Assembly Instructions
The Powerful Choice
This manual, including the warnings and cautions inside, must be read and followed carefully by all
persons who use or maintain this product, including those who have any responsibility involving its
selection, application, service, or repair. This cap lamp system will perform as designed only if used
and maintained according to the instructions, otherwise it could fail to perform as designed and
persons who rely on this product could sustain serious personal injury or death.
H
A
H
A
C
H
A
R
G
E
C
H
A
R
G
E
ASSEMBLY
MANUAL
M
M
R
F
R
A
M
E
R
F
R
A
M
E
WARNING
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EnerSys OLDHAM M656204
Summary of Contents for EnerSys OLDHAM M656204
- Page 1 Assembly Instructions The Powerful Choice ASSEMBLY MANUAL WARNING This manual, including the warnings and cautions inside, must be read and followed carefully by all persons who use or maintain this product, including those who have any responsibility involving its selection, application, service, or repair. This cap lamp system will perform as designed only if used and maintained according to the instructions, otherwise it could fail to perform as designed and persons who rely on this product could sustain serious personal injury or death.
- Page 2 . M656204, 115 / 230 V AC, ART NO SINGLE , 50~60 H , 10- PHASE LAMP CHARGER CAUTIONS AND WARNINGS IMPORTANT Pay close attention to Warnings and Cautions in this manual. A Warning describes a condition that may cause serious personal injury or death if allowed to happen.
- Page 3 Assembly Instructions For 30 or 60 Capacity Lamp Charging Equipment Introduction The Oldham 10 lamp charging units can be stacked to produce a 30 or 60 capacity charging frame. By mounting the individual 10 lamp charging units between two uprights, any number of combinations in multiples of 10 can be achieved up to a maximum of 60 lamps, e.g.
- Page 4 3. Attach a 10 lamp charging unit as shown below to the uprights (a) in the centre position for stability by using the M12x16 sem screws (d). Ensure screw holes in charging unit are free running before attaching to uprights. 4.
- Page 5 6. Attach the additional upright (a) to the existing upright of the charger using M4x10 'Posidrive' screws (f), leaving out the top screw until top upright cover (c) is fitted. Wiring Connections Note : this equipment must be installed by qualified personnel in accordance with local regulations. Ensure individual 10 lamp charger input voltage is set to the correct mains supply voltage.
- Page 6 Thread the main input cable to the charger into the 'din' rail (e) remembering to pass the cable through the top cover (c) and gland (g). Tighten the gland. Always ensure that the electrical supply to the charging frame is isolated before servicing any part of the frame or chargers.
- Page 7 11. Attach the top upright cover (c) to the uprights, using posidrive screws (f) taking care once again not to trap any cables. Page 7 of 7...
