30dBm, and at the maximum power level, the output power tolerance should not exceed +/-2dB under normal
condition and +/-2.5dB under extreme condition.

5.10.2 Module RF Receive Sensitivity

The following table shows the module's conducted receive sensitivity, it is tested under static condition.
Table 25 : SIM900-DS conducted RF receive sensitivity
Frequency
GSM850
EGSM900
DCS1800
PCS1900

5.10.3 Module Operating Frequencies

The following table shows the module's operating frequency range; it is followed by the 3GPP TS 05.05 technical
specification requirement.
Table 26 : SIM900-DS operating frequencies
Frequency
GSM850
EGSM900
DCS1800
PCS1900
SIM900-DS_Hardware Design_V1.00
Receive sensitivity（Typical）
-109dBm
-109dBm
-109dBm
-109dBm
Receive
869 ~ 894MHz
925 ~ 960MHz
1805 ~ 1880MHz
1930 ~ 1990MHz
42
Smart Machine Smart Decision
Receive sensitivity(Max)
-107dBm
-107dBm
-107dBm
-107dBm
Transmit
824 ~ 849 MHz
880 ~ 915MHz
1710 ~ 1785MHz
1850 ~ 1910MHz
