configuration file. Other fields can be configured with a numeric value, such as the Battery Status
Percentage or Proximity Mode Distance.
Note: It is recommended to open and modify the Core Configuration file with Notepad++.
The following sections describe the most common sections of the Core Configuration file that a user
may wish to modify.
17
Figure 23 - True View UMS
