6.10.2 Module RF Receive Sensitivity

The following table shows the module's conducted receiving sensitivity, it is tested under static condition.
Table 39: Conducted RF receive sensitivity
Frequency
GSM850,EGSM900
DCS1800,PCS1900

6.10.3 Module Operating Frequencies

The following table shows the module's operating frequency range; it is followed by the 3GPP TS 05.05
technical specification requirement.
Table 40: Operating frequencies
Frequency
GSM850
EGSM900
DCS1800
PCS1900
SIM800C_Hardware_Design_V1.00
22
20
18
16
14
12
10
8
6
4
2
0
Receive sensitivity（Typical）
< -109dBm
< -109dBm
Receive
869 ～ 894MHz
925 ～ 960MHz
1805 ～ 1880MHz
1930 ～ 1990MHz
47
Smart Machine Smart Decision
±3
±3
±3
±3
±3
±4
±4
±4
±4
±4
±5
±5
Receive sensitivity(Max)
< -107dBm
< -107dBm
Transmit
824 ～ 849MHz
880 ～ 915MHz
1710 ～ 1785MHz
1850 ～ 1910MHz
±4
±4
±4
±4
±4
±5
±5
±5
±5
±5
±6
±6
2014-10-30
