Wheelchair does not move when trigger is pressed Possible Solutions:
● Check the PowerAssist is switched on
● Check the battery is fully charged.
● Check the connection between the battery and motor is correct.
● Check the wheelchair brakes are not applied.
● Check the drive wheel is in contact with the ground.
Wheelchair is difficult to push manually. Possible Solutions:
● Check the wheelchair brakes are not applied.
● Remove PowerAssist.
The PowerAssist is too fast / slow
● Try varying the speed with speed dial.
● Try recharging the batteries (if too slow).
● Check the wheelchair brakes are not applied

TROUBLESHOOTING

SPECIFICATIONS

● Weight: 14kg (weight with battery)
6.5kg (battery pack)
● Max speed: 5 km/h
● Max gradient: 6º
● Weight capacity: (115kg) including wheel
chair & user
● Motor: 12V 100W 4100RPM
● Battery:12V 18ah Sealed Lead Acid
● Charger: 3A 12V output
