Model OMAX-6A-1B Single Bank Charger With Quick Disconnect
Model OMAX-12A-1B Single Bank Charger
Model OMAX-25A-1B Single Bank Charger
Model OMAX-50A-1B Single Bank Charger
Model OMAX-40AS-3B Three Bank Sequencing Charger
Model OMAX-50AS-3B Three Bank Sequencing Charger
For 12 Volt Odyssey
READ THE ENTIRE MANUAL BEFORE USING THIS PRODUCT.
FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY OR DEATH.
Warrensburg, MO 64093 USA
Please call Customer Service at 800-621-5485
for instructions on returning the charger.
Batteries
®
OWNER'S MANUAL
0099001202-03
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EnerSys Odyssey Ultimizer OMAX-6A-1B
Summary of Contents for EnerSys Odyssey Ultimizer OMAX-6A-1B
- Page 1 OWNER’S MANUAL Model OMAX-6A-1B Single Bank Charger With Quick Disconnect Model OMAX-12A-1B Single Bank Charger Model OMAX-25A-1B Single Bank Charger Model OMAX-50A-1B Single Bank Charger Model OMAX-40AS-3B Three Bank Sequencing Charger Model OMAX-50AS-3B Three Bank Sequencing Charger For 12 Volt Odyssey Batteries ®...
- Page 2 IMPORTANT: READ AND SAVE THIS SAFETY AND INSTRUCTION MANUAL. SAVE THESE INSTRUCTIONS – This manual will show you how to use your charger safely and effectively. Please read, understand and follow these instructions and precautions carefully, as this manual contains important safety and operating instructions.
- Page 3 RISK OF EXPLOSIVE GASES. 1.10 WORKING IN THE VICINITY OF A LEAD-ACID BATTERY IS DANGEROUS. BATTERIES GENERATE EXPLOSIVE GASES DURING NORMAL BATTERY OPERATION. FOR THIS REASON, IT IS OF UTMOST IMPORTANCE THAT YOU FOLLOW THE INSTRUCTIONS EACH TIME YOU USE THE CHARGER. 1.11 To reduce the risk of a battery explosion, follow these instructions and those published by the battery manufacturer and the manufacturer of any equipment you intend to use in the...
-
Page 4: Charger Location
Read, understand and follow all instructions for the charger, battery, vehicle and any equipment used near the battery and charger. Study all of the battery manufacturer’s specific precautions while charging and recommended rates of charge. Determine the voltage of the battery by referring to the vehicle owner’s manual and make sure that the output voltage selector switch is set to the correct voltage. -
Page 5: Follow These Steps When Battery Is Outside Vehicle
FOLLOW THESE STEPS WHEN BATTERY IS OUTSIDE VEHICLE. A SPARK NEAR THE BATTERY MAY CAUSE A BATTERY EXPLOSION. TO REDUCE THE RISK OF A SPARK NEAR THE BATTERY: Check the polarity of the battery posts. The POSITIVE (POS, P, +) battery post usually has a larger diameter than the NEGATIVE (NEG, N, -) post. -
Page 6: Control Panel
CONTROL PANEL LED Indicators (All Models) • CHECK (red) LED lit: Indicates that the battery is not properly connected to the charger. • CHECK (red) LED flashing: Indicates that the charger is in abort mode. • CHARGING (yellow) LED lit: Indicates that the charger has detected a battery and is charging it. -
Page 7: Charger Operation
Permanent Ring Connectors (Model OMAX-6A-1B) The ring connectors permanently attach to the battery, providing easy access to quickly charge your battery. This application is appopriate for motorcycles, lawn tractors, ATVs and snowmobiles. 1. To permanently attach to a battery, loosen and remove each nut from the bolt at the battery terminal. - Page 8 When the CHARGED LED is lit, the charger has started Maintain Mode. In this mode, the charger keeps the battery fully charged by delivering a small current when necessary. NOTE: The maintain mode technology utilized in the Enersys chargers allows you to ®...
-
Page 9: Maintenance Instructions
Initial Percent Calculation: When a battery % is calculated for the first time after connecting a battery, the digital display will show dashes (“- - -“ or “- -“ depending on the model) for a period as long as several seconds while the tester analyzes the battery. General Charging Notes Relay (All Models except OMAX-25A-1B) The charger is equipped with a relay that turns the charge current on and off to the battery. -
Page 10: Troubleshooting
TROUBLESHOOTING Models: All PROBLEM POSSIBLE CAUSE REASON/SOLUTION CHECK (red) LED is on. Clips are not making a good Check for a poor connection connection to the battery. to the battery. Make sure the connection points are clean. Connections are reversed. Unplug the charger and reverse the clips. - Page 11 Models: All, except OMAX-25A-1B PROBLEM POSSIBLE CAUSE REASON/SOLUTION The charger is making an The charger has a relay No problem; this is a normal audible clicking sound. that turns the current to the condition. battery on and off. Models: OMAX-6A-1B and OMAX-12A-1B PROBLEM POSSIBLE CAUSE REASON/SOLUTION...
-
Page 12: Before Returning For Repairs
BEFORE RETURNING FOR REPAIRS 16.1 When a charging problem arises, make certain that the battery is capable of accepting a normal charge. Double check all connections, the AC outlet for a full 120-volts, the charger clips for correct polarity and the quality of the connections from the cables to the clips and from the clips to the battery system. -
Page 13: Do Not Return This Product To The Store
LIMITED WARRANTY WARRANTY NOT VALID IN MEXICO. SCHUMACHER ELECTRIC CORPORATION, 801 BUSINESS CENTER DRIVE, MOUNT PROSPECT, IL 60056-2179, MAKES THIS LIMITED WARRANTY TO THE ORIGINAL RETAIL PURCHASER OF THIS PRODUCT. THIS LIMITED WARRANTY IS NOT TRANSFERABLE OR ASSIGNABLE. Schumacher Electric Corporation (the “Manufacturer”) warrants this battery charger for 3 years from the date of purchase at retail against defective material or workmanship that may occur under normal use and care. - Page 14 • 14 •...
- Page 15 SAVE ON POSTAGE! ACTIVATE YOUR WARRANTY ONLINE – THE QUICK AND EASY WAY! Go to www.batterychargers.com to register your product online. (No internet access? Send in the completed warranty card.) 3 YEAR LIMITED WARRANTY PROGRAM REGISTRATION MODEL: _____________________ DESCRIPTION: ________________________ This is the only express limited warranty, and the manufacturer neither assumes nor authorizes anyone to assume or make any other obligation.
