11 COMPONENTS IDENTIFICATION & ACCESS

11.1 FRONT LAYOUT (CONTROL BOX)

5
*Actual unit may be different

Figure 9 Sample Unit Shown*

NUMBER
1 DISCONNECT SWITCH
2 CONTACTORS
3 MOTOR PROTECTORS
4 MICROPROCESSOR CONTROLLER
5 TRANSFORMERS
29
1
3
2
4
NAME
