Locker Bed – Twin
Pre-Assembly:
Please read all instructions before beginning assembly.
Two-adult assembly is recommended.
Save all packing materials until assembly is complete to avoid accidentally discarding smaller parts or
hardware.
If using power tools to aid in assembly please use with caution. Power tools can damage hardware.
Note: Do not full tighten all bolts until all parts are in place. Failure to follow these instructions may cause the bolts
to misalign during assembly.
TOOLS REQUIRED:
Allen Wrench (4mm)
PARTS INCLUDED:
A - Bed - 1pc
HARDWARE LIST:
a –
Bolt(Φ 1/4"*1/2"L)
– 16pcs
d – Caster without Brake – 2pcs
Note: All parts and hardware are delivered in one carton.
b – Lock Washer et – 16pcs
e – Caster with Brake – 2pcs
- 1 -
www.pbteen.com
c – Flat Washer – 16pcs
Advertisement
Table of Contents
Related Manuals for PB TEEN Twin Locker Bed
Summary of Contents for PB TEEN Twin Locker Bed
- Page 1 Locker Bed – Twin Pre-Assembly: Please read all instructions before beginning assembly. Two-adult assembly is recommended. Save all packing materials until assembly is complete to avoid accidentally discarding smaller parts or hardware. If using power tools to aid in assembly please use with caution. Power tools can damage hardware. Note: Do not full tighten all bolts until all parts are in place.
- Page 2 Assembly Instructions: 1. Place the bed (A) upside down on a clean, soft surface such as a carpet or rug. 2. Attach the caster (d & e) to the bracket of bed as shown, using flat washer (c), lock washer (b) and bolt (a) . Securely tighten the bolt with Allen wrench.
