Avid CNC Benchtop PRO Assembly Instructions Manual page 72

Parts and Tools Required
QTY
1 CRP950-01 Cable Track Bracket
1 CRP950-02 Cable Track Bracket
1 CRP950-03 4040 Cable Track Extrusion
2 50mm Cable Track Section
1 CRP950-00-FAST:
- (6) M8 Roll-in T-Nut
- (4) M8 x 16mm Socket Head Cap Screw
- (4) M5 x 12mm Socket Head Cap Screw
- (2) M8 x 30mm Socket Head Cap Screw
- (2) 40 Series Anchor Fasteners
- (4) M5 x 16mm Socket Head Cap Screw
- (4) M5 Roll-in T-Nut
Required Tools:
- 6mm Allen Wrench
- 4mm Allen Wrench
- Flat Head Screwdriver
- Tape Measure
Benchtop PRO
Assembly Instructions
The following parts and tools will be used in Section 5
Part/Description Packaged In
CRP950-00-XX
CRP950-00-XX
CRP950-00-XX
CRP950-00-XX
CRP950-00-XX
