Mocka Jesse Entertainment Unit Assembly Instructions Manual page 7

Jesse Entertainment Unit
Assembly Instructions
11
Drawers x2
J
x4
J
J
14
Attach the back panel [17] in place between the side panels [14] and
[15] using 4x long screws (J) in the holes provided and a screwdriver.
Repeat step for the second drawer.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
J
17
J
15
12
Drawers x2
13
12
I I
C
DL
DR
C
C
Attach handles [11] & [13] to the corresponding front panels [10] & [12]
using 5x screws (I). Attach 2x rail components (D) to both left and right
side of each drawer using 4x screws (C).
11
10
I
I
I
C
C
DR
C
C
DL
C
7
