- Page 1 User Manual X4 Series X4 Pro X4 Classic X4 Sport ATTENTION: Please follow all assembly instructions. READ the instructions carefully to understand the operating procedures BEFORE you operate your caddy.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Packing List ..………………….......…......……3 Parts Glossary ..................………..4 Assembly Instructions .....………………........5, 6 Operating Instructions ..............……..7, 8 Remote Control Operation (X4R)..............9 Additional Instructions Braking System, Tracking, USB................10 Electronic Systems / Battery .............…….….11, 12 Testing Your Caddy..………………..........……12, 13 General Maintenance................…...…14 Trouble Shooting Guide .................14 Technical Specifications X4 Classic &... -
Page 3: Packing List
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT Bat-Caddy X4R FCC ID: QSQ-REMOTE IC ID: 10716A-Remote... -
Page 4: Parts Glossary
PARTS GLOSSARY X4 Series 1. Manual Rheostat Speed Control 2. Upper Bag Support 3. Bag Support Strap 4. Battery 5. Rear wheel 6. Rear Wheel Spring Clip Release & Lock 7. Dual Motors (within housing tube) 8. Lower Bag Support & Strap 9. -
Page 5: Assembly Instructions
ASSEMBLY INSTRUCTIONS X4 Series 1. Unpack all items carefully and check inventory. Place frame structure (one piece) on soft clean ground to protect the frame from being scratched. 2. Attach rear wheels to axles by pushing the wheel locking button (Pic-1) on the outside of the wheel and inserting the axle extension in to the wheel. - Page 6 ASSEMBLY INSTRUCTIONS (Continued) 6. Place the battery pack on the battery tray. Insert the 3-prong battery plug into the caddy outlet so the notch aligns properly and attach T-connector onto the battery. (SLA Battery lead is attached to battery) Then attach Velcro strap. Tightly fasten the Velcro strap underneath the battery tray and around the battery.
-
Page 7: Operating Instructions
OPERATING INSTRUCTIONS Manual Handle Control Functions X4 Sport / X4 Pro / X4R Rheostat speed dial Dual function - Power button / Stop-Go feature Advanced Distance Timer Battery indicator & power light Green - battery full Red - battery almost depleted 1. - Page 8 OPERATING INSTRUCTIONS (continued) X4 Classic Power button On/Off Stop/start button for digital cruise control Battery indicator & power light Green - battery full Red - battery almost depleted 1. The X4 Classic has a different face plate. 2. Power button has single feature power up cart or shut it off. 3.
-
Page 9: Remote Control Operation (X4R)
Remote Control Operation (X4R Only) FUNCTIONS: 1. STOP: The red button in the middle of the directional arrows should be used to stop the caddy abruptly or as emergency brake. 2. TIMER: 10, 20, 30 yards/meters: press once -10 yds., twice -20 yds.; three times - 30 yds. -
Page 10: Additional Instructions Braking System, Tracking, Usb
Additional Functions Braking System: The caddy drive train is designed to keep the wheels engaged with the motor/gearbox, thus acting as a brake that will maintain the caddy’s speed while going downhill. Tracking Adjustment*: Tracking behavior of all electric caddies is strongly dependent on equal weight distribution on the caddy and slope/topography of the golf course. -
Page 11: Electronic Systems / Battery
Electronic Systems • Remote Control Range: We recommend not to exceed 20-30 yards distance. The greater the distance between you and the caddy, the greater the chance of losing control of it. • Microcomputer: The remote caddy has 3 microcomputer controls. The primary microprocessor is in its own compartment underneath the battery tray. -
Page 12: Testing Your Caddy
Bat-Caddy will cover our batteries according to our warranty policy and any potential additional coverage is at our discretion”. - Page 13 Testing Your Caddy Remote Control Operation (X4R Only) (Continued) The remote is designed to have a maximum reach of 80-100 yards, but we strongly recommend to operate the caddy in closer ranges of 10-20 yards (not exceeding 30 yards) to be able to react quickly to any unforeseen events, such as other golfers crossing your path, or to avoid hidden obstructions such as creeks, bunkers, or uneven ground, etc.
-
Page 14: General Maintenance
• The Bat-Caddy has been designed so that the user can concentrate on playing golf, while the caddy does the work of carrying your bag. In order to keep your Bat-Caddy looking its best, wipe any mud or grass from the frame, wheels and chassis after every round using a damp cloth or paper towel. -
Page 15: Technical Specifications X4 Classic & X4 Sport
TECHNICAL SPECIFICATIONS Model Name X4 Classic / X4 Sport Model Type X4C & X4S: Non-Remote/Single Motor Standard Battery 35/36Ah SLA Dimensions SLA: 8 x 5 x 6 in (20 x 13 x 15 cm) Weight: 25 lbs Average charge time: 4-8 hours Lithium Battery 12V 25 Ah Lithium Dimensions: 7x5x4in, Weight: 5 lbs,... -
Page 16: X4 Pro & X4R
TECHNICAL SPECIFICATIONS Model Name X4 Pro / X4R Model Type X4 Pro: Non-Remote/Dual Motor X4R: Remote/Dual Motor Standard Battery 35/36Ah SLA Dimensions SLA: 8 x 5 x 6 in (20 x 13 x 15 cm) Weight: 25 lbs Average charge time: 4-8 hours Lithium Battery 12V 25 Ah Lithium Dimensions: 7x5x4in, Weight: 5 lbs,... -
Page 17: Technical Support & Contact Info
Check our website www.batcaddy.com Note: Bat-Caddy reserves the right to modify/upgrade any components during a model year, so illustrations on our website, brochures and manuals may slightly vary from the actual product shipped. However, Bat-Caddy guarantees that specifications and functionality will be always equal to or better from the advertised product. - Page 18 BC-9122020...
