Using Features
To Use Park and Paging
1. Park the call.
To park the call at your extension:
press programmed Park button, or
press Transfer, dial your extension, and press Transfer
again, or
press Feature and select Park.
To park the call at a Park zone:
press programmed Park-(zone) button, or
press Transfer, dial Park Zone extension, and press
Transfer again, or
press DSS button for the Park zone. If manual completion is
programmed, hang up.
2. Set up page.
For Speakerphone Page, press DSS button, or press
programmed Group Page-(name) or Page All button, or dial
Group Page or Page All number.
For Loudspeaker Page, press programmed
Loudspeaker Page button or press Feature and select
Loudspkr Pg[LdsPg]. If necessary, dial the code for the
page zone.
3. Announce call and extension where call is parked.
4-36 P a r k
