Mocka Jesse Entertainment Unit Assembly Instructions Manual page 5

Jesse Entertainment Unit
Jolt Wardrobe
Assembly Instructions
ASSEMBLY INSTRUCTIONS
7
8
B
B
J
J
Attach panel [21] to leg panels with 8x dowels (B) and secure
with 20x screws (J). Tighten with a screwdriver.
