  • Page 2 XEROX® and all Xerox product names mentioned in this publication are trademarks of XEROX CORPORATION. Other company trademarks are also acknowledged.
  • Page 3: Table Of Contents

    The options Options ..................19 The utilities Options ..................20 4 Technical Information Preset Mode Timing Chart ................21 D-SUB Connector PIN Assignment .............22 Plug and Play ....................23 Visual Inspection ..................23 Troubleshooting ...................24 Specifications ....................25 Authorized Service Centers .................26 Xerox© LCD Monitor User’s Manual...
  • Page 4 Recycling Place EUROPE When disposing of Xerox Branded Monitors in Europe, please contact one of the following three locations to make arrangements for recycling. Proview International (UK) Limited 30 The Avenue, Watford, Hertfordshire WD17 4AE United Kingdom Timothy Lo Tel: +44 1923-248-111 Fax: +44 1923-248-222 Email: tim.lo@proview.co.uk...
  • Page 5: Ce Marking Declaration Of Conformity

    All places of operation are characterized by their connection to the public low voltage power supply system. Xerox© LCD Monitor User’s Manual...
  • Page 6: Federal Communications Commission (fcc) Statement

    3. Connect the equipment into an outlet on a circuit which is different from what the receiver is connected to. 4. Consult the dealer or an experienced radio/TV technician for help. CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the user authority to operate the equipment. Xerox© LCD Monitor User’s Manual...
  • Page 7: Important Safety Instructions

    • Use and handle the power cord with care. • Do not place any heavy objects on the AC power cord. • Do not pull the AC power cord. Do not handle the AC power cord with a wet hand. Xerox© LCD Monitor User’s Manual...
  • Page 8 • Never place the equipment :on a bed, sofa, rug, or any other similar surfaces; too close to drapes/curtains/walls, in a bookcase, built-in cabinet, or any other similar places that may cause poor ventilation. (continued on next page) Xerox© LCD Monitor User’s Manual...
  • Page 9 Please drop off the above-mentioned waste at a designated place for recycling waste electrical and electronic equipment. If you do not know where to drop off your waste equipment for recycling, please contact your local city office or household waste collection service. Xerox© LCD Monitor User’s Manual...
  • Page 10: Introduction

    Special surface treatment on the LCD panel for high ambient light environments that provides excellent legibility by reducing glare. • Wall-Mounting Capability Compatible with the VESA industry standard for wall/arm mounts to save valuable desktop space. Xerox© LCD Monitor User’s Manual...
  • Page 11: Package Contents

    If any items are missing, please return this product to the original place of purchase. LCD Monitor Quick Warranty CD-ROM Guide Card (Driver/Manual) Power Cord CAUTION: Be sure to save original box and all packing material for future transport of monitor. Xerox© LCD Monitor User’s Manual...
  • Page 12: Front View And Controls

    The LED light indicates when the LCD monitor is activated (green light indicates power on and amber light indicates power saving). Turns the LCD monitor on and off. AUTO Press to automatically adjust the display settings to optimize performance based on the D-SUB signal. Xerox© LCD Monitor User’s Manual...
  • Page 13: Installation

    Turn off the computer and unplug the power cable. Connect the signal cable to the D-SUB port on the back of the computer. Connect the power cord to the LCD monitor and wall outlet. Connect to the D-SUB port Connect to power source Xerox© LCD Monitor User’s Manual...
  • Page 14 NOTE: The LED indicator is green when the monitor operates normally and will turn to amber when in power saving mode. When the monitor is off, the LED turns dark. Xerox© LCD Monitor User’s Manual...
  • Page 15: Installing Your Lcd Monitor

    Cover an even stable surface with a soft cloth. Place the unit face-down on the cloth. Fit the stand onto the bottom of the display unit as shown, then push until the two latches snap into their sockets. LATCH SOCKETS LATCHES Xerox© LCD Monitor User’s Manual...
  • Page 16: Osd Menu

    3 OSD Menu Using the OSD Menu To create the best picture, your XA3 series has been preset at the factory with the Preset Mode Timing shown on page 21. The OSD (On Screen Display) Menu allows the user to adjust various settings and options by following the steps below.
  • Page 17: The Osd Options

    Adjusts picture settings such as H/V position, H size and phase. utilities Adjusts the setting of the display time of the on-screen menu. Allows selection of the language used on all the on-screen menus. reset Restores the factory settings. exit Exits the on-screen menus. Xerox© LCD Monitor User’s Manual...
  • Page 18: The Picture Options

    Adjusts the position of the picture up and down in the window. phase Adjusts signal phase, which can improve focus clarity and image stability. clock Adjusts the width of the picture. exit Exits the picture menu. Xerox© LCD Monitor User’s Manual...
  • Page 19: The Advanced Options

    Fixes the red, green and blue component levels at factory settings; they cannot be independently adjusted. user Allows the user to adjust red, green and blue color component levels independently. exit Exits the advanced menu. Xerox© LCD Monitor User’s Manual...
  • Page 20: The Options Options

    The options menu includes the following options: DESCRIPTION osd h. position Moves the OSD left and right in the window. osd v. position Moves the OSD up and down in the window. exit Exits the OSD menu. Xerox© LCD Monitor User’s Manual...
  • Page 21: The Utilities Options

    Allows selection of the display time of the on-screen menu. osd background Controls the translucence of the on-screen menu’s background. languages Allows selection of the languages used on all the on-screen menus. exit Exits the utilities menu. Xerox© LCD Monitor User’s Manual...
  • Page 22: Technical Information

    800 x 600 37.88 60.30 48.08 72.20 46.87 75.00 1024 x 768 48.36 60.00 56.48 70.10 60.02 75.00 1280 x 1024* 63.98 79.98 * 1280 x 1024 resolution is not available in 15” LCD monitor. Xerox© LCD Monitor User’s Manual...
  • Page 23: D-sub Connector Pin Assignment

    Technical Information D-SUB Connector PIN Assignment DESCRIPTION Green Blue Ground Self Test Red Ground Green Ground Blue Ground 5 VDC Ground Ground SDA (FOR DDC) H. Sync V. Sync SCL (FOR DDC) Xerox© LCD Monitor User’s Manual...
  • Page 24: Plug And Play

    LCD display. A few isolated permanently lit or unlit pixels may be present. The maximum permitted number of pixel faults is stipulated in the stringent international standard ISO 13406-2 (Class II). Xerox© LCD Monitor User’s Manual...
  • Page 25: Troubleshooting

    • If using Windows 9X/2000/XP, wait a few seconds; once Windows detects the problem, a dialog will appear allowing you to manually set up the video mode according to the preset mode timing chart (refer to page 21). Xerox© LCD Monitor User’s Manual...
  • Page 26: Specifications

    800:1 Dot Pitch 0.264mm x 0.264mm 0.294mm x 0.294mm Max. Resolution 1280x1024 1280x1024 Input Connector D-SUB D-SUB Power Source AC100-240V, 50-60Hz AC100-240V, 50-60Hz Power Consumption Dimension 378x382x192 mm 426x413x210 mm Changes are periodically made to this specifications. Current specifications may also be obtained via the internet, www.xerox-displays.com or www.xerox-displays.info Xerox© LCD Monitor User’s Manual...
  • Page 27: Authorized Service Centers

    Hours: 8AM ~ 6PM - Central Time EUROPE AUTHORIZED SERVICE CENTER CONTACTS: XOAL BVBA RAKETSRAAT 100 B-1130 BRUSSEL BELGIUM E-EMAIL: rma@proview-repair.com http://www.proview-repair.com Hotline: 00800 00 88 77 66 Fax: +32-2-725-2513 Hours: 10AM ~ 12PM and 2PM ~ 5PM Monday through Friday Xerox© LCD Monitor User’s Manual...
