24 volt fully automatic battery charger

Advertisement

24 VOLT FULLY AUTOMATIC
MODEL 26340L
AC Supply:
DC Output:
Battery Capacity:
PLEASE SAVE THESE IMPORTANT SAFETY AND OPERATING INSTRUCTIONS
For correct operation of the equipment, it is important to read and be familiar
with this entire manual before installing and operating the charger.
LOOK FOR THIS SYMBOL TO POINT OUT SAFETY PRECAUTIONS. IT MEANS:
BECOME ALERT—YOUR SAFETY IS INVOLVED. IF YOU DO NOT FOLLOW THESE
SAFETY INSTRUCTIONS, INJURY OR PROPERTY DAMAGE CAN OCCUR.
IMPORTANT SAFETY INSTRUCTIONS
Read and understand this entire manual before
installing or operating the charger.
instructions on the charger, battery, and battery
powered equipment.
INTRODUCTION
This battery charger provides superior battery
performance and life, with low electrical power
consumption. The solid state design provides a
highly reliable, self-regulating charger with a
minimum of moving parts, designed for long,
trouble-free service.
reached its maximum state of charge, the solid
state control turns the charger off.
Operating Instructions

BATTERY CHARGER

Specifications
120 volts, 9.5 Amps, 60 Hertz, single-phase
24 volts DC, 20 amps
Use only on 24 volt, 12 cell, 150 to 225 ampere-hour (6 hr. rate) liquid electrolyte
lead acid batteries
DO NOT DISCARD THIS MANUAL AFTER READING.
Follow all
When the battery has
TYPE 24EL20-4ET
INSTALLATION
DANGER: TO AVOID ELECTRIC SHOCK,
NEVER ATTEMPT TO INSTALL OR REMOVE
CHARGER TO OR FROM BATTERY TRAY
WHILE THE CHARGER IS CONNECTED TO
THE AC SUPPLY OR BATTERIES.
CAUTION: NEVER ATTEMPT TO LIFT THE
CHARGER BY PULLING ON THE AC CORD.
CAUTION:
CHARGER INTO THE CHARGER COMPART-
MENT OF THE BATTERY TRAY, ALWAYS
PLACE
THE
VENTILATION HOLES FACING THE VENTI-
LATION HOLES IN THE BATTERY TRAY.
1
WHEN
PLACING
CHARGER
WITH
01825E
THE
THE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 26340L and is the answer not in the manual?

Questions and answers

Summary of Contents for EnerSys 26340L

  • Page 1: Battery Charger

    24 VOLT FULLY AUTOMATIC BATTERY CHARGER MODEL 26340L TYPE 24EL20-4ET Specifications AC Supply: 120 volts, 9.5 Amps, 60 Hertz, single-phase DC Output: 24 volts DC, 20 amps Battery Capacity: Use only on 24 volt, 12 cell, 150 to 225 ampere-hour (6 hr. rate) liquid electrolyte...
  • Page 2 FAILURE TO DO SO MAY CAUSE CHARGER GROUNDING METHODS FAILURE OR IMPROPER OPERATION. CAUTION: NEVER USE THE CHARGER IN A BATTERY TRAY THAT DOES NOT HAVE SUITABLE VENTILATION HOLES. place charger into charger compartment of the battery tray, lift the charger by grasping the charger handle to a position directly above the charger compartment.
  • Page 3: Troubleshooting Guide

    hours to be properly charged. If the charger WARNING: LEAD-ACID BATTERIES operates up to 18 hours and is unable to fully GENERATE GASES WHICH charge the batteries, an internal timer turns EXPLOSIVE. IF THE CHARGE CYCLE MUST the charger off. BE INTERRUPTED, PRESS THE START/STOP 7.
  • Page 4: Proper Care Of Motive Power Batteries

    utilized. Once sulfation is allowed to take CONTAIN ACIDS WHICH CAN CAUSE BODILY place, it may be partially reduced by HARM. DO NOT PUT WRENCHES OR OTHER returning, temporarily, to daily charging. METAL OBJECTS ACROSS THE BATTERY TERMINAL OR BATTERY TOP. ARCING OR 3.
  • Page 5 output until they have been discharged a ACID BATTERIES MONTHLY. MAINTAIN number of times. THE PROPER ELECTROLYTE LEVEL BY ADDING DISTILLED OR PURIFIED WATER 5. Do excessively discharge batteries. WHEN NECESSARY. Electrolyte levels lower Excessive discharge cause polarity during discharge and rise during charge. reversal individual cells...
  • Page 6: Wiring Diagram

    WIRING DIAGRAM PARTS LIST FOR MODEL 26340L TYPE 24EL20-4ET 120 VAC / 60 HZ PART NO. QTY. DESCRIPTION 28516S CASE ASSEMBLY 27317S AMMETER 26769S SCR ASSEMBLY 27706S ELECTRONIC TIMER 27784S CONTROL CABLE ASSEMBLY 26112S CORDSET, AC 03837S FUSE HOLDER 16681S...

This manual is also suitable for:

24el20-4et
