CORRECT PHASING OF SCROLL COMPRESSORS:
The scroll compressor is a unidirectional compressor and will only compress refrigerant in one
rotation direction. Therefore, the proper rotation of the scroll compressor must be checked. The
scroll compressor will run in the reverse direction but it will not pump refrigerant and will draw
substantially reduced current as compared to listed values, and will result in elevated sound levels.
Scroll compressor will trip on internal protection after running for some time in the reverse
direction.
Verification of the proper rotation of the scroll compressor is done by observing that suction
pressure drops and discharge pressure rises when the compressor is energized.
WARNING:
EXTENDED IMPROPER OPERATION MAY ALSO VOID COMPRESSOR WARRANTY.

1 SAFETY INFORMATION

PLEASE CAREFULLY READ THE FOLLOWING SAFETY INFORMATION BEFORE PROCEEDING
FURTHER
This installation and operation manual (IOM) contains important safety information that should be
followed during installation or servicing of a System 2100 series. Below is general safety information
as well as descriptions of safety and accident prevention symbols that will be utilized throughout
this document. In addition to safety information provided by this manual, all warnings, cautions, and
safety instructions located on the unit should be adhered to at all times. If applicable, local codes or
ordinances and any other safety requirements must also be taken into consideration when installing
or servicing the unit.
This IOM should be stored in a safe and accessible location for service personnel during installation
or servicing operations. When no longer needed, this IOM should be returned to its original location
for future reference.
General guidelines:
a)
Installation and maintenance are to be performed by qualified personnel only.
b)
Assure all field wiring conforms to the requirements of the equipment and all applicable national
and local codes. Assure the voltage on the unit name-plate agrees with the power supply available.
c)
Avoid contact with any sharp edges. It may cause serious injury.
d)
Make sure all power sources are disconnected before any service work is performed on the
equipment
ADDENDUM
5
