  • Page 1 User’s Guide XM3-19w LCD Monitor LCD Monitor...
  • Page 2 XEROX® and all Xerox product names mentioned in this publication are trademarks of XEROX CORPORATION. Other company trademarks are also acknowledged.
  • Page 3: Table Of Contents

    4 Technical Information Preset Mode Timing Chart ...24 DVI Connector PIN Assignment ...25 D-SUB Connector PIN Assignment ...26 Plug and Play ...27 Visual Inspection ...27 Troubleshooting ...28 Specifications ...29 Authorized Service Centers ...30 Table of Contents Xerox© LCD Monitor User’s Manual...
  • Page 4 EUROPE When disposing of Xerox Branded Monitors in Europe, please contact one of the following three locations to make arrangements for recycling. Proview International (UK) Limited 30 The Avenue, Watford, Hertfordshire WD17 4AE United Kingdom Timothy Lo Tel: +44 1923-248-111 Fax: +44 1923-248-222 Email: tim.lo@proview.co.uk...
  • Page 5: Ce Marking Declaration Of Conformity

    All places of operation are characterized by their connection to the public low voltage power supply system. Xerox© LCD Monitor User’s Manual...
  • Page 6: Federal Communications Commission (Fcc) Statement

    4. Consult the dealer or an experienced radio/TV technician for help. CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the user authority to operate the equipment. Xerox© LCD Monitor User’s Manual FCC/CE...
  • Page 7: Important Safety Instructions

    • Use and handle the power cord with care. • Do not place any heavy objects on the AC power cord. • Do not pull the AC power cord. Do not handle the AC power cord with a wet hand. Xerox© LCD Monitor User’s Manual...
  • Page 8 • Never place the equipment :on a bed, sofa, rug, or any other similar surfaces; too close to drapes/curtains/walls, in a bookcase, built-in cabinet, or any other similar places that may cause poor ventilation. Xerox© LCD Monitor User’s Manual Important Safety Instructions (continued on next page)
  • Page 9 If you do not know where to drop off your waste equipment for recycling, please contact your local city office or household waste collection service. Xerox© LCD Monitor User’s Manual...
  • Page 10: Introduction

    The 19” wide screen has the outstanding 1440x900 resolution. It can make the image displayed more precise. XM3-19w is excellent to be your first wide screen monitor. True multimedia sound without using valuable desktop space. The XM3-19w features two built-in stereo speakers integrated into the stylish design.
  • Page 11: Package Contents

    Be sure to save original box and all packing material for future transport of monitor. LCD Monitor D-SUB Cable AUDIO Cable ������ ����� ������� ������� ��� ������� ��� ������� ��� ������� ��� ������� Quick Warranty Guide Card Power Cord ������ ����� CD-ROM (Driver/Manual) Xerox© LCD Monitor User’s Manual...
  • Page 12: Front View And Controls

    (blue light indicates power on and amber light indicates power saving). Turns the LCD monitor on and off. AUTO Press to automatically adjust the display settings to optimize performance based on the D-SUB signal. Xerox© LCD Monitor User’s Manual Introduction...
  • Page 13: Installation

    Connect the signal cable to the D-SUB port on the back of the computer. Connect the audio cable to the line-in port on the back of the computer. Connect to the Line-in port Connect to the D-SUB port Connect to power source Xerox© LCD Monitor User’s Manual...
  • Page 14 When the monitor is off, the LED turns dark. Xerox© LCD Monitor User’s Manual button, located on the bottom side of the main button is used for switching the LCD monitor on and...
  • Page 15: Method 2: Digital (Dvi) Connection

    When the DVI and VGA input ports are connected at the same time, press down the AUTO button after 3 seconds to switch between the VGA mode and DVI mode. button, located on the bottom side of the main Xerox© LCD Monitor User’s Manual...
  • Page 16 For upgraded video card, refer to the video card manufacturer’s web site: nVIDIA® (www. nvidia.com), ATI® (www.ati.com), S3® (www.s3graphics.com), Intel® (www.intel.com) and so on. Xerox© LCD Monitor User’s Manual Installation Connect to the Line-in port Connect to the DVI port...
  • Page 17: Installing Your Lcd Monitor

    Cover an even stable surface with a soft cloth. Place the unit face-down on the cloth. Fit the stand onto the bottom of the display unit as shown, then push until the two latches snap into their sockets. LATCHES Xerox© LCD Monitor User’s Manual LATCH SOCKETS...
  • Page 18: Osd Menu

    3 OSD Menu Using the OSD Menu To create the best picture, your XM3-19w has been preset at the factory with the Preset Mode Timing shown on page 24. The OSD (On Screen Display) Menu allows the user to adjust various settings and options by following the steps below.
  • Page 19: The Osd Options

    Restores the factory settings. Exits the on-screen menus. auto adjust brightness picture contrast advanced h position audio v position options phase utilities clock reset exit exit picture advanced audio options utilities reset exit Xerox© LCD Monitor User’s Manual <up>to select...
  • Page 20: The Picture Options

    Adjusts signal phase, which can improve focus clarity and image stability. clock Adjusts the width of the picture. exit Exits the picture menu. Xerox© LCD Monitor User’s Manual auto adjust brightness picture contrast advanced h position audio v position...
  • Page 21: The Advanced Options

    Fixes the red, green and blue component levels at factory settings; they cannot be independently adjusted. user Allows the user to adjust red, green and blue color component levels independently. exit 1 2 3 4 5 cool natural warm Xerox© LCD Monitor User’s Manual user...
  • Page 22: The Audio Options

    The audio menu includes the following options: volume Adjusts the speakers volume up and down. mute Mutes and restores the monitor speakers sound. exit Exits the audio menu. Xerox© LCD Monitor User’s Manual volume mute picture exit advanced audio options...
  • Page 23: The Options Options

    Moves the OSD up and down in the window. Exits the OSD menu. osd h position osd v position picture exit advanced audio options utilities reset exit DESCRIPTION osd h. position osd v. position exit Xerox© LCD Monitor User’s Manual...
  • Page 24: The Utilities Options

    Allows selection of the display time of the on-screen menu. Controls the translucence of the on-screen menu’s background. Allows selection of the languages used on all the on-screen menus. Exits the utilities menu. Xerox© LCD Monitor User’s Manual osd timeout osd background picture language advanced...
  • Page 25: Technical Information

    1440 x 900 Horizontal Frequency(kHz) 31.47 31.47 37.86 37.50 35.16 37.88 48.08 46.87 48.36 56.48 60.02 63.98 79.98 55.47 70.64 Xerox© LCD Monitor User’s Manual Vertical Frequency(Hz) 70.00 60.00 72.80 75.00 56.25 60.30 72.20 75.00 60.00 70.10 75.00 59.90 74.98...
  • Page 26: Dvi Connector Pin Assignment

    DVI Connector PIN Assignment Xerox© LCD Monitor User’s Manual C1 C2 C3 C4 DESCRIPTION TMDS Data 2- TMDS Data 2+ TMDS Data 2/4 shield DDC Clock DDC Data Analog Vertical Sync TMDS Data 1- TMDS Data 1+ TMDS Data 1/3 shield...
  • Page 27: D-Sub Connector Pin Assignment

    D-SUB Connector PIN Assignment DESCRIPTION Ground Self Test Red Ground Green Ground Blue Ground Ground Ground SDA (FOR DDC) H. Sync V. Sync SCL (FOR DDC) Green Blue 5 VDC Xerox© LCD Monitor User’s Manual...
  • Page 28: Plug And Play

    According to ISO 13406-2 (Class II), a maximum of 6 pixels and 7 subpixels may be defective, i. e. a total of 25 faulted dots. This corresponds to approx. 0.002 % of the entire screen surface. Xerox© LCD Monitor User’s Manual Technical Information...
  • Page 29: Troubleshooting

    • If using Windows 9X/2000/XP, wait a few seconds; once Windows detects the problem, a dialog will appear allowing you to manually set up the video mode according to the preset mode timing chart (refer to page 24). Xerox© LCD Monitor User’s Manual...
  • Page 30: Specifications

    Input Connector Power Source Power Consumption Dimension Changes are periodically made to this specifications. Current specifications may also be obtained via the internet, www.xerox-displays.com or www.xerox-displays.info Xerox© LCD Monitor User’s Manual XM3-19w Panel Size 19”w TFT LCD Brightness Contrast Ratio 500:1 Dot Pitch 0.284mm x 0.284mm...
  • Page 31: Authorized Service Centers

    Hours: 8AM ~ 6PM - Central Time EUROPE AUTHORIZED SERVICE CENTER CONTACTS: XOAL BVBA RAKETSRAAT 100 B-1130 BRUSSEL BELGIUM E-EMAIL: rma@proview-repair.com http://www.proview-repair.com Hotline: 00800 00 88 77 66 Fax: +32-2-725-2513 Hours: 10AM ~ 12PM and 2PM ~ 5PM Monday through Friday Xerox© LCD Monitor User’s Manual...
