CY8CKIT-016 PS
CY8CKIT-001
CY8CKIT-001 Board with
CY8C28 Family Processor Module
MiniProg3
1
Download the CY8CKIT-016 Kit Setup execut-
able file from
http://www.cypress.com/go/
CY8CKIT-016. If you already have PSoC
Designer and PSoC Programmer installed,
download CY8CKIT-016 Kit Only. Run the
executable file to start the installation process.
During the installation process, continue with
the hardware setup.
®
C
1 THERMAL MANAGEMENT KIT
O
QUICK START GUIDE
Prerequisites for CY8CKIT-016
USB Cable
Connecting Wires
CY8CKIT-036 Board
2
Set VDD DIG and VDD ANLG to 3.3 V using
SW3, J7, and J6 on the CY8CKIT-001.
Attach the LCD included with the PSoC DVK
and set the LCD power jumper (J12) to ON
CY8CKIT-036
Power Adapter
.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cypress CY8CKIT-016
Summary of Contents for Cypress CY8CKIT-016
- Page 1 CY8C28 Family Processor Module USB Cable Connecting Wires MiniProg3 Power Adapter Download the CY8CKIT-016 Kit Setup execut- Set VDD DIG and VDD ANLG to 3.3 V using able file from http://www.cypress.com/go/ SW3, J7, and J6 on the CY8CKIT-001. CY8CKIT-016. If you already have PSoC...
- Page 2 Click on Program to program the device. details. For the latest information about this kit, visit http://www.cypress.com/go/CY8CKIT-016 © 2012 Cypress Semiconductor Corporation. All rights reserved. All trademarks or registered trademarks referenced herein are the properties of their respective owners. Doc.#: 001-80792 Rev. **...
