piping connections

suction and discharge
connections

sight glass

schrader

oil drain

Suction
sM / sZ 084
Discharge
Suction
sM / sZ 090
Discharge
Suction
sM / sZ 100
Discharge
Suction
sM / sZ 110
Discharge
Suction
sM / sZ 115
Discharge
Suction
sM / sZ 120
Discharge
Suction
sM / sZ 125
Discharge
Suction
sM / sZ 148
Discharge
Suction
sM / sZ 161
Discharge
Suction
sM / sZ 160
Discharge
Suction
sM / sZ 175
Discharge
Suction
sM / sZ 185
Discharge
Suction
sY / sZ 240
Discharge
Suction
sY / sZ 300
Discharge
Suction
sY / sZ 380
Discharge
All Performer® scroll compressors
come equipped with a sight glass that
may be used to determine the amount
and condition of the oil in the sump.
The oil fill connection and gauge port
is a 1/4" male flare connector that
incorporates a Schrader valve.
The oil drain connection allows oil
to be removed from the sump for
changing, testing, etc. The fitting
contains an extension tube into the oil
sump for more effective oil removal.
The connection is female 1/4" NPT .
note: on SY/SZ 240-380, it is not
possible to drain oil from the suction
connection.
Brazed version Rotolock version
1
Brazed Rotolock
1'' 1/8 -
3/4'' -
1'' 1/8 -
3/4'' -
1'' 1/8 -
3/4'' -
1'' 3/8 -
7/8'' -
1'' 3/8 1'' 3/4
7/8'' 1'' 1/4
1'' 3/8 -
7/8'' -
1'' 3/8 1'' 3/4
7/8'' 1'' 1/4
1'' 3/8 -
7/8'' -
1'' 3/8 -
7/8'' -
1'' 5/8 2'' 1/4
1'' 1/8 1'' 3/4
1'' 5/8 2'' 1/4
1'' 1/8 1'' 3/4
1'' 5/8 2'' 1/4
1'' 1/8 1'' 3/4
1'' 5/8 2'' 1/4
1'' 1/8 1'' 3/4
1'' 5/8 2'' 1/4
1'' 1/8 1'' 3/4
2'' 1/8 -
1'' 3/8 -
oil fill
connection
and
gauge port
oil drain
connection
2
sleeve included
2
1
-
-
-
-
-
-
-
-
1'' 1/8
3/4''
-
-
1'' 1/8
3/4''
-
-
-
-
1'' 3/8
7/8''
1'' 3/8
7/8''
1'' 3/8
7/8''
1'' 5/8
1'' 1/8
1'' 5/8
1'' 1/8
-
-
