12. scanCONTROL Gateway
scanCONTROL Gateway allows for scanCONTROL SMART sensors to be integrated
into various fieldbus systems:
- Profinet
- Ethernet IP
- EtherCat
All measurement results obtained from the profile evaluation carried out of a
scanCONTROL SMART sensor can be transmitted to a PLC via one of these fieldbus
systems. Furthermore, all scanCONTROL sensor settings can be set via scanCON-
TROL Gateway (e. g. Laser on/off or switch User Mode).
Sensor parame-
terization
Power supply
Triggering
Encoder
Synchronization
Mode control
Sensor control
The scanCONTROL Gateway can connect up to four scanCONTROL SMART sensors
to the fieldbus. The transmission rate of measurement values is up to 500 Hz.
Please refer to the TechNote T026 (scanCONTROL fieldbus integration) for more
details.
Gateway parameterization
Ethernet
Switch
USB
scanCONTROL
Gateway
