Regular Voice Parameters - Yamaha PORTATONE PSR-1000 Owner's Manual

Editing the voice -SOUND CREATOR-

Regular Voice Parameters

COMMON
SOUND
EFFECT/EQ (PSR-2000)
EFFECT (PSR-1000)
HARMONY
The following parameters are linked to the ones in each display.
Common parameter
MONO
PORTAMENTO TIME
FILTER BRIGHTNESS
FILTER HARMONIC CONTENT
REVERB DEPTH
CHORUS DEPTH
DSP ON/OFF
DSP DEPTH
DSP TYPE/VARIATION
EQ LOW/GAIN
EQ HIGH/GAIN
HARMONY/ECHO TYPE
HARMONY/ECHO VOLUME
HARMONY/ECHO SPEED
HARMONY/ECHO ASSIGN
HARMONY/ECHO CHORD NOTE ONLY
HARMONY/ECHO TOUCH LIMIT
COMMON
The explanations here apply to step #3 on page 87.
Set the volume of the current edited
voice.
Determines the touch sensitivity, or
how greatly the volume responds to
your playing strength.
0 — –– Produces more dramatic
level drops, the more softly
you play.
64 — – Normal response.
127 — Produces high volume for
any playing strength (fixed)
88
PSR-2000/1000
Determines the common settings such as voice volume or octave.
Determines the timbre/EG (Envelope Generator)/vibrato of the voice.
Determines the effect depth/type and equalizer settings.
Determines the Harmony/Echo settings.
Other location
VOICE EFFECT (TOP PANEL)
MIXING CONSOLE
MIXING CONSOLE
MIXING CONSOLE
MIXING CONSOLE
MIXING CONSOLE
VOICE EFFECT (TOP PANEL)
MIXING CONSOLE
MIXING CONSOLE/VOICE EFFECT (TOP PANEL)
MIXING CONSOLE
MIXING CONSOLE
HARMONY/ECHO (FUNCTION)
HARMONY/ECHO (FUNCTION)
HARMONY/ECHO (FUNCTION)
HARMONY/ECHO (FUNCTION)
HARMONY/ECHO (FUNCTION)
HARMONY/ECHO (FUNCTION)
1 2 3 4 5 6 7 8
Keep in mind that there are
certain parameters whose
Sound Creator settings
affect only the Main part's
voice.
page 58
page 123
page 123
page 123
page 124
page 124
page 57
page 124
page 58,124
page 121
page 121
page 143
page 143
page 143
page 143
page 143
page 143
Set the portamento time of each
part (MAIN/LAYER/VOICE)
(page 123).
This determines whether the voice
is played monophonically (page 58).
Shift the octave range of the
selected voice up or down in
octaves. When the Main or Layer
part's voice is used, the M/LYR
parameter is available; when the
Left part's voice is used, the LEFT
parameter is available.
