nnection to an SPS
Status
13 14
DO 1
DO 7
A1 A2
DO 1
A3 A4
DO 3
A5 A6
DO 5
A7 A8
DO 7
750-536
Digital output module
Connect the supply voltage
Digital output modules need a field supply of 5 VDC or 24 VDC depending on the
module type.
After mounting of the modules install the required wiring.
Connect the "System supply (out)" terminals of the OU-Filter module to the
"System supply (in)" terminals of the OU-Fieldbus Coupler (0 V and 24 V).
Connect the system supply (in) of the OU-Filter module to the power supply
(0 V and 24 V).
Connect the field supply (in) of the OU-Filter module to the power supply
(0 V and 24 V resp. 0 V and 5 V).
i
The system supply and field supply should be separated to ensure the bus
operation and electrical isolation in case of a short-circuit of an actor.
Status
DO 2
Function
Error
DO 8
Data
contacts
DO 2
AO 1
D0 4
D0 6
AO 3
DO 8
Power jumper
contacts
13 14
A
C
B
D
A1 A2
AO 2
M M
0
V
A3 A4
M M
0
V
0
750-555
Analog output module
Data contacts
0 V
AO 4
V
Power jumper
contacts
Bus termination
A
C
B
D
750-600
