  6. Installation instructions manual

Hearth & Home HEAT-OUT-GAS Installation Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
For use with these IntelliFire™ Touch models:
6000C-IFT
6000CL-IFT
6000CLX-IFT
6000CMOD-IFT
CD4236IFTR
CD4236IFTLR
CNXT4236IFTT/H
MERID36/MERIDPLA36
COSMO32/42-IFT
JADE32IN/JADE42IN/JADE42IL
MARQ36IN/MARQ42IN/MARQ42STIN
SL-3X/5X/7X/9X-IFT
MEZZO-C
COSMO32/36/42-IFT-B
JADE32IN-B/JADE42IN-B/JADE42IL-B
• Important operating
a n d m a i n t e n a n c e
instructions included.
1

Introduction

Table of Contents

1 Introduction
A. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
B. Approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
C. Kit Contents of HEAT-OUT-GAS . . . . . . . . . . . . . . . . . . . . 2
D. Installation Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
A. Framing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
B. Installing Vent Cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
C. Connecting Insulated Flex Duct . . . . . . . . . . . . . . . . . . . . 13
Installation of the HEAT-OUT-GAS may be done by a
qualified service technician only. Installation MUST com-
ply with local, regional, state and national codes and reg-
ulations.
IMPORTANT:
Failure to read and follow these instruc-
tions may create a possible hazard and will void the fire-
place warranty.
These instructions must remain with the equipment.
1
HEAT-OUT-GAS
- Installation Instructions -
8000C-IFT
8000CL-IFT
8000CLX-IFT
8000CMOD-IFT
CD4842IFTR
CD4842IFTLR
CNXT4842IFTT/H
MERIDPLA36/MERIDPLA42
RAVE32/42-IFT
TRUE-IFT/HEIR-IFT
ESC-42ST-IFT
ECHEL-C
CRAVE-C
RAVE32/36/42-IFT-B
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Hearth & Home Technologies • HEAT-OUT-GAS Instructions • 2310-939 Rev. I • 9/20
NOTICE
• Leave this manual with
party responsible for use
and operation.
CAUTION! Risk of Cuts or Abrasions. Wear protective
gloves and safety glasses during installation. Sheet metal
edges are sharp.
CAUTION! Failure to install, operate, and maintain the
power venting system in accordance with manufacturer's
instructions will result in conditions which may produce
bodily injury and/or property damage.
NOTICE: The fan motors present in the HEAT-OUT-GAS
Heat Management System will generate sound during op-
eration. The effects of the increased sound level can be
minimized with careful planning during installation of the
system.
CAUTION! Risk of Shock! Disconnect electrical power
from fireplace/power vent before performing any mainte-
nance, repair, or electrical wiring.
A. Introduction
The HEAT-OUT-GAS Heat Management system is de-
signed to remove unwanted heat from your home. The
HEAT-OUT-GAS operates on 120VAC, 60Hz electrical
services.
B. Approvals
The HEAT-OUT-GAS kit uses flexible duct marked as meet-
ing requirements of UL-181, Class I ducting.
