Installation

Method 2: Digital(DVI) Connection

12
1
Turn off the computer and unplug the power cable.
2
Connect the signal cable (DVI-I) to the DVI port on the back
of the computer.
3
Connect the AC power cable to the power socket on the
back of the monitor.
4
Plug the computer and monitor power cables into a nearby
outlet.
5
Press the POWER/
monitor to turn the monitor on, then turn the computer on. If
the monitor displays an image, the monitor is successfully
installed. If no image is displayed, check all connections.
4
3
If the screen displays "out of range", please follow the
instructions below to set up:
Press the MENU button to display the OSD.
Press the UP or DOWN button to highight the
SELECT) icon, then press the MENU button. The OSD
displays:
Press the UP or DOWN button to select DIGITAL INPUT.
button on the front panel of the LCD
Connect to
wall outlet
2
Connect to the DVI port
1
2
1
2
DIGITAL
INPUT
Xerox© LCD Monitor User's Manual
(INPUT
