- Page 2 XEROX® and all Xerox product names mentioned in this publication are trademarks of XEROX CORPORATION. Other company trademarks are also acknowledged.
-
Page 3: Table Of Contents
Using the OSD Menu ...14 The OSD Options ...15 4 Technical Information Preset Mode Timing Chart ...18 DVI Connector PIN Assignment ...19 D-SUB Connector PIN Assignment ...20 Plug and Play ...21 Visual Inspection ...21 Troubleshooting ...22 Table of Contents Xerox© LCD Monitor User’s Manual... -
Page 4: Federal Communications Commission (Fcc) Statement
4. Consult the dealer or an experienced radio/TV technician for help. CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the user authority to operate the equipment. Xerox© LCD Monitor User’s Manual... -
Page 5: Important Safety Instructions
• Use and handle the power cord with care. • Do not place any heavy objects on the AC power cord. • Do not pull the AC power cord. Do not handle the AC power cord with a wet hand. Xerox© LCD Monitor User’s Manual... - Page 6 • Never place the equipment :on a bed, sofa, rug, or any other similar surfaces; too close to drapes/curtains/walls, in a bookcase, built-in cabinet, or any other similar places that may cause poor ventilation. Xerox© LCD Monitor User’s Manual Important Safety Instructions (continued on next page)
- Page 7 The power cord or plug is damaged. b. Liquid is spilled into the product . c. An object falls onto or into the product. d. The product has been dropped or damaged. e. The product’s display is abnormal. Xerox© LCD Monitor User’s Manual...
-
Page 8: Introduction
• Compatible with standard IBM VGA, extended VGA, super VGA, IBM XGA modes, as well as VESA resolution standards. • Universal power supply. • Microsoft© Windows 9x/2000/XP compatible and VESA Display Data Channel(DDC)1/2B compatible. Xerox© LCD Monitor User’s Manual Introduction... -
Page 9: Package Contents
LCD Monitor Power Cord* DVI-I to D-SUB User Guide Adapter * Power cord specification : H05 VV-F 3G 0.75mm CAUTION: Be sure to save original box and all packing material for future transport of monitor. Xerox© LCD Monitor User’s Manual... -
Page 10: Front View And Controls
VGA signal. The LED light indicates when the LCD monitor is activated (blue light indicates power on and blue flash indicates power saving). POWER/ Turns the LCD monitor on and off. Xerox© LCD Monitor User’s Manual Introduction... -
Page 11: Installing Your Lcd Monitor
Fit the stand onto the bottom of the display unit as shown. Use a coin to tighten the screw on the bottom of the stand until the screw is firmly fixed in place. DISPLAY UNIT Xerox© LCD Monitor User’s Manual STAND... -
Page 12: Installation
If the monitor displays an image, the monitor is successfully installed. If no image is displayed, check all connections. Xerox© LCD Monitor User’s Manual button on the front panel of the LCD Attach the... -
Page 13: Method 2: Digital(Dvi) Connection
SELECT) icon, then press the MENU button. The OSD displays: • Press the UP or DOWN button to select DIGITAL INPUT. button on the front panel of the LCD Connect to wall outlet Connect to the DVI port DIGITAL INPUT Xerox© LCD Monitor User’s Manual (INPUT... -
Page 14: Using Your Lcd Monitor
The LED indicator is blue when the monitor operates normally and will flash when in power saving mode. When the monitor is off, the LED turns dark. Xerox© LCD Monitor User’s Manual button is used for switching the LCD POWER/... -
Page 15: Osd Menu
Press the UP or DOWN button to change the value of the selected item. Select the EXIT icon to exit the OSD. Repeat steps 1 through 5 to make further adjustments. All changes are stored immediately. EXIT Xerox© LCD Monitor User’s Manual... -
Page 16: The Osd Options
Adjust the position of the picture up and down in the window. H.Size Adjusts the width of the picture. Phase Adjusts signal phase, which can improve focus clarity and image stability. Xerox© LCD Monitor User’s Manual EXIT DESCRIPTION OSD Menu... - Page 17 WARM Inclines colors toward the red end of the spectrum. Fixes the red, green and blue component levels at factory settings; they cannot be independently adjusted. EXIT Exits the OSD menu. Xerox© LCD Monitor User’s Manual...
- Page 18 Changes the position of the OSD. H. Position Moves the OSD left and right in the window. V. Position Moves the OSD up and down in the window. EXIT Exits the OSD menu. EXIT Exits the OSD. Xerox© LCD Monitor User’s Manual OSD Menu...
-
Page 19: Technical Information
800 x 600 1024 x 768 1280 x 1024 Horizontal Frequency(kHz) 31.47 31.47 37.86 37.50 35.16 37.88 48.08 46.87 48.36 56.48 60.02 63.98 79.98 Xerox© LCD Monitor User’s Manual Vertical Frequency(Hz) 70.00 60.00 72.80 75.00 56.25 60.30 72.20 75.00 60.00 70.10 75.00... -
Page 20: Dvi Connector Pin Assignment
DVI Connector PIN Assignment Xerox© LCD Monitor User’s Manual C1 C2 C3 C4 DESCRIPTION TMDS Data 2- TMDS Data 2+ TMDS Data 2/4 shield DDC Clock DDC Data Analog Vertical Sync TMDS Data 1- TMDS Data 1+ TMDS Data 1/3 shield... -
Page 21: D-Sub Connector Pin Assignment
D-SUB Connector PIN Assignment DESCRIPTION Ground Self Test Red Ground Green Ground Blue Ground Ground Ground SDA (FOR DDC) H. Sync V. Sync SCL (FOR DDC) Green Blue 5 VDC Xerox© LCD Monitor User’s Manual... -
Page 22: Plug And Play
According to ISO 13406-2 (Class II), a maximum of 6 pixels and 7 subpixels may be defective, i. e. a total of 25 faulted dots. This corresponds to approx. 0.002 % of the entire screen surface. Xerox© LCD Monitor User’s Manual Technical Information... -
Page 23: Troubleshooting
Windows detects the problem, a dialog will appear allowing you to manually set up the video mode according to the preset mode timing chart (refer to page 18). button on the front panel of the Xerox© LCD Monitor User’s Manual...
