SIM Tech SIMCom SIM7100-PCIE Hardware Design

Hide thumbs Also See for SIMCom SIM7100-PCIE:
Table of Contents

Advertisement

Quick Links

Download this manual
SIM7100-PCIE(A)_Hardware Design_V1.01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIMCom SIM7100-PCIE and is the answer not in the manual?

Questions and answers

Related Manuals for SIM Tech SIMCom SIM7100-PCIE

Summary of Contents for SIM Tech SIMCom SIM7100-PCIE

  • Page 1: Sim7100-Pcie_Hardware Design_V1.01

    SIM7100-PCIE(A)_Hardware Design_V1.01...

  • Page 2: General Notes

    Smart Machine Smart Decision Document Title SIM7100-PCIE(A) Hardware Design Version 1.01 Date 2014-11-03 Status Draft Document SIM7100-PCIE(A)_Hardware_Design_V1.01 Control ID General Notes SIMCom offers this information as a service to its customers, to support application and engineering efforts that use the products designed by SIMCom. The information provided is based upon requirements specifically provided to SIMCom by the customers.

  • Page 3: Table Of Contents

    Smart Machine Smart Decision Contents SIM7100-PCIE_Hardware Design_V1.01........................1 General Notes................................2 Copyright..................................2 Copyright © Shanghai SIMCom Wireless Solutions Ltd. 2014................2 Contents..................................3 Table Index.................................. 5 Figure Index................................6 Version History................................7 Introduction................................8 SIM7100-PCIE(A) Overview..........................9 2.1. SIM7100-PCIE(A) Key Features......................11 2.2.
  • Page 4 Smart Machine Smart Decision 5.5. Current Consumption (VCC =3.3V+0.3V/-0.1V)..................33 5.6. Electro-Static Discharge..........................34 5.7. Radio Characteristics..........................35 5.7.1. Conducted Output Power........................35 5.7.2. Conducted Receive Sensitivity......................36 5.7.3. Supported Band............................36 Appendix..................................37 SIM7100-PCIE(A) Top and Bottom View....................37 Dimensions of SIM7100-PCIE......................... 38 III. Related Documents............................40 Terms and Abbreviations...........................41 Safety Caution............................
  • Page 5 Smart Machine Smart Decision Table Index TABLE 1: SIM7100-PCIE(A) SERIES FREQUENCY BANDS..................9 TABLE 2: SIM7100-PCIE(A) KEY FEATURES......................11 TABLE 3: CODING SCHEMES AND MAXIMUM NET DATA RATES OVER AIR INTERFACE......12 TABLE 4: OPERATING MODE............................14 TABLE 5: PCI EXPRESS MINI CARD CONNECTOR PIN DESCRIPTION..............17 TABLE 6: RECOMMENDED 3.3V POWER SUPPLY CHARACTERISTICS...............
  • Page 6 Smart Machine Smart Decision Figure Index FIGURE 1: SIM7100-PCIE(A) FUNCTIONAL DIAGRAM................... 15 FIGURE 2: SIM7100-PCIE(A) PIN OUT DIAGRAM..................... 16 FIGURE 3: DIMENSIONS OF SIM7100-PCIE(UNIT: MM)..................19 FIGURE 4: SIM CARD HOLDER REFERENCE CIRCUIT................... 22 FIGURE 5: RESET TIMING............................. 23 FIGURE 6: LED_WWAN# REFERENCE CIRCUIT....................... 24 FIGURE 7: WAKE# BEHAVIOUR...........................

  • Page 7: Version History

    Smart Machine Smart Decision Version History Date Version Description of change Author 2014-11-03 1.01 Origin Yang Hongliang, Li Ya SIM7100-PCIEA_Hardware_Design 2014-11-03...

  • Page 8: Introduction

    Smart Machine Smart Decision 1 Introduction SIM7100-PCIE(A) module is PCI Express Mini Card. This document describes SIM7100-PCIE(A) hardware interface in great detail, which can help user to quickly understand SIM7100-PCIE(A) interface specifications, electrical and mechanical details. SIM7100-PCIEA_Hardware_Design 2014-11-03...

  • Page 9: Sim7100-Pcie(A) Overview

    Smart Machine Smart Decision 2 SIM7100-PCIE(A) Overview SIM7100-PCIE(A) series support dual-band GSM/GPRS/EDGE and dual-band UMTS /HSPA+ that works on frequencies of GSM 850MHz/EGSM 900 MHz, DCS 1800 MHz/PCS 1900MHz and WCDMA 850/900MHz, 1900/18000 MHz, 2100MHz,TDSCDMA band A and band B,LTE-FDD band1/2/3/4/5/6/7/8/13/17/20, LTE-TDD band 38/39/40/41.
  • Page 10 Smart Machine Smart Decision LTE TDD B40   LTE TDD B41  (100M BW) SIM7100-PCIE(A) provides various hardware interfaces via Mini PCI Express card connector.  Power supply: : 3.3V+0.3/-0.1V  USB Interface  Audio Interface  UART Interface ...

  • Page 11: Sim7100-Pcie(A) Key Features

    Smart Machine Smart Decision 2.1. SIM7100-PCIE(A) Key Features Table 2: SIM7100-PCIE(A) Key Features Feature Implementation Power supply Single supply voltage 3.3V+0.3V/-0.1V  GPRS multi-slot class 12  EDGE multi-slot class 12  UMTS R99 speed: 384 kbps DL/UL  HSPA+: 5.76 Mbps(UL), 42 Mbps(DL) Transmission data ...

  • Page 12: Table 3: Coding Schemes And Maximum Net Data Rates Over Air Interface

    Smart Machine Smart Decision Table 3: Coding schemes and maximum net data rates over air interface Multislot definition(GPRS/EDGE) Slot class DL slot number UL slot number Active slot number GPRS coding scheme Max data rata（4 slots） Modulation type CS 1 = 9.05 kb/s / time slot 36.2 kb/s GMSK CS 2 = 13.4 kb/s / time slot...
  • Page 13 Smart Machine Smart Decision Category 10 14.4Mbps 16QAM,QPSK Category 11 0.9Mbps QPSK Category 12 1.8Mbps QPSK Category 13 17.6Mbps 64QAM Category 14 21.1Mbps 64QAM Category 15 23.4Mbps 16QAM Category 16 28Mbps 16QAM Category 17 23.4Mbps 64QAM Category 18 28Mbps 64QAM Category 19 35.5Mbps 64QAM...

  • Page 14: Operating Mode

    Smart Machine Smart Decision 2.2. Operating Mode The table below summarizes the various operating modes of SIM7100-PCIE. Table 4: Operating Mode Mode Status Function Module will automatically go into sleep mode if the conditions of sleep mode are enabling and there is no on air GSM/GPRS/E and no hardware interrupt (such as USB wake-up operation or DGE/WCDM...

  • Page 15: Functional Diagram

    Smart Machine Smart Decision 2.3. Functional Diagram The following figure is SIM7100-PCIE(A) functional diagram. Figure 1: SIM7100-PCIE(A) Functional Diagram SIM7100-PCIEA_Hardware_Design 2014-11-03...

  • Page 16: Package Information

    Smart Machine Smart Decision 3 Package Information 3.1. Pin Out Diagram Figure 2: SIM7100-PCIE(A) Pin Out Diagram SIM7100-PCIEA_Hardware_Design 2014-11-03...

  • Page 17: Pci Express Mini Card Connector Pin Description

    Smart Machine Smart Decision 3.2. PCI Express Mini Card Connector P in Description Table 5: PCI Express Mini Card Connector Pin Description Pin name Pin number Description Comment Power supply 2,24,39,41,52 3.3 Power supply for module 4,9,15,18,21, 26,27,29,34,3 Ground 5,37,40,43,50 Reset If this pin is unused, PERST#...
  • Page 18 Smart Machine Smart Decision GPIO42 General input/output PIN. others Default: Wake up host WAKE#/MIC1P Optional：MIC positive input * If these pins are unused, keep open. Default：NC If Analog audio is MIC1N Optional: MIC negative input * available, wake up function is invalid. Default: NC Analog audio is EAR1P...

  • Page 19: Package Dimensions

    Smart Machine Smart Decision 3.3. P ackage Dimensions Figure 3: Dimensions of SIM7100-PCIE(Unit: mm) ： Note Please refer to appendix for package dimension details. SIM7100-PCIEA_Hardware_Design 2014-11-03...

  • Page 20: Application Interface

    Smart Machine Smart Decision 4 Application Interface Power Supply The recommended power supply voltage of SIM7100-PCIE(A) is 3.3V. Table 6: Recommended 3.3V Power Supply Characteristics Symbol Parameter Type Unit Power supply voltage Supply current capability 2000 Power Saving Mode SIM7100-PCIE(A) has two power saving modes: minimum functionality mode and sleep mode. When SIM7100-PCIE(A) is in sleep mode and minimum functionality mode, the current of module is lowest.

  • Page 21: Wake Up Sim7100-Pcie(A) From Sleep Mode

    Smart Machine Smart Decision If USB HOST sends USB suspend request, SIM7100-PCIE(A) will enter sleep mode automatically for reducing power consume, when peripheral equipment of SIM7100-PCIE(A) stops working, and module has no on air or audio activity required. In sleep mode, SIM7100-PCIE(A) can still receive paging or SMS from network. Note: SIM7100-PCIE(A) could enter sleep mode when the host CPU supports USB suspend mode, otherwise it could not enter sleep mode.

  • Page 22: Sim Card Interface

    Smart Machine Smart Decision SIM Card Interface The SIM interface complies with the GSM Phase 1 specification and the new GSM Phase 2+ specification for FAST 64 kbps SIM card. Both 1.8V and 3.0V SIM card are supported. The SIM interface is powered from an internal regulator in the module.

  • Page 23: W_Disable

    Smart Machine Smart Decision Symbol Parameter Type Unit High-level input voltage Low-level input voltage After power up AND-NOT high-hold operation time(keep high level or keep open) Reset low level hold on time low-hold The low level pulse time must is longer than 300us，The following figure is the timing of reset function. Figure 5: Reset Timing W_DISABLE# The W_DISABLE# pin controls SIM7100-PCIE(A) to enter or exit the Flight mode by default.

  • Page 24: Wake

    Smart Machine Smart Decision LED_WWAN# Status Working Status Searching Network/Call Connect 200ms On, 200ms Off Data Transmit 800ms On, 800ms Off Registered network Power off / Sleep Reference circuit is recommended in the following figure: Figure 6: LED_WWAN# Reference Circuit WAKE# The WAKE# pin can be used as an interrupt signal to host.

  • Page 25: Uart Interface

    Smart Machine Smart Decision Figure 8: WAKE# behavior as a caller WAKE# Reference circuit is recommended in the following figure: Figure 9: WAKE# Reference Circuit Note: If Analog audio is available, wake up function is invalid. Please consult our sales staff, for more information.

  • Page 26: Table 13: Uart Electrical Characteristic

    Smart Machine Smart Decision Figure 10: UART1 Full modem Figure 11: Null modem Table 13: UART Electrical Characteristic Symbol Parameter Unit High-level input voltage 1.26 -0.3 0.63 Low-level input voltage High-level output voltage 1.35 Low-level output voltage 0.45 The SIM7100-PCIE(A) UART is 1.8V interface. A level shifter should be used if user’s application is equipped with a 3.3V UART interface.

  • Page 27: Pcm/Analog Audio Interface

    Smart Machine Smart Decision Figure 12: Reference circuit of level shift To comply with RS-232-C protocol, the RS-232-C level shifter chip should be used to connect SIM7100-PCIE(A) to the RS-232-C interface. In this connection, the TTL level and RS-232-C level are converted mutually.

  • Page 28: Analog Audio Interface

    Smart Machine Smart Decision Data Ordering Note: PCM interface can be control by AT command. For more details please refer to document [1] and document [2] Table 15: PCM DC Characteristics Symbol Parameter Type Unit High-level input voltage 1.26 Low-level input voltage -0.3 0.63 High-level output voltage...

  • Page 29: Table 18: Audio Parameter

    Smart Machine Smart Decision Figure 14: Microphone interface configuration Note: SIM7100-PCIE(A) has integrated MIC bias circuit. There is no need to pull the MIC1P and MIC1N up to the external power, just connect it to microphone. MIC1P and MIC1N must be differential lines. Main audio parameters can be changed to satisfy users’...

  • Page 30: Gnss (Gps And Glonass)

    Smart Machine Smart Decision own electronic and mechanical design. 4.11 GNSS (GPS and GLONASS) SIM7100-PCIE(A) merges GNSS (GPS/GLONASS) satellite and network information to provide a high-availability solution that offers industry-leading accuracy and performance. This solution performs well, even in very challenging environmental conditions where conventional GNSS receivers fail, and provides a platform to enable wireless operators to address both location-based services and emergency mandates.
  • Page 31 Smart Machine Smart Decision GSM850 ≧ 29dBm ≦ -104dBm EGSM900 ≧ 29dBm ≦ -104dBm DCS1800 ≧ 26dBm ≦ -104dBm PCS1900 ≧ 26dBm ≦ -104dBm WCDMA B1 ≧ 19dBm ≦ -104dBm WCDMA B2 ≧ 19dBm ≦ -104dBm WCDMA B5 ≧ 19dBm ≦...

  • Page 32: Electrical, Reliability And Radio Characteristics

    Smart Machine Smart Decision 5 Electrical, Reliability and Radio Characteristics 5.1. Absolute Maximum Ratings The absolute maximum ratings are described by the following table. Module may be damaged beyond these ratings. Table 21: Absolute maximum ratings Symbol Parameter Type Unit VCC input voltage VCC total peak current Input current...

  • Page 33: Usim_Vdd Characteristics

    Smart Machine Smart Decision USIM_VDD=3.0V USIM_VDD=1.8V 0.36 USIM_VDD=3.0V 0.36 USIM_VDD=1.8V 1.62 USIM_VDD=3.0V USIM_CLK USIM_VDD=1.8V 0.216 USIM_VDD=3.0V USIM_VDD=1.8V USIM_VDD=3.0V USIM_VDD=1.8V 0.27 USIM_VDD=3.0V USIM_DATA USIM_VDD=1.8V USIM_VDD=3.0V USIM_VDD=1.8V 0.27 USIM_VDD=3.0V 5.4. USIM_VDD Characteristics Table 24: USIM_VDD Characteristics Symbol Parameter Type Unit 2.85 3.15 Output voltage 1.80 Output current...

  • Page 34: Electro-Static Discharge

    Smart Machine Smart Decision DCS1800 @power level #0 <530mA,Typical 420mA PCS1900 @power level #0 <530mA,Typical 420mA DATA mode, GPRS ( 3Rx, 2 Tx ) CLASS 12 GSM 850 @power level #5 <460mA,Typical 360mA GSM 900 @power level #5 <440mA,Typical 325mA DCS1800 @power level #0 <400mA,Typical 285mA PCS1900...

  • Page 35: Radio Characteristics

    Smart Machine Smart Decision Table 26: ESD characteristics (Temperature: 25℃, Humidity: 45 %) Contact discharge Air discharge ±5KV ±10KV ±5KV ±10KV Antenna port ±5KV ±10KV USB_DP,USB_DN ±4KV ±8KV 5.7. Radio Characteristics 5.7.1. Conducted Output Power The following table shows SIM7100-PCIE’s conducted output power, comply with 3GPP TS 05.05and TS 34.121.

  • Page 36: Conducted Receive Sensitivity

    Smart Machine Smart Decision 5.7.2. Conducted Receive Sensitivity The following table shows conducted receiving sensitivity of SIM7100-PCIE. Table 28: Conducted Receive Sensitivity Frequency Receive sensitivity GSM850 < -109dBm E-GSM900 < -109dBm DCS1800 < -109dBm DCS1800 < -109dBm WCDMA 2100 < -110dBm WCDMA 1900 <...

  • Page 37: Appendix

    Smart Machine Smart Decision Appendix I. SIM7100-PCIE(A) Top and Bottom View Figure 15: SIM7100-PCIE(A) Top and Bottom View SIM7100-PCIEA_Hardware_Design 2014-11-03...

  • Page 38: Dimensions Of Sim7100-Pcie

    Smart Machine Smart Decision Dimensions of SIM7100-PCIE Figure 16: Dimensions of SIM7100-PCIE(A) (Unit: mm Top view) SIM7100-PCIEA_Hardware_Design 2014-11-03...

  • Page 39: Figure 17: Dimensions Of Sim7100-Pcie(A) (Unit: Mm Bottom And Side View)

    Smart Machine Smart Decision Figure 17: Dimensions of SIM7100-PCIE(A) (Unit: mm Bottom and Side view) SIM7100-PCIEA_Hardware_Design 2014-11-03...

  • Page 40: Related Documents

    Smart Machine Smart Decision III.Related Documents Table 30: Related Documents Document name Remark SIMCOM_SIM7100_ATC_EN_ V1.XX.doc SIM7100_Audio_Application_ SIM7100_Audio_Application_Note Note ITU-T Draft Serial asynchronous automatic dialing and control recommendation V.25ter: Digital cellular telecommunications (Phase 2+); AT command set for GSM 07.07: GSM Mobile Equipment (ME) GSM 07.10: Support GSM 07.10 multiplexing protocol Digital cellular telecommunications (Phase 2+);...

  • Page 41: Terms And Abbreviations

    Smart Machine Smart Decision IV. Terms and Abbreviations Table 31: Terms and Abbreviations Abbreviation Description Analog-to-Digital Converter Adaptive Multi-Rate Coding Scheme Circuit Switched Data Clear to Send Data Terminal Equipment (typically computer, terminal, printer) Data Terminal Ready Discontinuous Transmission Enhanced Full Rate EGSM Enhanced GSM Electrostatic Discharge...
  • Page 42 Smart Machine Smart Decision Terminal Equipment, also referred to as DTE Transmit Direction UART Universal Asynchronous Receiver & Transmitter Unsolicited Result Code USSD Unstructured Supplementary Service Data Phonebook abbreviations SIM fix dialing phonebook SIM last dialing phonebook (list of numbers most recently dialed) Mobile Equipment list of unanswered MT calls (missed calls) SIM (or ME) own numbers (MSISDNs) list Mobile Equipment list of received calls...

  • Page 43: Safety Caution

    Smart Machine Smart Decision V. Safety Caution Table 32: Safety caution Marks Requirements When in a hospital or other health care facility, observe the restrictions about the use of mobiles. Switch the cellular terminal or mobile off, medical equipment may be sensitive to not operate normally for RF energy interference.

  • Page 44: Contact Us

    Smart Machine Smart Decision Contact us: Shanghai SIMCom Wireless Solutions Ltd. Add: SIM Technology Building, No.633,Jinzhong Road, Changning District, Shanghai P.R. China 200335 Tel: +86 21 3235 3300 Fax: +86 21 3235 3301 URL: www.sim.com/wm SIM7100-PCIEA_Hardware_Design 2014-11-03...
