Front Accesss; Side Layout; Figure 10. Condenser And Reheat Elements Access; Figure 11. Unit Side Layout - Compu-aire System 2100 Series Installation And Operation Manual

11.2 FRONT ACCESSS

CW/GLYCOLM
ODULATING
VALVE
AIR FILTER
SWITCH

11.3 SIDE LAYOUT

Figure 10. Condenser and Reheat elements access

3
4

Figure 11. Unit Side Layout

1 HUMIDIFIER
2 COMPRESSOR
3 HOT GAS BYPASS VALVE,
SOLENOIDS,ETC
4 PIPING CONNECTION
30
REHEAT
ELEMENTS
PRESSURE
REGULATING
VALVE
1
2
