Parts And Tools Required - Avid CNC Benchtop PRO Assembly Instructions Manual

Parts and Tools Required

QTY
1 8016 Gantry Extrusion, 800mm (31-1/2)
1 CRP840-00-650 - PRO Linear Ballscrew Axis, Gantry
1 CRP920-01-L - Gantry Riser, Left
1 CRP920-01-R - Gantry Riser, Right
1 CRP920-00-FAST:
- (16) M8 x 25mm Socket Head Cap Screw
- (16) M8 Slide-in T-Nut
1 CRP930-00-FAST:
- (16) M8 x 25mm Flat Head Screw
- (16) M8 x 25mm Socket Head Cap Screw
- (16) M8 Slide-in T-Nut
QTY
1 8016 Gantry Extrusion, 1120mm (44-1/16")
1 CRP840-00-950 - PRO Linear Ballscrew Axis, Gantry
1 CRP920-01-L - Gantry Riser, Left
1 CRP920-01-R - Gantry Riser, Right
1 CRP920-00-FAST:
- (16) M8 x 25mm Socket Head Cap Screw
- (16) M8 Slide-in T-Nut
1 CRP930-00-36-FAST:
- (22) M8 x 25mm Flat Head Screw
- (16) M8 x 25mm Socket Head Cap Screw
- (22) M8 Slide-in T-Nut
Benchtop PRO
Assembly Instructions
The following parts and tools will be used in Section 2
2' Wide Parts List
Part/Description
3' Wide Parts List
Part/Description
Packaged In
Linear Extrusion Bundle
Benchtop Gantry Axis
CRP900-00-XXXX-HW
CRP900-00-XXXX-HW
CRP900-00-XXXX-HW
CRP900-00-XXXX-HW
Packaged In
Linear Extrusion Bundle
Benchtop Gantry Axis
CRP900-00-3636-HW
CRP900-00-3636-HW
CRP900-00-3636-HW
CRP900-00-3636-HW
