Virgo Multi Media Storage Shelf
Assembly Instructions -
Dimensions
Width - 97cm
Depth - 16.8cm
Height - 15cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
875/4097
875/7290
issue 1 4/22/10
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Virgo Multi Media Storage Shelf
Summary of Contents for Argos Virgo Multi Media Storage Shelf
- Page 1 Virgo Multi Media Storage Shelf Assembly Instructions - 875/4097 Please keep for future reference 875/7290 Dimensions Width - 97cm Depth - 16.8cm Height - 15cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Check you have all the Do not stand on the panels, this We do not components and tools listed on could cause damage. recommend the use pages 2 and 3.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline:08456 400800 Please check you have all the panels listed below Back (97 x 15cm) Bottom (97x 15cm) Vertical x 5 (14.8 x 12.9cm)
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Wall Plug x 4 Screw x 19 Cover cap x 9 50mm Screw x 4 T ools required...
- Page 5 Assembly Instructions Step 1 Step 1 Constructing the shelf Note: It would be useful to ask someone to help you at this stage. Firstly, locate the Back board . This board has four pre-drilled holes which are used to mount the shelf to a wall after assembly.
- Page 6 Assembly Instructions Step 2 Attaching the bottom and back panel Note: It would be useful to ask someone to help you at this stage. Attach Bottom panel to the unit using Screws To secure Back panel to the Bottom panel using Screws...
- Page 7 Assembly Instructions Step 3 Mounting the wall unit Note: It would be useful to ask someone to help you at this stage. Important: When drilling into walls always check that there are no hidden wires or pipes etc. Make sure that the screws and wall plugs supplied are suitable for supporting the unit.
-
Page 8: A Guide To -Wall Mounting & Fixings
A Guide to -Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
