2.3

Gateway configuration

When the gateway is powered on, the blue LED at the bottom of the gateway turns ON.
After bootup, the gateway will turn on the configuration WIFI hotspot. The bootup takes
about 30-60 seconds.
Configuration WIFI hotspot has SSID "cassia-XXXXXX", where XXXXXX is the last 6 digits
of the gateway's MAC address. MAC address can be found from the bottom of the
gateway. Password for this WIFI hotspot is the same as the SSID.
Connect to this WIFI hotspot with the device used for configuration (computer, phone or
tablet) and open the web browser. Type 192.168.40.1 to the web browser's address field
and press enter. Cassia configuration page will open. During the first login the default
password needs to be changed. Default credentials are:
-
Login: admin
-
Password: admin
It is recommended to replace the default credentials.
Once logged in, the Status Page is shown. This page shows current operation mode and
connection status of the gateway. AC Online Time shows how long the gateway has been
connected to the AC (Access Controller) server. If no time is shown, it means that the
gateway does not have a connection to the AC server. AC server connection is needed for
the Smart Sensor data transfer.
DOCUMENT ID
9AKK107046A4620
© Copyright 2020 ABB. All rights reserved.
Figure 2 Cassia login page
