oRdeRing inFoRMation and pacKaging

packaging

Multipack
Compressor models Nbr*
SM/SZ 084 6
SM/SZ 090 6
SM/SZ 100 6
SM/SZ 110-120 6
SM/SZ 115-125 6
SM/SZ 160 6
SM/SZ 148-161 6
SM/SZ 175-185 6
SY/SZ 240 4
SY/SZ 300 4
SY/SZ 380 4
* Nbr = number of compressors per pallet
Compressor models Nbr*
SM/SZ 084 8
SM/SZ 090 8
SM/SZ 100 8
SM/SZ 110-120 8
SM/SZ 115-125 6
SM/SZ 160 6
SM/SZ 148-161 6
SM/SZ 175-185 6
SY/SZ 240 4
SY/SZ 300 4
SY/SZ 380 4
38
Multipack
Length Width Height
in. in. in.
44.9 37.4 29.0
44.9 37.4 29.0
44.9 37.4 29.0
44.9 37.4 29.0
44.9 37.4 32.0
44.9 37.4 32.0
44.9 37.4 32.0
48.4 37.4 33.0
44.9 37.4 36.25
44.9 37.4 36.25
44.9 37.4 37.2
Industrial pack
Length Width Height
in. in. in.
44.90 37.4 27.8
44.90 37.4 27.8
44.90 37.4 27.8
44.25 38.0 29.0
44.25 38.0 29.0
44.25 38.0 30.0
44.25 38.0 30.0
44.25 38.0 33.0
44.90 37.4 35.6
44.90 37.4 36.0
44.90 37.4 37.0
Single pack
Gross Static
Length
weight stacking
in.
lb pallets
941 3 18.5
968 3 18.5
968 3 18.5
1087 3 24.0
1140 3 24.0
1338 3 24.0
1219 3 24.0
1444 2 24.0
1413 2 20.1
1413 2 20.1
1440 2 20.1
Gross Static
weight stacking
lb. pallets
1213 3
1248 3
1248 3
1467 3
1114 3
1299 3
1194 3
1419 2
1400 2
1400 2
1426 2
Single pack
Gross
Width Height
weight
in. in.
14.6 23.5
14.6 23.5
14.6 23.5
24.0 37.0
24.0 37.0
24.0 37.0
24.0 37.0
24.0 37.0
18.3 30.7
18.3 30.7
18.3 31.7
Industrial pack
lb.
148
152
152
197
197
228
211
248
344
355
362
