Avid CNC Benchtop PRO Assembly Instructions Manual page 10

QTY
4 8080 Crossmember Extrusion, 961mm (37-7/8")
1 CRP840-00-950 - PRO Linear Ballscrew Axis, Left
1 CRP840-00-950 - PRO Linear Ballscrew Axis, Right
1 CRP910-00-36-FAST:
- (32) 40 Series Anchor Fastener
- (32) M8 x 30mm Socket Head Cap Screw
- (16) M8 Slide-in T-Nut
4 CRP913-00:
- (1) M12 Leveling Foot 50mm (Total QTY: 4)
- (1) M12 BTP Leveling Foot End Plate (Total QTY: 4)
- (2) M8 x 30mm Socket Head Cap Screw (Total QTY: 8)
- (2) M8 Roll In T-Nut (Total QTY: 8)
6mm Ball-End Allen Wrench
Adjustable Wrench
Benchtop PRO
Assembly Instructions
3' x 3' Parts List
Part/Description
Required Tools
Packaged In
Linear Extrusion Bundle
Table Axis Left
Table Axis Right
CRP900-00-3636-HW
CRP900-00-3636-HW
Version 2020Q2.1
© 2020 Avid CNC
All Rights Reserved
