Summary of Contents for EL-CELL ECC-DEMS
- Page 1 User Manual Release 1.42 Electrochemical Test Cell ECC-DEMS July 2017 © 2017 EL-CELL GmbH...
- Page 2 The information in this manual has been carefully checked and believed to be accurate; however, no responsibility is assumed for inaccuracies. EL-CELL GmbH maintains the right to make changes without further notice to products described in this manual to improve reliability, function, or design. EL-CELL GmbH does not assume any liability arising from the use or application of this product.
-
Page 3: Table Of Contents
Features ........................ 5 Safety Precautions ....................6 Unpacking ......................6 Cell Assembly ....................... 7 Disassembly and Cleaning ................... 8 Accessories and Spare Parts ................9 Technical Support ....................10 Warranty ......................11 Page 3 of 11 User Manual ECC-DEMS – Release 1.42... -
Page 4: Product Description
The ECC-DEMS cell design is based on recent work on lithium-air batteries (Z. Peng, S.A. Freunberger, Y. Chen, P.G. Bruce, Science, Vol. 337 no. 6094 pp. 563-566). We especially thank Stefan Freunberger for his help to realize this test cell as another member of our ECC test cell series. -
Page 5: Features
Materials in media contact are stainless steel 1.4404 and PEEK (other materials on request) Size (including bracket): 90 mm x 54 mm x 70 mm (height x width x depth) Weight: 650 g Page 5 of 11 User Manual ECC-DEMS – Release 1.42... -
Page 6: Safety Precautions
Contact the factory if anything is missing or damaged. NOTE: Damaged shipments must remain with the original packaging for freight company inspection. List of Components ECC-DEMS test cell with bracket, fully equipped for operation with and without reference Accessories Kit ... -
Page 7: Cell Assembly
NOTE: Make sure not to short circuit cell lid and base through electrically conducting tube. Consider using a floating mode potentiostat when grounding either the cell lid or base by using metal tubing. Page 7 of 11 User Manual ECC-DEMS – Release 1.42... -
Page 8: Disassembly And Cleaning
Afterwards, the parts are to be rinsed with water, and to be dried at 80°C. PE seals and PTFE ferrules are to be replaced. NOTE: Leaving cell parts in contact with ambient atmosphere while still being wetted with electrolyte may result in severe corrosion. Page 8 of 11 User Manual ECC-DEMS – Release 1.42... -
Page 9: Accessories And Spare Parts
7 Accessories and Spare Parts ECC-DEMS Test Cell Page 9 of 11 User Manual ECC-DEMS – Release 1.42... -
Page 10: Technical Support
8 Technical Support Technical support for this product is exclusively handled by EL-CELL GmbH. The following procedure must be followed when the ECC-DEMS or any part of it is returned to EL-CELL GmbH for repair: Page 10 of 11 User Manual ECC-DEMS – Release 1.42... -
Page 11: Warranty
9 Warranty For a period of one year from the date of shipment, EL-CELL GmbH (hereinafter Seller) warrants the goods to be free from defect in material and workmanship to the original purchaser. During the warranty period, Seller agrees to repair or replace defective and/or nonconforming goods or parts without charge for material or labor, or, at the Seller’s option, demand return of the goods and tender...
