Emmett - Extending Dining Table
Assembly Instructions
- Please keep for future reference
149/2765
Dimensions
Width - 200cm
Depth - 90cm
Height - 75cm
Important
- Please read these instructions fully before starting assembly.
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
IW-17-7521-010-0
Issue 1 - 04/06/12
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Emmett 149/2765
Summary of Contents for Argos Emmett 149/2765
- Page 1 Emmett - Extending Dining Table Assembly Instructions - Please keep for future reference 149/2765 Dimensions Width - 200cm Depth - 90cm Height - 75cm Important - Please read these instructions fully before starting assembly. If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 IW-17-7521-010-0 Issue 1 - 04/06/12...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly. • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product, this could cause recommend the page 2.
- Page 3 If you have damaged or missing components, Components - Panels call the Customer Helpline: 08456 400800 Please check you have all the panels listed below Leg x 4 Top table (7 x 72.2cm) (160/200 x 90cm) Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly.
- Page 4 Assembly Instructions Step 1 Fitting dowels Insert cross dowel into the hole on top of each leg Note: Ensure the horizontal marking on each cross dowel is facing out as shown. Insert threaded bolt into the hole on each leg Tighten threaded bolt into the hole of cross dowel...
- Page 5 Assembly Instructions Step 2 - continued Attach leg onto table top by inserting bolts into the pre-drilled holes of metal corner bracket as shown. Insert flat washer lock washer and hex onto the two threaded bolts on leg and in order as shown.
- Page 6 Assembly Instructions Step 3 Stand the table upright LOCK Turn thumbscrews clockwise to lock table top in place. With help, carefully stand UNLOCK dining table upright. Important: LOCK table top before righting the table. LOCK Warning: The dining table is heavy. Lift with care.
- Page 7 Assembly Instructions Step 4 - continued Push ends of table inwards until no gap is visible. Note: Make sure dowels line up with holes on mating panel to avoid damage. Turn thumbscrews clockwise to lock table top in place. Note: To close table, reverse the procedure.
- Page 8 Emmett - Pair of Wooden Chairs Assembly Instructions - Please keep for future reference 156/8589 Dimensions Width - 44.2cm Depth - 51.3cm Height - 88cm Important - Please read these instructions fully before starting assembly. If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 IW-17-7521-172-0 Issue 1 - 23/06/12...
- Page 9 Safety and Care Advice Important - Please read these instructions fully before starting assembly. • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product, this could cause recommend the page 2.
- Page 10 If you have damaged or missing components, Components - Panels call the Customer Helpline: 08456 400800 Please check you have all the panels listed below Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 11 Assembly Instructions Step 1 Attaching aprons Position aprons onto back leg frame Note: Ensure the tenons are aligned correctly with mating back leg frame to avoid damage. Fix aprons back leg frame using 4 bolts as shown. Use allen key to turn fitting clockwise to fix.
- Page 12 Assembly Instructions Step 3 Fixing front leg frame Front side Carefully stand chair upright. Fix front leg frame aprons using 2 bolts as shown. Use allen key to turn fitting clockwise to fix. Step 4 Placing seat pad. Place seat pad a flat, stable, clean and soft surface as shown.
- Page 13 Assembly Instructions Step 5 Fixing seat pad. Insert 2 seat brackets into the slots on aprons shown. Note: Align holes on seat brackets with holes on seat pad Insert 2 bolts into the holes of seat brackets and the holes of mating seat pad shown.
